Description
This 4-port DP KVM switch combines a 4K 60Hz display with KVM switch control of four connected PC and MAC computers. A simple yet comprehensive solution, this 4-port DisplayPort KVM switch combines 4K (60Hz) digital display capability with seamless KVM control of up to 4 connected PC computers and with Mini-DisplayPort adapters, it is also compatible with MAC computers and laptops, convertible notebooks, and tablets.
The DisplayPort KVM switch supports resolutions up to 4K at 60Hz and can drive one large DP display with ease for maximum viewing space.
Featuring audio and USB peripheral support along with both front-panel push-button and hotkey switching, and offering a small form factor with rear connection ports, this 4-port KVM switch will help to minimize workspace disruptions.
The integrated USB 2.0 hub lets you share two additional peripherals among attached computers as if they were directly connected. Sharing USB peripherals using the integrated hub eliminates the expense of duplicate devices such as printers, scanners, and so on.
If you'd like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rack-mountable KVM.
Specifications
Summary
- Product Description
- StarTech.com 4 Port DisplayPort KVM Switch, 4K 60Hz, Single Display, Dual Port UHD DP 1.2 USB KVM Switch with Integrated USB 2.0 Hub and Audio, Dell, HP, Apple, Lenovo, TAA Compliant - Keyboard/Video/Mouse Switch (SV431DPUA2) - KVM / audio switch - 4 ports
- Device Type
- KVM / audio switch - 4 ports
- Enclosure Type
- 1U
- Subtype
- KVM
- Ports
- 4 x KVM / audio
- KVM Users Qty
- 1 local user
- Features
- 4K resolution support
- Power
- AC 100 - 240 V 0.6 A
- Dimensions (WxDxH)
- 13.1 cm x 22 cm x 4.5 cm
- Weight
- 160 g
- Colour
- Black
- Localisation
- Australia, Japan, New Zealand, North America, United Kingdom, Europe
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- KVM / audio switch - 4 ports
- Enclosure Type
- Desktop 1U
- Subtype
- KVM
- Ports
- 4 x KVM / audio
- KVM Local Users Qty
- 1 local user
- Keyboard / Mouse Interface
- USB
- Max Resolution
- 3684 x 2160 @ 60 Hz
- Features
- 4K resolution support
- Status Indicators
- Port status, power
Expansion / Connectivity
- Interfaces
- 4 x DisplayPort , 4 x USB 2.0 Type B , 8 x audio output mini-jack , 1 x DisplayPort , 2 x audio output mini-jack , 4 x USB Type A
Power
- Power Device
- External power adapter
- Voltage Required
- AC 100 - 240 V
- Electric Current Required
- 0.6 A
- Power Consumption Operational
- 18 Watt
Miscellaneous
- Colour
- Black
- Included Accessories
- 4 foot pads
- Compliant Standards
- FCC, RoHS, WEEE
- Localisation
- Australia, Japan, New Zealand, North America, United Kingdom, Europe
Dimensions & Weight
- Width
- 13.1 cm
- Depth
- 22 cm
- Height
- 4.5 cm
- Weight
- 160 g
Dimensions & Weight (Shipping)
- Shipping Weight
- 190 g
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 40%
- Min Storage Temperature
- -10 °C
- Max Storage Temperature
- 60 °C
