HPE HP 830 24P PoE Wired WLAN Switch

Review this product
Quicklinx: 9R03WS00 Mfr#: JG640A
Type: Gigabit Ethernet
Ports: 24
Managed: Yes
POE: PoE+
Ordered upon request
£3,469.94 ex VAT
£4,163.92 inc VAT
Qty
Standard delivery Product out of stock. Due date unavailable.

Description

The HP 830 Unified Wired-WLAN Switch Series integrates both wireless controller and GbE switch functions. The switch series provides 1000 Mbps Ethernet ports, each supporting up to 30 W of PoE+ and manages IEEE 802.11a/b/g/n/ac APs to deliver unified access, consistent policy and RF optimization for your small to medium branch offices. The HP 830 24-Port PoE+ Unified Wired-WLAN Switch provides two optional 10GbE slots on the rear panel to relieve transmission bottleneck at the core of a WLAN network. The HP 830 Unified Wired-WLAN Switch Series are part of the HPN Mobility enterprise solution.

  • Enhanced Performance and Unified Access for Branch Offices

    The HPE 830 Unified Wired-WLAN Switch Series accommodates the growth of mobile devices by offering unified wired and wireless services in a single device, which can support up to 1000 wireless users and comes with 8 or 24 Gigabit Ethernet PoE+ ports.Supports both centralized and distributed forwarding options for unparalleled application performance and WLAN scalability.Offers a self-optimizing wireless network with Wi-Fi Clear Connect RF optimization, automatic interference mitigation and dynamic client load balancing for enhanced connectivity in dense client environments.Supports N+1, N+N redundancy, to provide continuity of services in branch offices.Provides granular access control policies based on Committed Access Rate (CAS), QoS profiles, SSID or access point location for user, application and BYOD initiatives.
  • Robust Security and Threat Protection

    The HPE 830 Unified Wired-WLAN Switch Series provides integrated wireless intrusion detection and prevention and supports Virtual Service Domains to deploy security policies by department or location.Provides robust security and threat protection with support for embedded or external authentication servers and integrated Endpoint Admission Defense (EAD).Provides role or SSID based access through embedded firewall to protect clients from outside attacks and restrict access to specific network resources.
  • Reduced Total Cost of Ownership (TCO) and Simplified Management

    The HPE 830 Unified Wired-WLAN Switch Series reduces TCO with a Limited Lifetime Warranty.Simplifies configuration, management and troubleshooting and policy enforcement for wired and wireless network with HPE single management tool.Reduces the cost of ownership by integrating wired and wireless connectivity in a single device eliminating the need to purchase separate wired and wireless access devices.

Specifications

Summary

Product Description
HPE 830 24-Port PoE+ Unified Wired-WLAN Switch - switch - 24 ports - Managed - rack-mountable
Device Type
Switch - 24 ports - Managed
Enclosure Type
Rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
24 x 10/100/1000 (PoE+) + 4 x shared Gigabit SFP
Power Over Ethernet (PoE)
PoE+
MAC Address Table Size
8K entries
Jumbo Frame Support
Yes
Routing Protocol
RIP-1, RIP-2, static IPv4 routing, static IPv6 routing
Remote Management Protocol
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI
Features
Flow control, Layer 2 switching, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, DiffServ support, Intrusion Detection System (IDS), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Endpoint Admission Defense (EAD), STP Root Guard, fan tray, MAC address lockout
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
Power
AC 120/230 V (50/60 Hz)
Dimensions (WxDxH)
44 cm x 42.9 cm x 4.29 cm
Weight
7.2 kg


Detail

General

Device Type
Switch - 24 ports - Managed
Enclosure Type
Rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
24 x 10/100/1000 (PoE+) + 4 x shared Gigabit SFP
Power Over Ethernet (PoE)
PoE+
MAC Address Table Size
8K entries
Jumbo Frame Support
Yes
Routing Protocol
RIP-1, RIP-2, static IPv4 routing, static IPv6 routing
Remote Management Protocol
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI
Encryption Algorithm
AES, SSL, TLS, TKIP, WPA, WPA2, PKI, WEP
Authentication Method
RADIUS
Features
Flow control, Layer 2 switching, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, DiffServ support, Intrusion Detection System (IDS), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Endpoint Admission Defense (EAD), STP Root Guard, fan tray, MAC address lockout
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
Processor
1: 750 MHz
RAM
512 MB DDR2 SDRAM
Flash Memory
1 GB

Expansion / Connectivity

Interfaces
24 x 1000Base-T RJ-45 PoE+ , 1 x console RJ-45 management , 4 x SFP (mini-GBIC)
Expansion Slots
2 (total) / 2 (free) x Expansion Slot

Power

Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)

Miscellaneous

Rack Mounting Kit
Included
Compliant Standards
CISPR 22 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, ICES-003 Class A, RoHS, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CAN/CSA C22.2 No. 60950-1, VCCI V-3 Class A ITE, VCCI V-4

Dimensions & Weight

Width
44 cm
Depth
42.9 cm
Height
4.29 cm
Weight
7.2 kg

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
