Description
MU-MIMO technology serves several devices at once, reducing wait time, increasing Wi-Fi throughput for every device, and making each stream more efficient. As a powerful DSL modem router, the Archer VR2800 supports super fast VDSL or ADSL broadband, as well a variety of other connection types. The LAN/WAN port accepts connections from cable modem or fiber modem, and both of the USB 3.0 ports support 3G/4G dongle connections for a perfect main or backup internet connection. Beamforming technology locates the connected devices and further improves the Archer VR2800's range and the signal strength to each mobile device, delivering a more reliable and efficient wireless connection. Separate Wi-Fi bands enable more devices to connect to your network without a drop in performance.
-
MU-MIMO
MU-MIMO technology serves several devices at once, reducing wait time, increasing Wi-Fi throughput for every device, and making each stream more efficient. -
Versatile connectivity
As a powerful DSL modem router, the Archer VR2800 supports super fast VDSL or ADSL broadband, as well a variety of other connection types. The LAN/WAN port accepts connections from cable modem or fiber modem, and both of the USB 3.0 ports support 3G/4G dongle connections for a perfect main or backup internet connection. -
Wi-Fi with Beamforming
Beamforming technology locates the connected devices and further improves the Archer VR2800's range and the signal strength to each mobile device, delivering a more reliable and efficient wireless connection. -
Simultaneous dual band
Separate Wi-Fi bands enable more devices to connect to your network without a drop in performance.
Specifications
Summary
- Product Description
- TP-Link Archer VR2800 - wireless router - DSL modem - Wi-Fi 5 - Wi-Fi 5 - desktop
- Device Type
- Wireless router - DSL modem - 4-port switch (integrated)
- Enclosure Type
- Desktop
- Digital Signaling Protocol
- ADSL, ADSL2, ADSL2+, VDSL2
- WAN Ports Qty
- 2
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band
- 2.4 GHz / 5 GHz
- Routing Protocol
- IGMPv2, IGMP, static IP routing, IGMPv3
- Remote Management Protocol
- SNMP 1, SNMP 2c, HTTP, CLI, TR-069
- Features
- NAT support, ALG support, dynamic DNS server, print server, MAC address filtering, IPv6 support, parental control, IP address filtering, DDos attack prevention, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Wi-Fi Protected Setup (WPS), DHCP server, Samba support, FTP server, port forwarding, reset button, DHCP relay, Stateful Packet Inspection Firewall (SPIF), DHCP client, VPN Server, MU-MIMO technology, beamforming technology, Broadcom NitroQAM technology
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac
- Dimensions (WxDxH)
- 26.38 cm x 19.78 cm x 3.73 cm
Detailed Specification
General
- Device Type
- Wireless router - 4-port switch (integrated)
- Enclosure Type
- Desktop
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band
- 2.4 GHz / 5 GHz
- Routing Protocol
- IGMPv2, IGMP, static IP routing, IGMPv3
- Remote Management Protocol
- SNMP 1, SNMP 2c, HTTP, CLI, TR-069
- Encryption Algorithm
- 128-bit WEP, 64-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK
- Features
- NAT support, ALG support, dynamic DNS server, print server, MAC address filtering, IPv6 support, parental control, IP address filtering, DDos attack prevention, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Wi-Fi Protected Setup (WPS), DHCP server, Samba support, FTP server, port forwarding, reset button, DHCP relay, Stateful Packet Inspection Firewall (SPIF), DHCP client, VPN Server, MU-MIMO technology, beamforming technology, Broadcom NitroQAM technology
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, RoHS, RCM
Communications
- Type
- DSL modem
- Digital Signaling Protocol
- ADSL, ADSL2, ADSL2+, VDSL2
- Protocols & Specifications
- ITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite), ITU G.994.1 (G.hs), ITU G.992.3 (G.DMT.bis), ITU G.992.5, ITU G.993.2, ITU G.998.4, ITU G.993.5
Expansion / Connectivity
- Interfaces
- LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , USB 3.0: 2 x 9 pin USB Type A , WAN: 1 x VDSL2 / ADSL2+ - RJ-11
Aerial
- Aerial
- External detachable
- Antenna Qty
- 4
Power
- Power Device
- External power adapter
Miscellaneous
- Cables Included
- 1 x network cable , 1 x phone cable , 1 x phone splitter
Dimensions & Weight
- Width
- 26.38 cm
- Depth
- 19.78 cm
- Height
- 3.73 cm
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
