Description
Synology RS2421+/RS2421RP+ are versatile 2U 12-bay storage servers designed to accommodate a diverse set of business environments. Scalable up to 24 drives, they are designed for cost-effective file management and sharing and include powerful backup capabilities designed for businesses with a growing data footprint. The unit delivers 2,200 MB/s 64K sequential read and 1154 MB/s sequential write performance1, and can be optionally enhanced with SSD cache and 10/25Gb Ethernet2.
Built for reliability
Redundant power3-
Reduce the possibility of power disruptions on a single distribution channel or PDU adversely impacting data and service availability.
Near-zero downtime-
Pair two identical devices with Synology High Availability and enable automatic minute-level failover between both devices in the event one server fails.
Data integrity and protection-
ECC memory brings higher system reliability, while the Btrfs file system helps prevent data corruption, supports snapshot technology, and simplifies data protection.
-
Versatile and reliable storage platform
RS2421RP+ units combine ample performance with versatile storage capabilities to deliver a cost-efficient data management solution. -
Optimized for data protection and integrity
Powered by Synology's DSM operating system, tailored for data management, and built upon the Btrfs file system, data stored on the S2421RP+ is safely guarded by modern data protection technologies. -
Remote and on-premises collaboration
Synology's collaboration suite provides a private cloud solution for on-premises and remote workers to concurrently edit documents, share files, manage emails, send instant messages, and more. -
Private video surveillance
With Synology surveillance station, the RS2421RP+ become powerful network video recorder solutions with support for up to 40 IP cameras. -
Virtualization and certified storage
DSM streamlines provisioning for and management of virtual machines with full certification for VMware vSphere, Microsoft Hyper-V, Citrix XenServer, and OpenStack virtualization environments.
Specifications
Summary
- Product Description
- Synology RackStation RS2421RP+ - NAS server
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet
- Enclosure Type
- Rack-mountable - 2U
- Max Supported Capacity
- 108 TB
- Installed Devices / Modules Qty
- 0 (installed) / 12 (max)
- Dimensions (WxDxH)
- 48.2 cm x 57.8 cm x 8.8 cm
- Weight
- 11.9 kg ()
- Processor
- 1 x Ryzen Embedded V1500B 2.2 GHz (Quad-Core)
- Storage Controller
- RAID SATA 6Gb/s RAID RAID 0, 1, 5, 6, 10, JBOD
- Networking
- 10Mb LAN, 100Mb LAN, 1GbE
- IP Cameras Supported
- 40
- RAM
- 4 GB
- Power
- AC 120/230 V (50/60 Hz)
- Power Redundancy
- Yes
- System Requirements
- Microsoft Windows 7, Apple macOS 10.12
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet
- Enclosure Type
- Rack-mountable - 2U
- Total Storage Capacity
- 0 GB
- Max Supported Capacity
- 108 TB
- Installed Devices / Modules Qty
- 0 (installed) / 12 (max)
- Width
- 48.2 cm
- Depth
- 57.8 cm
- Height
- 8.8 cm
- Weight
- 11.9 kg ()
Processor / Memory
- Processors Installed
- 1 x Ryzen Embedded V1500B 2.2 GHz
- Number of Cores
- Quad-Core
- Max Supported Qty
- 1
- RAM
- 4 GB (installed) / 32 GB (supported) - DDR4
Storage Controller
- Type
- RAID
- Interface Type
- SATA 6Gb/s
- RAID Level
- RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Networking
- Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE
- Network / Transport Protocol
- PPTP, L2TP, iSCSI, FTP, SMB, NFS, SFTP, HTTPs
- Remote Management Protocol
- SNMP, Telnet, HTTPS, SSH, SFTP
- Network Services Compatibility
- Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), SFTP
- Features
- VPN support, LDAP support, Access Control List (ACL) support, SSH support, e-mail server, reset button, Rsync compatible, L2TP support
- Encryption Algorithm
- SSL, TLS, AES-NI
Security DVR
- IP Cameras Supported
- 40
Expansion / Connectivity
- Expansion Bays
- 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5"
- Expansion Slots
- 1 (total) / 1 (free) x PCI Express
- Interfaces
- 4 x Ethernet 1000Base-T , 2 x USB 3.2 - Type A , 1 x management
Miscellaneous
- Features
- Built-in 3 cooling fans
- Compliant Standards
- TLS, SSL
Power
- Power Device
- Internal power supply
- Installed Qty
- 2
- Max Supported Qty
- 2
- Power Redundancy
- Yes
- Voltage Required
- AC 120/230 V (50/60 Hz)
Software / System Requirements
- OS Required
- Microsoft Windows 7, Apple macOS 10.12
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 5 - 95%
