NETGEAR ProSAFE XS708T 10GBase 8 Port Switch

NETGEAR ProSAFE XS708T 10GBase 8 Port Switch

Clearance!
Clearance
Last Few Remaining
Limited Time Offer
Review this product
Quicklinx: C4NHWS00 Mfr#: XS708T-100NES
Type: 10 Gigabit Ethernet
Ports: 8
Managed: Yes
Stock Status: In Stock
18 in stock
£537.88 ex VAT
£645.45 inc VAT
Qty
Standard delivery Delivered within 3 working days

Description

The XS708T 10-Gigabit Ethernet Smart Managed Switch brings the second generation of 10-Gigabit Copper switching to SMBs. The XS708T is a powerful Smart Managed Switch that includes 8 ports of 10-Gigabit connectivity (8 copper with 2 shared combo copper/SFP+ Fiber ports). NETGEAR's 10-Gigabit Smart Managed Switches are purposely designed as a cost-effective way to provide 10G connections to 10G-capable servers and NAS (Network Attached Storage) systems. The XS708T provides comprehensive L2+/Layer 3 Lite features (including IPV6 management) allowing SMB customers to deploy virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, which require higher reliability, speed, and performance. It can be used at the "center of a small business network" or as an aggregation/access switch in a larger organization. The XS708T is ideal for smaller workgroups that need high-bandwidth for sharing, collaborating, editing, and publishing high-density content like video or animation.

  • Comprehensive L2+ / Layer 3 Lite features

    The ProSAFE 10G Smart Managed Switch provides comprehensive L2+ / Layer 3 Lite features in order to meet current and future needs on virtualization, converged networking and mobility.
  • Smart IT, not big IT

    Easy-to-use web browser-based management GUI makes setup and management simple. It features a standards-based technology, ensuring interoperability with any standards-based devices in the existing network, as well as dual firmware images, improving reliability and uptime to your network.
  • 10-Gigabit transition with BASE-T

    10GBASE-T, like other BASE-T technologies, uses the standard RJ-45 Ethernet jack. It is backward compatible, auto-negotiating between higher and lower speeds - thereby not forcing an all-at-once network equipment upgrade.

Specifications

Summary

Product Description
NETGEAR ProSAFE XS708T - switch - 8 ports - smart - rack-mountable
Device Type
Switch - 8 ports - L3 Lite - smart
Enclosure Type
Rack-mountable 1U
Subtype
10 Gigabit Ethernet
Ports
8 x 10GBase-T + 2 x shared 10 Gigabit SFP+
Performance
Switching fabric bandwidth: 160 Gbps , Forwarding performance (64-byte packet size): 119 Mpps
Capacity
ACL: 100 , Virtual interfaces (VLANs): 512 , IGMP groups: 512 , IPv4 routes: 32 , IPv6 routes: 32 , Priority queues per port: 8 , ARP entries: 738 , DHCP snooping entries: 8000
MAC Address Table Size
16K entries
Jumbo Frame Support
9KB
Routing Protocol
Static IPv4 routing, static IPv6 routing
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
Features
Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, store and forward, MAC address filtering, Broadcast Storm Control, IP address filtering, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MLD snooping, Dynamic ARP Inspection (DAI), reset button, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Strict Priority Queuing (SPQ), 2MB packet buffer, Class of Service (CoS), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, cable test, layer 2+ switching
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
Dimensions (WxDxH)
44 cm x 20.4 cm x 4.3 cm
Weight
2.61 kg
Localisation
Latin America, North America, Europe
Manufacturer Warranty
NETGEAR lifetime warranty


Detail

General

Device Type
Switch - 8 ports - L3 Lite - smart
Enclosure Type
Desktop, rack-mountable 1U
Subtype
10 Gigabit Ethernet
Ports
8 x 10GBase-T + 2 x shared 10 Gigabit SFP+
Performance
Switching fabric bandwidth: 160 Gbps , Forwarding performance (64-byte packet size): 119 Mpps
Capacity
ACL: 100 , Virtual interfaces (VLANs): 512 , IGMP groups: 512 , IPv4 routes: 32 , IPv6 routes: 32 , Priority queues per port: 8 , ARP entries: 738 , DHCP snooping entries: 8000
MAC Address Table Size
16K entries
Jumbo Frame Support
9KB
Routing Protocol
Static IPv4 routing, static IPv6 routing
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
Encryption Algorithm
TLS 1.0, SSL 3.0
Authentication Method
RADIUS, TACACS+
Features
Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, store and forward, MAC address filtering, Broadcast Storm Control, IP address filtering, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MLD snooping, Dynamic ARP Inspection (DAI), reset button, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Strict Priority Queuing (SPQ), 2MB packet buffer, Class of Service (CoS), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, cable test, layer 2+ switching
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
Processor
Cortex-A9: 600 MHz
RAM
512 MB
Flash Memory
256 MB
Status Indicators
Port transmission speed, power, link/activity, fan

Expansion / Connectivity

Interfaces
8 x 10GBase-T RJ-45 , 2 x 10GBase-X SFP+ , 1 x USB 2.0 management

Power

Power Device
Internal power supply
Power Consumption Operational
49.5 Watt

Miscellaneous

Included Accessories
Rubber feet
Rack Mounting Kit
Included
MTBF
276,197 hours
Compliant Standards
cUL, EN 60950, IEC950, UL 1950, EN55024, CSA 22.2 No. 950, EN55022 Class A, CISPR 22, CCC, FCC Part 15 A, C-Tick Class A, SCC, VCCI Class A, TLS v1.2, TLS v1.0
Localisation
Latin America, North America, Europe

Software / System Requirements

Software Included
Drivers & Utilities

Dimensions & Weight

Width
44 cm
Depth
20.4 cm
Height
4.3 cm
Weight
2.61 kg

Manufacturer Warranty

Service & Support
NETGEAR lifetime warranty

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
90% (non-condensing)
Min Storage Temperature
-10 °C
Max Storage Temperature
70 °C
