TP LINK JetStream 24-Port Gigabit SFP L2 Managed Switch

Review this product
Quicklinx: FNDFWS00 Mfr#: T2600G-28SQ
Type: Gigabit Ethernet
Ports: 28
Managed: Yes
Ordered upon request
£363.36 ex VAT
£436.03 inc VAT
Qty
Standard delivery Product out of stock. Due date unavailable.

Description

TP-Link's JetStream T2600G-28SQ provides high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. With 24 gigabit SFP slots, 4 10/100/1000 Mbps RJ45 ports and 4 10G SFP+ slots, T2600G-28SQ ensures a highly stable and high-speed network environment. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-of-Service (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitates network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link JetStream L2 managed Switches T2600G-28SQ provides a reliable, secure solution for enterprise, campus and ISP networks.

  • Secure networking

    The T2600G-28SQ provides IP-MAC-Port Binding, Port Security, Storm control and DHCP Snooping which protect against broadcast storms, ARP attacks, etc. It integrates some typical Dos attacks to select. You can protect these attacks more easily ever than before. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports and even VLAN ID. Moreover, the switch supports 802.1X authentication, which is used in conjunction with a RADIUS/Tacacs+ server to require some authentication information before access to the network is allowed.
  • Advanced QoS features

    To integrate voice, data and video service on one traffic based on a variety of means including IP or MAC address, TCP or UDP port number, etc, to ensure that voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN the switch supporting, the voice applications will operate with much smoother performance.
  • Abundant L2 and L2+ features

    T2600G-28SQ supports a complete lineup of L2 features, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow Control function. Any more, the switch provides advanced features for network maintenance. Such as Loopback Detection, Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Moreover, T2600G-28SQ supports L2+ feature-static routing, which is a simple way to provide segmentation of the network with internal routing through the switch and helps network traffic for more efficient use.
  • ISP features

    T2600G-28SQ supports a bundle of ISP features such as 802.3ah OAM, DDM, sFlow, QinQ, L2PT PPPoE ID Insertion, IGMP authentication etc. 802.3ah OAM and Device Link Detection Protocol (DLDP) functions improve monitor and troubleshoot Ethernet networks, help facilitate network management. DDM(Digital Diagnostic Monitoring) function helps view the status of SFP modules inserting to the Switch and to configure alarm settings, warning settings, temperature threshold settings, voltage threshold settings, bias current threshold settings, TX power threshold settings, and RX power threshold settings.
  • IPv6 support

    T2600G-28SQ series support various IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discovery, which guarantees your network is ready for the Next Generation Network (NGN) without upgrading your network equipment.
  • Enterprise level management features

    T2600G-28SQ is easy to use and manage. It supports various user-friendly standard management features, such as intuitive web-based Graphical User Interface (GUI) or industry-standard Command Line Interface (CLI), either administration traffic can be protected through SSL or SSH encryptions. SNMP (v1/v2c/v3) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events.

Specifications

Summary

Product Description
TP-Link JetStream T2600G-28SQ - switch - 28 ports - Managed - rack-mountable
Device Type
Switch - 28 ports - L2+ - Managed
Enclosure Type
Rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
24 x SFP + 4 x combo Gigabit Ethernet/Gigabit SFP + 4 x 10 Gigabit SFP+
Performance
Bandwidth: 128 Gbps , Packet forwarding rate: 95.2 Mpps
MAC Address Table Size
16K entries
Jumbo Frame Support
9216 bytes
Routing Protocol
IGMPv2, IGMP, static IP routing, IGMPv3, static IPv6 routing, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2, CLI
Features
Flow control, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, port mirroring, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MLD snooping, Dynamic ARP Inspection (DAI), Device Link Detection Protocol (DLDP) support, IPv4 support, DHCP relay, Link Aggregation Control Protocol (LACP), Port Security, IP-MAC binding, DHCP client, Neighbor Discovery Protocol (NDP), static routing, Loopback, Generic Attribute Registration Protocol (GARP), 802.1x authentication, GARP VLAN Registration Protocol (GVRP), DiffServ Code Point (DSCP) support, 2 fans, 1.5MB packet buffer, IP source guard, ARP inspection, Bridge protocol data unit (BPDU)
Compliant Standards
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.3at
Power
AC 120/230 V (50/60 Hz)
Dimensions (WxDxH)
44 cm x 22 cm x 4.4 cm
System Requirements
UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows XP / Vista / 7 / 8 / 10


Detailed Specification

General

Device Type
Switch - 28 ports - L2+ - Managed
Enclosure Type
Desktop, rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
24 x SFP + 4 x combo Gigabit Ethernet/Gigabit SFP + 4 x 10 Gigabit SFP+
Performance
Bandwidth: 128 Gbps , Packet forwarding rate: 95.2 Mpps
MAC Address Table Size
16K entries
Jumbo Frame Support
9216 bytes
Routing Protocol
IGMPv2, IGMP, static IP routing, IGMPv3, static IPv6 routing, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2, CLI
Encryption Algorithm
TLS 1.0, SSL 3.0
Authentication Method
Secure Shell (SSH), RADIUS, Secure Shell v.2 (SSH2), internal user database
Features
Flow control, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, port mirroring, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MLD snooping, Dynamic ARP Inspection (DAI), Device Link Detection Protocol (DLDP) support, IPv4 support, DHCP relay, Link Aggregation Control Protocol (LACP), Port Security, IP-MAC binding, DHCP client, Neighbor Discovery Protocol (NDP), static routing, Loopback, Generic Attribute Registration Protocol (GARP), 802.1x authentication, GARP VLAN Registration Protocol (GVRP), DiffServ Code Point (DSCP) support, 2 fans, 1.5MB packet buffer, IP source guard, ARP inspection, Bridge protocol data unit (BPDU)
Compliant Standards
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.3at
Status Indicators
Port status, power, system, link/activity

Expansion / Connectivity

Interfaces
24 x 1000Base-X SFP , 4 x 1000Base-T / 1000Base-X RJ-45/SFP , 1 x console RJ-45 management , 1 x micro-USB output Type B management , 4 x 10GBase-X SFP+

Power

Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)

Miscellaneous

Included Accessories
Rubber feet
Rack Mounting Kit
Included
Compliant Standards
FCC, RoHS

Software / System Requirements

Software Included
Drivers & Utilities
OS Required
UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows XP / Vista / 7 / 8 / 10

Dimensions & Weight

Width
44 cm
Depth
22 cm
Height
4.4 cm

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 90% (non-condensing)
