Description
The Ideal DSL Router with VPN for Small Business and Remote Working
DrayTek’s Vigor 2865 series Multi-WAN Firewall VPN routers are ideal for Superfast VDSL Broadband and Ethernet-based FTTP Fibre Broadband. With Gigabit throughput, Quality of Service, VPN client/server, comprehensive Firewall and Content Filtering controls.
Wi-Fi is available on ‘ac’ models and the integrated 4G+ LTE modem on ‘Lac’ models takes full advantage of mobile broadband. The Vigor 2865 series provides a reliable, flexible, and secure networking solution, that’s ideal for Home Offices, Small Business and Satellite Offices.
VDSL and Ethernet Load Balancer
Route Policy - Powerful Routing Management
Integrated LTE 4G/3G Modem
Constant Connectivity - Dual-SIM LTE
AC1300 Wireless LAN with Mesh
Ideal VPN router for SMB
Connect VPNs from behind NAT with DrayTek's VPN Matcher
Connecting Remote Sites with LAN to LAN VPN
DrayTek SSL VPN for Dial-In Teleworkers & LAN to LAN
5+1 Gigabit LAN Ports with VLANs
Designed for Central Management
Robust & Comprehensive IPv4 / IPv6 Firewall
Web Content Filtering with DNS Filter
High Availability - Hardware Failover
DrayDDNS - DrayTek Dynamic DNS Address
Manage Guest WiFi with Hotspot Web Portal
Quality of Service & Bandwidth Control
Central AP & Switch Management
-
VDSL and Ethernet Load Balancer
Connect the Vigor 2865 to Superfast Fibre with the integrated VDSL modem. Use the Ethernet WAN with cable and Ultrafast FTTP. Load Balance multiple connections to boost performance. -
Dual-SIM 4G+ LTE modem
Ensure ultra-reliable connectivity with an integrated high-performance 4G+/LTE Category 6 modem. Handle mobile network outages with Dual-SIM Failover. -
Packed with features
Take advantage of DrayTek's rich feature set and useful functionality such as Quality of Service, Route Policy, Hotspot Web Portal, VPN Matcher, DrayDDNS and more. -
Robust SMB VPN router
Quickly and securely connect remote sites with up to 32 VPN tunnels. Enable remote workers to access resources with DrayTek SSL VPN and OpenVPN support. -
5+1 Gigabit LAN ports with VLANs
Link server, computers, and network attached storage directly, with up to 6 Gigabit LAN ports. VLANs allow for as many as 8 separate networks, with options for Hotspot Captive Portal. -
VigorACS central management
The Vigor 2865 can be fully managed and configured remotely with the VigorACS central management platform. Manage DrayTek networks spanning multiple sites.
Specifications
Summary
- Product Description
- Draytek Vigor 2865Lac - router - DSL/WWAN - Wi-Fi 5 - desktop
- Device Type
- Router - DSL modem / wireless cellular modem - 6-port switch (integrated)
- Enclosure Type
- Desktop
- Digital Signaling Protocol
- ADSL, VDSL, ADSL2, ADSL2+, VDSL2, Vplus 35b
- Mobile Communication Protocol
- LTE
- WAN Ports Qty
- 2
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
- Frequency Band
- 2.4 GHz / 5 GHz
- Capacity
- Concurrent VPN tunnels: 32 , NAT sessions: 50000 , Concurrent SSL VPN tunnels: 16
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, ARP, FTP, DHCP, DNS, Bonjour, SMB, DDNS, DHCPv6, RTSP, IPv4, IPv6
- Routing Protocol
- RIP, BGP, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR)
- Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, TR-069
- VoIP Protocols
- H.323, SIP
- Features
