Description
The ModXStream Pro Series is the superlative solution for driving today's gaming systems, and can power both NVIDIA SLI and ATI CrossFire modes. Professional-grade yet designed with gamers and modders in mind, this PSU is stable, robust, and sports a sleek look and compact form factor. Kept ultra-cool with a load-controlled 135mm fan, the ModXStream Pro was engineered to be the quietest PSU available and eliminate distracting noises from your PC. Highly efficient, featuring up to 86% efficiency at typical load and up to 82% at full load, this leading-edge power supply remains rock solid and powerful while retaining superior efficiency under load.
As a gamer or case modder, modular cabling is a necessity when building a cool and orderly system. To optimize airflow and eliminate cable mazes, the ModXStream Pro is equipped with EZMod technology to allow complete customization of your power system by utilizing only the cables you require.
The OCZ ModXStream provides universal input and active PFC (Power Factor Correction) to effectively regulate input voltage across worldwide power grids and maintain an economical, stable supply of power.
Specifications
Summary
- Product Description
- OCZ ModXStream Pro - power supply - 700 Watt
- Device Type
- Power supply - active Power Factor Correction (PFC) - internal
- Specification Compliance
- ATX12V 2.2/ EPS12V
- Localisation
- United Kingdom
- Output Voltage
- +3.3, +5, ±12 V
- Power Capacity
- 700 Watt
- Output Current
- +5V - 25 A , +3.3V - 25 A , +12V1 - 25 A , +12V2 - 25 A , -12V - 0.3 A , +5VSB - 2.5 A
- Output connectors
- 1 x power 24 pin ATX with detachable 4 pin section , 1 x power 8 pin +12V , 1 x power 4 pin ATX12V connector , 1 x 6 pin PCI Express power , 1 x 8 pin PCI Express power with detachable 2 pin section , 4 x 4 PIN internal power , 2 x 4 PIN mini-power connector , 6 x 15 pin Serial ATA power
- Modular Cable Management
- Yes
- Dimensions (WxDxH)
- 15 cm x 16 cm x 8.6 cm
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- Power supply - active Power Factor Correction (PFC) - internal
- Specification Compliance
- ATX12V 2.2/ EPS12V
- PSU Form Factor
- ATX
- Localisation
- United Kingdom
Power Device
- Input Voltage Range
- AC 100 - 240 V
- Frequency Required
- 50 - 60 Hz
- Power Output Connectors Details
- 1 x power 24 pin ATX with detachable 4 pin section , 1 x power 8 pin +12V , 1 x power 4 pin ATX12V connector , 1 x 6 pin PCI Express power , 1 x 8 pin PCI Express power with detachable 2 pin section , 4 x 4 PIN internal power , 2 x 4 PIN mini-power connector , 6 x 15 pin Serial ATA power
- Output Voltage
- +3.3, +5, ±12 V
- Power Capacity
- 700 Watt
- Output Current
- +5V - 25 A , +3.3V - 25 A , +12V1 - 25 A , +12V2 - 25 A , -12V - 0.3 A , +5VSB - 2.5 A
- Modular Cable Management
- Yes
Miscellaneous
- MTBF
- 100,000 hours
- Features
- Over voltage protection, overpower protection, SLI ready, CrossFire ready, cable management, short-circuit protection
Manufacturer Warranty
- Service & Support
- Limited warranty - replacement - 3 years
Dimensions & Weight
- Width
- 15 cm
- Depth
- 16 cm
- Height
- 8.6 cm
