Description
The HPE 1620 Gigabit Switch Series is an entry-level, smart-managed switch ideal for small businesses looking for basic network features to enhance network performance but without the added complexity and cost of more advanced switches. Part of the HP OfficeConnect portfolio, these switches are plug-and-play out of the box. An intuitive Web GUI provides ease of access to fine tune switch operation, if necessary. The HPE 1620 Gigabit Switch Series consists of 8-, 24-, and 48-port models that can be rack mounted. Customizable features include VLANs, IEEE802.1p QoS and IGPM Snooping.
-
Simple Deployment and Management
The HPE 1620 Switch Series is an entry-level, smart-managed switch ideal for small businesses that deliver plug-n-play out of the box. No device configurations are needed to get up and running at gigabit speeds.An intuitive Web interface provides access to fine tune network performance, if necessary.Auto-speed negotiation automatically selects individual port speed depending on client capabilities without the need for manual intervention.All models come with internal power supplies removing the need to manage external power adapters and can be rack mounted with the included hardware. The 8-port model can be deployed on the desktop, on the wall or in the rack. -
Enhance Network Performance
The HPE 1620 Switch Series includes VLAN support to provide network traffic and resource segregation for additional security and better network performance.IEEE 802.1p QoS and IGMP Snooping prioritizes traffic and reduces unnecessary broadcast of multicast traffic for efficient network utilization. -
Peace of Mind
The HPE 1620 Switch Series has a Limited Lifetime Warranty.The switch series uses Energy Efficient Ethernet for lower power consumption.
Specifications
Summary
- Product Description
- HPE 1620-24G - switch - 24 ports - Managed - rack-mountable
- Device Type
- Switch - 24 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 24 x 10/100/1000
- Performance
- Throughput (64-byte packet size): up to 35.7 Mpps , Routing/switching capacity: 48 Gbps
- MAC Address Table Size
- 8192 entries
- Jumbo Frame Support
- 10KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3
- Remote Management Protocol
- SNMP 1, SNMP 3, SNMP 2c, CLI
- Features
- Flow control, full duplex capability, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, QoS, Jumbo Frames support, fanless, LACP, DHCP client, Energy Efficient Ethernet, dual firmware images, NTP time synchronisation, Loopback, DSCP support, cable test
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3az
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 43.99 cm x 17.3 cm x 4.39 cm
- Weight
- 2.2 kg
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 24 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 24 x 10/100/1000
- Performance
- Throughput (64-byte packet size): up to 35.7 Mpps , Routing/switching capacity: 48 Gbps
- MAC Address Table Size
- 8192 entries
- Jumbo Frame Support
- 10KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3
- Remote Management Protocol
- SNMP 1, SNMP 3, SNMP 2c, CLI
- Features
- Flow control, full duplex capability, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, QoS, Jumbo Frames support, fanless, LACP, DHCP client, Energy Efficient Ethernet, dual firmware images, NTP time synchronisation, Loopback, DSCP support, cable test
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3az
- Processor
- 1 x MIPS: 500 MHz
- RAM
- 128 MB SDRAM
- Flash Memory
- 32 MB
Expansion / Connectivity
- Interfaces
- 24 x 1000Base-T RJ-45 , 1 x console RJ-45 management
Power
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 15 Watt
Miscellaneous
- Rack Mounting Kit
- Included
- MTBF
- 123.46 years
- Compliant Standards
- CISPR 22 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, ICES-003 Class A, IEC 60950-1, EN 60950-1, UL 60950-1 Second Edition, FCC Part 15 A, VCCI Class A, CSA 22.2 No. 60950-1
Dimensions & Weight
- Width
- 43.99 cm
- Depth
- 17.3 cm
- Height
- 4.39 cm
- Weight
- 2.2 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - advance parts replacement - lifetime - response time: next business day
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
