Description
The Eaton 5S UPS provides cost effective line interactive backup power and automatic voltage regulation (AVR) for small and medium businesses. Suited for workstations, desktop PCs, telephone equipment, this product also brings internet and Ethernet protection With its 4 IEC outlets ( 3 with battery backup and surge protection and one with lightning protection only), It can be placed as a standalone tower or under a computer monitor and its slim line design saves space. Furthermore, the 5S possesses an audible alarm to warn you when there is a power problem.
-
Efficient power management
The Eaton 5S UPS features line interactive technology that provides reliable, efficient power management to protect your devices during power fluctuations. -
Convenient connectivity
With a USB remote management interface, this UPS allows for easy monitoring and management of your power backup system, ensuring seamless operation and minimal downtime.
Specifications
Summary
- Product Description
- Eaton 5S 550i - UPS - 330 Watt - 500 VA
- Device Type
- UPS - external
- Weight
- 4.96 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 230 V ± 10%
- Power Capacity
- 330 Watt / 500 VA
- Input Connectors
- 1
- Output connectors
- 1 x power IEC 60320 C13 (surge) , 3 x power IEC 60320 C13 (UPS and surge)
- Run Time (Up To)
- 10 min
- Networking
- USB
- Colour
- Black
- System Requirements
- Linux, Apple MacOS X, Microsoft Windows Vista / 7 / 8
- Dimensions (WxDxH)
- 8.7 cm x 26 cm x 25 cm
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- UPS - external
- Colour
- Black
Power Device
- UPS Technology
- Line interactive
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 175 - 275 V
- Frequency Required
- 50 - 60 Hz
- Input Connectors
- 1
- Power Output Connectors Details
- 1 x power IEC 60320 C13 (surge) , 3 x power IEC 60320 C13 (UPS and surge)
- Output Voltage
- AC 230 V ± 10%
- Power Capacity
- 330 Watt / 500 VA
- Dataline Surge Protection
- Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line
- Surge Suppression
- Yes
Battery
- Run Time (Up To)
- 10 min at half load , 6 min at 70% load
Networking
- Remote Management Interface
- USB
Expansion / Connectivity
- Interfaces
- 1 x management (USB) - 4 pin USB Type B
Miscellaneous
- Cables Included
- USB cable - external
- Features
- Automatic Voltage Regulation (AVR)
- Compliant Standards
- CB, IEC 62040-3, IEC 62040-1-1
Software / System Requirements
- OS Required
- Linux, Apple MacOS X, Microsoft Windows Vista / 7 / 8
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years , Limited warranty - batteries - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
Dimensions & Weight
- Width
- 8.7 cm
- Depth
- 26 cm
- Height
- 25 cm
- Weight
- 4.96 kg
