Description
Designed to provide essential solutions to small and medium businesses, the HP 2510 Switch Series consists of four Layer 2-managed switches that provide reliable 10/100 and 10/100/1000 connectivity. Building off of the popularity of the HP 2510-24 Switch, a 24-port 10/100 switch with two dual-personality ports, the 2510 switch series has expanded to include a higher-density HP 2510-48 Switch, with 48 10/100 ports and four Gigabit Ethernet uplinks. Additionally, the 2510-G switches add Gigabit Ethernet to the 2510 series, with the 2510G-24 and 2510G-48 switches, which are 24- and 48-port 10/100/1000 switches, each with four dual-personality ports, making them ideal for businesses that are ready to upgrade to increased network performance.
-
Quality of Service (QoS)
IEEE 802.1p prioritization: delivers data to devices based on the priority and type of traffic. -
Connectivity
10/100 and 10/100/1000 connectivity: provides customers with the choice of selecting the network connectivity speed that best meets their needs, with a consistent user experience.Gigabit uplinks: E2510-24 and E2510-48 switches: the E2510-24 switch has two dual-personality ports for either 10/100/1000 or mini-GBIC connectivity; the E2510-48 switch has four Gigabit Ethernet ports, which can all be used concurrently with two 10/100/1000 ports and two open mini-GBIC slots. E2510G-24 and E2510G-48 switches: four dual-personality ports for 10/100/1000 or SFP ports for optional fiber connectivity such as Gigabit-SX, -LX, and -LH, or 100-FX.HP Auto-MDIX: automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 copper ports. -
Resiliency and high availability
IEEE 802.1s Multiple Spanning Tree: provides high link availability in multiple VLAN environments by allowing multiple spanning trees; provides legacy support for IEEE 802.1d and IEEE 802.1w.IEEE 802.3ad Link Aggregation Control Protocol (LACP) and HP trunking: - E2510-24 switch supports up to two 10/100 trunks each with four links/ports plus one Gigabit Ethernet trunk. - E2510-48 switch supports up to 24 trunks with eight links/ports per trunk. - E2510-24G & E2510-48G switches support up to 24 trunks with eight links/ports per trunk. -
Manageability
IEEE 802.1AB Link Layer Discovery Protocol (LLDP): provides automated device discovery protocol for easy mapping by network management applications.RMON: provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events.Full-featured console: provides complete control of the switch with a familiar command-line interface (CLI).Web interface: allows configuration of the switch from any Web browser on the network.Single IP Address Management: provides single IP address management for a virtual stack of up to 16 switches.
Specifications
Summary
- Product Description
- HPE 2510-24 Switch - switch - 24 ports - Managed - rack-mountable
- Device Type
- Switch - 24 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Fast Ethernet
- Ports
- 24 x 10/100 + 2 x combo Gigabit SFP
- MAC Address Table Size
- 8K entries
- Routing Protocol
- IGMPv2, IGMPv3
- Remote Management Protocol
- SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP
- Features
- Flow control, Layer 2 switching, VLAN support, auto-uplink (auto MDI/MDI-X), manageable
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 44.3 cm x 23.6 cm x 4.4 cm
- Weight
- 2.2 kg
- Localisation
- English / United Kingdom
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 24 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Fast Ethernet
- Ports
- 24 x 10/100 + 2 x combo Gigabit SFP
- MAC Address Table Size
- 8K entries
- Routing Protocol
- IGMPv2, IGMPv3
- Remote Management Protocol
- SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP
- Encryption Algorithm
- SSL
- Authentication Method
- Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
- Features
- Flow control, Layer 2 switching, VLAN support, auto-uplink (auto MDI/MDI-X), manageable
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
- Processor
- 1 x MIPS: 264 MHz
- RAM
- 64 MB SDRAM
- Flash Memory
- 8 MB Flash
Expansion / Connectivity
- Interfaces
- 24 x 10Base-T/100Base-TX - RJ-45 , 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , 1 x console RJ-45 , 2 x SFP (mini-GBIC)
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 30 Watt
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- FCC Class A certified, CISPR 22 Class A, CISPR 24, cUL, EN 60950, EN 61000-3-2, EN55022, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, UL 60950, CSA 22.2 No. 60950
- Localisation
- English / United Kingdom
Dimensions & Weight
- Width
- 44.3 cm
- Depth
- 23.6 cm
- Height
- 4.4 cm
- Weight
- 2.2 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 15 - 95%