- Firewall protection, load balancing, IGMP snooping, Syslog support, DoS attack prevention, content filtering, ALG support, port mirroring, E-mail alert, IPv6 support, VPN passthrough, High Availability, WDS support, URL filtering, firmware upgradable, WMM support, ACL support, QoS, IPSec NAT-T, WPS, IPSec passthrough, DHCP server, SMS alert, hidden SSID, reset button, bandwidth control, IPv4 support, DNS server, port triggering, 3G/4G USB Dongle Support, anti-spoofing protection, IP-MAC binding, application filtering, IGMP proxy, 802.1x authentication, ToS, PBC, L2TP passthrough, band steering, WDS bridge, Web Filtering, IGMP fast leave, Airtime Fairness, 2x2 MU-MIMO technology, L2TP over IPSec, client isolation, DMZ support, VLAN Tagging, port-based VLAN, port-based QoS, WDS repeater mode, multiple PVC support, broadcast threshold, DNS filtering, 2x2 MIMO technology, DNSSEC support, WLAN scheduling, DSCP based QoS, Brute Force Protection
- Compliant Standards
- IEEE 802.1Q, ANSI T1.413, IEEE 802.1p, IEEE 802.1x, UPnP
- Dimensions (WxDxH)
- 24.1 cm x 16.5 cm x 4.4 cm
- Weight
- 620 g
- Localisation
- United Kingdom, Ireland
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- Router - 6-port switch (integrated)
- Enclosure Type
- Desktop
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
- Frequency Band
- 2.4 GHz / 5 GHz
- Capacity
- Concurrent VPN tunnels: 32 , NAT sessions: 50000 , Concurrent SSL VPN tunnels: 16
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, ARP, FTP, DHCP, DNS, Bonjour, SMB, DDNS, DHCPv6, RTSP, IPv4, IPv6
- Routing Protocol
- RIP, BGP, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR)
- Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, TR-069
- Encryption Algorithm
- DES, Triple DES, MPPE, AES, SSL, SHA-1, WPA, WPA2, IKEv2, 256-bit SHA, WEP
- Authentication Method
- RADIUS, X.509 certificates, TACACS+, LDAP, internal user database, XAUTH authentication
- Features
- Firewall protection, load balancing, IGMP snooping, Syslog support, DoS attack prevention, content filtering, ALG support, port mirroring, E-mail alert, IPv6 support, VPN passthrough, High Availability, WDS support, URL filtering, firmware upgradable, WMM support, ACL support, QoS, IPSec NAT-T, WPS, IPSec passthrough, DHCP server, SMS alert, hidden SSID, reset button, bandwidth control, IPv4 support, DNS server, port triggering, 3G/4G USB Dongle Support, anti-spoofing protection, IP-MAC binding, application filtering, IGMP proxy, 802.1x authentication, ToS, PBC, L2TP passthrough, band steering, WDS bridge, Web Filtering, IGMP fast leave, Airtime Fairness, 2x2 MU-MIMO technology, L2TP over IPSec, client isolation, DMZ support, VLAN Tagging, port-based VLAN, port-based QoS, WDS repeater mode, multiple PVC support, broadcast threshold, DNS filtering, 2x2 MIMO technology, DNSSEC support, WLAN scheduling, DSCP based QoS, Brute Force Protection
- Compliant Standards
- IEEE 802.1Q, ANSI T1.413, IEEE 802.1p, IEEE 802.1x, UPnP
- Status Indicators
- WAN, DMZ, link/activity, USB, DSL, 5 GHz, 2.4 GHz, QoS
Line Properties
- Framing Format
- ANSI T1.413
Communications
- Type
- DSL modem / wireless cellular modem
- Digital Signaling Protocol
- ADSL, VDSL, ADSL2, ADSL2+, VDSL2, Vplus 35b
- Mobile Communication Protocol
- LTE
- Protocols & Specifications
- ITU G.992.1 (G.DMT), ITU G.992.5, ITU G.993.2, ITU G.993.5, ITU G.992.3
- Max Transfer Rate
- 300 Mbps
IP Telephony
- VoIP Protocols
- H.323, SIP
Expansion / Connectivity
- Interfaces
- LAN: 5 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , WAN: 1 x VDSL2 / ADSL2+ - RJ-11 , USB 2.0: 2 x 4 pin USB Type A
- Expansion Slots
- 2 SIM
Aerial
- Aerial
- External detachable
- Antenna Qty
- 2
Power
- Power Device
- External power adapter
Miscellaneous
- Cables Included
- 1 x modem cable
- Localisation
- United Kingdom, Ireland
Software / System Requirements
- OS Provided
- No operating system
Dimensions & Weight
- Width
- 24.1 cm
- Depth
- 16.5 cm
- Height
- 4.4 cm
- Weight
- 620 g
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
