Description
The XS748T 10-Gigabit Ethernet Smart Managed Switch brings the second generation of 10-Gigabit Copper switching to SMBs. The XS748T is a powerful Smart Managed Switch that includes 44 ports of 10-Gigabit connectivity (44 copper with 4 dedicated 10-Gigabit SFP+ Fiber ports). NETGEAR's 10-Gigabit Smart Managed Switches are purposely designed as a cost-effective way to provide 10G connections to 10G-capable servers and NAS (Network Attached Storage) systems. The XS748T provides comprehensive L2+/Layer 3 Lite features (including IPV6 management) allowing SMB customers to deploy virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, which require higher reliability, speed, and performance. It can be used at the "center of a small business network" or as an aggregation/access switch in a larger organization. The XS748T is ideal for is ideal for expanding network capacity, removing performance bottlenecks and/or support of premise expansion needs.
-
Comprehensive L2+ / Layer 3 Lite features
The ProSAFE 10G Smart Managed Switch provides comprehensive L2+ / Layer 3 Lite features in order to meet current and future needs on virtualization, converged networking and mobility. -
Smart IT, not big IT
Easy-to-use web browser-based management GUI makes setup and management simple. It features a standards-based technology, ensuring interoperability with any standards-based devices in the existing network, as well as dual firmware images, improving reliability and uptime to your network. -
10-Gigabit transition with BASE-T
10GBASE-T, like other BASE-T technologies, uses the standard RJ-45 Ethernet jack. It is backward compatible, auto-negotiating between higher and lower speeds - thereby not forcing an all-at-once network equipment upgrade.
Specifications
Summary
- Product Description
- NETGEAR Smart XS748T - switch - 48 ports - smart - rack-mountable
- Device Type
- Switch - 48 ports - L3 Lite - smart
- Enclosure Type
- Rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 44 x 10GBase-T + 4 x 10 Gigabit SFP+
- Performance
- Switching fabric bandwidth: 960 Gbps , Forwarding performance (64-byte packet size): 238 Mpps
- Capacity
- ACL: 164 , Virtual interfaces (VLANs): 512 , IGMP groups: 512 , IPv4 routes: 64 , IPv6 routes: 64 , Priority queues per port: 8 , ARP entries: 1024 , DHCP snooping entries: 1000
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 10KB
- Routing Protocol
- Static IPv4 routing, static IPv6 routing
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
- Features
- Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, WRR queuing, store and forward, MAC address filtering, Broadcast Storm Control, IP address filtering, Unicast Storm Control, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, RADIUS support, MLD snooping, reset button, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, SPQ, CoS, 802.1x authentication, ToS, DSCP support, 4 fans, 3MB packet buffer, cable test, layer 2+ switching
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
- Dimensions (WxDxH)
- 44 cm x 31 cm x 4.3 cm
- Weight
- 6.25 kg
- Localisation
- Latin America, North America, Europe
- Manufacturer Warranty
- NETGEAR lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 48 ports - L3 Lite - smart
- Enclosure Type
- Desktop, rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 44 x 10GBase-T + 4 x 10 Gigabit SFP+
- Performance
- Switching fabric bandwidth: 960 Gbps , Forwarding performance (64-byte packet size): 238 Mpps
- Capacity
- ACL: 164 , Virtual interfaces (VLANs): 512 , IGMP groups: 512 , IPv4 routes: 64 , IPv6 routes: 64 , Priority queues per port: 8 , ARP entries: 1024 , DHCP snooping entries: 1000
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 10KB
- Routing Protocol
- Static IPv4 routing, static IPv6 routing
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
- Encryption Algorithm
- TLS 1.0, SSL 2.0, TLS 1.2
- Authentication Method
- RADIUS, TACACS+
- Features
- Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, WRR queuing, store and forward, MAC address filtering, Broadcast Storm Control, IP address filtering, Unicast Storm Control, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, RADIUS support, MLD snooping, reset button, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, SPQ, CoS, 802.1x authentication, ToS, DSCP support, 4 fans, 3MB packet buffer, cable test, layer 2+ switching
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
- Processor
- : 800 MHz
- RAM
- 512 MB
- Flash Memory
- 256 MB
- Status Indicators
- Port transmission speed, power, link/activity, fan
Expansion / Connectivity
- Interfaces
- 44 x 10GBase-T RJ-45 , 4 x 10GBase-X SFP+ , 1 x USB 2.0 management
Power
- Power Device
- Internal power supply
- Power Consumption Operational
- 262.8 Watt
Miscellaneous
- Included Accessories
- Rubber feet
- Rack Mounting Kit
- Included
- MTBF
- 483,808 hours
- Compliant Standards
- cUL, EN 60950, IEC950, UL 1950, EN55024, CSA 22.2 No. 950, EN55022 Class A, CISPR 22, CCC, FCC Part 15 A, C-Tick Class A, SCC, VCCI Class A, TLS v1.2, TLS v1.0
- Localisation
- Latin America, North America, Europe
Software / System Requirements
- Software Included
- Drivers & Utilities
Dimensions & Weight
- Width
- 44 cm
- Depth
- 31 cm
- Height
- 4.3 cm
- Weight
- 6.25 kg
Manufacturer Warranty
- Service & Support
- NETGEAR lifetime warranty
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 90% (non-condensing)
- Min Storage Temperature
- -20 °C
- Max Storage Temperature
- 70 °C
