Description
With scanning speeds of 100 ppm/200 ipm (200/300 dpi), the fi-7600 greatly improves process efficiency. Large volumes of information can be captured from various media types, including thin paper, plastic cards, envelopes and long page documents.
The fi-7600 automatically adjusts to paper weights from 20-413 g/m². The straight paper path reduces the load on a document and assures reliable scanning regardless of the condition and type of a document. By simply sliding a lever to non-separation mode, you can easily scan thick and long documents folded in half, multi-layered document sets and envelopes.
Skew Reducer automatically handles sheets of paper in a stack individually, so that if one sheet is fed-in skewed, subsequent sheets are not forced into physical skew. This ensures that all information in the documents is captured correctly, even in batches with mixed document formats. The Paper Protection function monitors document movement and automatically stops feeding when any irregularities are detected.
The fi-7600 is equipped with an operation panel on both sides allowing for right and left handed use. The LCD on the operation panel reveals the scanner status at a glance and enables instant operation.
The Automatic Document Feeder's (ADF) independent side guides move to exactly the position required for each batch. The adjustable stacker side guides support neat alignment of processed documents.
The fi-7600 comes bundled with PaperStream IP, an integrated scanner driver and image enhancement module that is built on TWAIN/ISIS standards offering user friendly operability, intuitive high quality image creation and real time processing that will benefit post scan routines like OCR. PaperStream Capture enhances the document capture process from adjusting scanning settings to performing batch scanning, verifying data and releasing to directories, repositories or subsequent process routines. Users can complete data capture tasks easily with the extremely user-friendly graphical user interface (GUI). Moving scanned batches into a queue for later retrieval is possible as well.
-
Efficient scanning capabilities
The fi-7600 delivers remarkable scanning capabilities, offering an impressive duty cycle of 30,000 scans per day. Its automatic duplexing feature allows for scanning both sides of a document simultaneously, maximizing productivity. -
Advanced image processing
Equipped with Advanced DTC, Barcode Detection, and Ultrasonic multifeed sensor, the fi-7600 ensures high-quality scans. Features like Blank Page Detection and RGB Color Dropout enhance scan accuracy, making it ideal for diverse document types. -
Versatile document handling
This scanner accommodates a wide range of document sizes, from small cards to large formats up to 304.8 x 5588 mm. Its 300-sheet feeder capacity and support for embossed cards and plastic cards make it highly versatile for professional use. -
High-speed performance
Achieve efficiency with scan speeds of up to 100 ppm/200 ipm in color and black and white. The fi-7600's ability to handle high volumes quickly makes it a valuable asset for fast-paced environments. -
Energy-efficient design
ENERGY STAR certification and a power-efficient operation, with a sleep mode consuming only 1.7 watts, underscore the fi-7600's commitment to environmental sustainability without compromising on performance.
Specifications
Summary
- Product Description
- Ricoh fi-7600 - document scanner - desktop - USB 3.1 Gen 1
- Device Type
- Document scanner - desktop
- Interface Type
- USB 3.1 Gen 1
- Scanning Sensor Type
- Dual CCD
- Light Source
- White LED array
- Additional Functions
- Scan to SharePoint
- Max Supported Document Size
- 304.8 x 431.8 mm
- Input Type
- Colour
- Grayscale / Color Depth (External)
- 8-bit (256 grey levels) / 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Interpolated Resolution
- 1200 dpi x 1200 dpi
- Max Document Scan Speed
- 100 ppm (mono) / 100 ppm (colour)
- Max Document Size
- 304.8 mm x 5588 mm
- Automatic Duplexing
- Yes
- Supported Document Type
- Plain paper, plastic card, envelope, embossed card
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 300 sheets
- Duty Cycle
- 30000 scans per day
- Power
- AC 120/230 V
- System Requirements
- Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Microsoft Windows Server 2012 R2 x64 Edition, Windows 10 (32/64 bits), Microsoft Windows Server 2016 (64-bit)
- Dimensions (WxDxH)
- 23.6 cm x 43.2 cm x 21.4 cm
- Weight
- 11 kg
- Environmental Standards
- ENERGY STAR Qualified
- Manufacturer Warranty
- 1-year warranty
Detailed Specification
General
- Type
- Document scanner - desktop
- Interface Type
- USB 3.1 Gen 1
- Additional Functions
- Scan to SharePoint
- Max Supported Document Size
- 304.8 x 431.8 mm
Scanner
- Input Type
- Colour
- Grayscale Depth (External)
- 8-bit (256 grey levels)
- Colour Depth (External)
- 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Interpolated Resolution
- 1200 dpi x 1200 dpi
- Automatic Duplexing
- Yes
- Scanning Sensor Type
- Dual CCD
- Bulb / Light Source Type
- White LED array
- Max Document Scan Speed B/W
- 100 ppm
- Max Document Scan Speed Colour
- 100 ppm
- Duty Cycle
- 30000 scans per day
- Scanner Speed Details
- 100 ppm - landscape - A4 - 200 dpi , 100 ppm - landscape - A4 - 300 dpi , 200 ipm - duplex - landscape - A4 - 200 dpi , 200 ipm - duplex - landscape - A4 - 300 dpi , 80 ppm - portrait - A4 - 200 dpi , 80 ppm - portrait - A4 - 300 dpi , 160 ipm - duplex - portrait - A4 - 200 dpi , 160 ipm - duplex - portrait - A4 - 300 dpi
- Scanner Features
- Paper Protection Function, Image Emphasis, Long Paper Mode, Dynamic Threshold, Error Diffusion, Barcode Detection, Ultrasonic multifeed sensor, automatic colour detection, Dither, Advanced DTC, Multi-Image Output, built-in LCD screen, RGB Color Dropout, Punch Hole Removal, Deskew, Blank Page Detection
- Compliant Standards
- TWAIN, ISIS
Media Handling
- Max Document Size
- 304.8 mm x 5588 mm
- Supported Document Type
- Plain paper, plastic card, envelope, embossed card
- Supported Document Size Details
- ADF - up to 304.8 x 431.8 mm , Long document - up to 304.8 x 5588 mm
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 300 sheets
Expansion / Connectivity
- Interfaces Details
- USB 3.1 Gen 1 - Type B
Miscellaneous
- Cables Included
- 1 x USB cable
- Compliant Standards
- RoHS
Environmental Standards
- ENERGY STAR Certified
- Yes
Power
- Power Device
- External power adapter
- Voltage Required
- AC 120/230 V
- Power Consumption Operational (Standby)
- 64 Watt
- Power Consumption Stand by
- 0.35 Watt
- Power Consumption Sleep
- 1.7 Watt
Software / System Requirements
- Software Included
- Drivers & Utilities, ScanSnap Manager, Scan to Microsoft SharePoint, ABBYY FineReader for ScanSnap, Scanner Central Admin, Software Operation Panel, PaperStream IP, PaperStream Capture, 2D Barcode for PaperStream, Error Recovery Guide
- OS Required
- Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Microsoft Windows Server 2012 R2 x64 Edition, Windows 10 (32/64 bits), Microsoft Windows Server 2016 (64-bit)
Dimensions & Weight
- Width
- 23.6 cm
- Depth
- 43.2 cm
- Height
- 21.4 cm
- Weight
- 11 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - 1 year
Environmental Parameters
- Min Operating Temperature
- 5 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 20 - 80% (non-condensing)
