Description
The fi-7160 document scanner from Fujitsu is armed with a host of automated hardware and software based tools designed to make the job of scanning mixed batches of documents as seamless and hassle free as possible. Impressive scan speeds, industry leading paper protection mechanisms, status monitoring tools and bundled Fujitsu developed driver (PaperStream IP) and image enhancement software (PaperStream Capture) help ensure that the capture of your documents is done reliably and efficiently.
-
Critical for perfect results: the interplay between hard- and software
Both hardware and software are equally important in the Fujitsu fi-7160 scanner. The newly developed PaperStream IP driver and image processing middleware combined with the PaperStream Capture software offer simplified and automated batch scanning routines that intelligently convert batches of documents into predetermined work routines. -
iSOP - "senses" the feeding process
In addition to the industry leading paper protection feature of the previous generations, the new model introduces a premium feature into a desktop scanner - the intelligent Sonic Paper Protection mechanism iSOP. This is an acoustic noise sensor module that monitors the feeding process. It detects the sound emission of every document, recognizing any sound indicating an irregularity and immediately stops the paper feed motion, saving users' time and protecting important and valuable originals. -
Top results, quickly and reliably
This new fi series model offers USB 3.0 support and is designed to make end-to-end scanning processes faster. The fi-7160 model processes up to 60 sheets/120 pages per minute (A4, color, duplex, 300 dpi). Additional functions also help deliver top results. For example, it is easy to scan a mixed batch containing sheets of different sizes and thicknesses. The scanner mechanically straightens any documents that may have been fed askew and PaperStream IP also automatically corrects any remaining irregularities. An ultrasonic sensor recognizes whether two or more sheets have fed in and issues an error message. Even sticky notes do not delay the workflow as the system recognizes them automatically. Further, user support is provided through the scanners' LCD panel which provides straightforward operation flows and allows users to select profiles directly on the device, check the quantity of scanned documents or review any status messages. -
Scanner central administration lowers operating costs
The scanner central administration function allows management of all of the new fi Series scanners efficiently. For example, administrators can determine scan profiles, install drivers applications with ease and perform updates centrally. Error messages or maintenance status updates also appear in the central management functions. The result is a much lower TotalCost of Ownership (TCO). -
PaperStream IP - top-quality image processing and enhancement
PaperStream IP represents a totally new type of driver middleware. Advanced black and white and color processing automatically converts every document into an image of extraordinary quality. Users need not worry about individual scanning parameters but are able to adjust any parameter to suit their needs to specific jobs. PaperStream IP prepares digitized data for subsequent processing such as OCR (Optical Character Recognition) and connects with common scanning applications that would regularly control the scanner via either the TWAIN or ISIS interface. PaperStream IP also provides a unique triple stream capability. -
PaperStream Capture - optimizes batch scanning
PaperStream Capture allows users to fine-tune their document work flow (including batches) at every step. Once users have scanned a batch they can instantly release it to the defined destination or place it into a queue for subsequent validation and additional processing. The software also brings flexibility when users need to add more documents to an existing batch at a later point in time: newly scanned documents of the same class or belonging to the same logical batch can be appended without the need to re-scan the entire set. Users of ECM (Enterprise Content Management) and DMS (Document Management System) applications can use PaperStream Capture as a versatile onramp for document batches being fed into their productivity applications with less effort and offering better quality performance. -
ScanSnap Manager for fi Series - universal everyday use
In addition to offering full-featured document capture and batch processing, the fi Series is also on hand for more ad-hoc daily tasks through the ScanSnap Manager for fi Series. This allows users to undertake individual tasks at their desks such as Scan-to-PDF, Scan-to-Email or Scan-to-Word.
Specifications
Summary
- Product Description
- Fujitsu fi-7160 - document scanner - desktop - USB 3.0
- Device Type
- Document scanner - desktop
- Interface Type
- USB 3.0
- Scanning Sensor Type
- Dual CCD
- Max Supported Document Size
- 216 x 355.6 mm
- Input Type
- Colour
- Grayscale / Color Depth (External)
- 8-bit (256 grey levels) / 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Max Document Scan Speed
- 60 ppm (mono) / 60 ppm (colour)
- Max Document Size
- 216 mm x 5588 mm
- Automatic Duplexing
- Yes
- Supported Document Type
- Plain paper
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 80 sheets
- Duty Cycle
- 4000 scans per day
- Power
- AC 120/230 V (50/60 Hz)
- System Requirements
- Microsoft Windows Vista (32/64 bits), Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Windows 8 (32/64 bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Microsoft Windows Server 2012 R2 x64 Edition, Ubuntu 14.04 LTS, Windows 10 (32/64 bits), Ubuntu 16.04, Microsoft Windows Server 2016 (64-bit)
- Dimensions (WxDxH)
- 30 cm x 17 cm x 16.3 cm
- Weight
- 4.2 kg
- Environmental Standards
- ENERGY STAR Qualified
Detailed Specification
General
- Type
- Document scanner - desktop
- Interface Type
- USB 3.0
- Max Supported Document Size
- 216 x 355.6 mm
Scanner
- Input Type
- Colour
- Grayscale Depth (External)
- 8-bit (256 grey levels)
- Colour Depth (External)
- 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Automatic Duplexing
- Yes
- Scanning Sensor Type
- Dual CCD
- Max Document Scan Speed B/W
- 60 ppm
- Max Document Scan Speed Colour
- 60 ppm
- Duty Cycle
- 4000 scans per day
- Scanner Speed Details
- 60 ppm - colour - 200 dpi , 60 ppm - colour - 300 dpi , 60 ppm - greyscale - 200 dpi , 60 ppm - greyscale - 300 dpi , 60 ppm - black & white - 200 dpi , 60 ppm - black & white - 300 dpi , 120 ipm - duplex - colour - 200 dpi , 120 ipm - duplex - colour - 300 dpi , 120 ipm - duplex - greyscale - 200 dpi , 120 ipm - duplex - greyscale - 300 dpi , 120 ipm - duplex - black & white - 200 dpi , 120 ipm - duplex - black & white - 300 dpi
- Scanner Features
- Built-in LCD screen
- Compliant Standards
- TWAIN, ISIS
Media Handling
- Max Document Size
- 216 mm x 5588 mm
- Supported Document Type
- Plain paper
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 80 sheets
Expansion / Connectivity
- Interfaces
- USB 3.0 - Type B
Miscellaneous
- Compliant Standards
- RoHS
Environmental Standards
- EPEAT Compliant
- EPEAT Silver
- ENERGY STAR Certified
- Yes
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational (Standby)
- 38 Watt (1.8 Watt)
Software / System Requirements
- Software Included
- ScanSnap Manager, Scan to Microsoft SharePoint, Scanner Central Admin, Software Operation Panel, PaperStream IP, PaperStream Capture, Error Recovery Guide
- OS Required
- Microsoft Windows Vista (32/64 bits), Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Windows 8 (32/64 bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Microsoft Windows Server 2012 R2 x64 Edition, Ubuntu 14.04 LTS, Windows 10 (32/64 bits), Ubuntu 16.04, Microsoft Windows Server 2016 (64-bit)
Dimensions & Weight
- Width
- 30 cm
- Depth
- 17 cm
- Height
- 16.3 cm
- Weight
- 4.2 kg
Environmental Parameters
- Min Operating Temperature
- 5 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 20 - 80% (non-condensing)
