Description
Unreal Performance, Realized.
Always Evolving SSD
The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by the latest V-NAND technology and firmware optimization. It maximizes the potential of NVMe bandwidth for unbeatable computing. In capacities up to 2TB, with reliability of up to 1,200 TBW.
Level up Performance
The 970 EVO Plus reaches sequential read/write speeds up to 3,500/3,300 MB/s, up to 53% faster than the 970 EVO. The latest V-NAND—which brings greater NAND performance and higher power efficiency—along with optimized firmware, a proven Phoenix controller, and Intelligent TurboWrite boost.
Unparalleled Reliability
Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops.
-
Level up performance
Samsung's V-NAND technology - which brings greater NAND performance and higher power efficiency - along with optimized firmware, a proven Phoenix controller, and Intelligent TurboWrite boost speeds. -
Design flexibility
The 970 EVO Plus fits high capacity onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung's innovative technology empowers you with the capacity to do more and accomplish more. -
Unparalleled reliability
Achieve a new level of drive confidence. Samsung's advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable remarkable heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to help minimize performance drops.
Specifications
Summary
- Product Description
- Samsung 970 EVO Plus MZ-V75S500BW - SSD - 500 GB - PCIe 3.0 x4 (NVMe)
- Type
- Solid state drive - internal
- Capacity
- 500 GB
- Hardware Encryption
- Yes
- Encryption Algorithm
- 256-bit AES
- NAND Flash Memory Type
- Triple-level cell (TLC)
- Form Factor
- M.2 2280
- Interface
- PCIe 3.0 x4 (NVMe)
- Buffer Size
- 512 MB
- Features
- TRIM support, sleep mode, Auto Garbage Collection Algorithm, V-NAND Technology, NVM Express (NVMe) 1.3, Samsung Phoenix Controller, S.M.A.R.T.
- Dimensions (WxDxH)
- 22.15 mm x 80.15 mm x 2.38 mm
- Weight
- 8 g
- Manufacturer Warranty
- 5-year warranty
- Designed For
- Intel Next Unit of Computing 11 Essential Kit - NUC11ATKPE
Detailed Specification
General
- Device Type
- Solid state drive - internal
- Capacity
- 500 GB
- Hardware Encryption
- Yes
- Encryption Algorithm
- 256-bit AES
- NAND Flash Memory Type
- Triple-level cell (TLC)
- Form Factor
- M.2 2280
- Interface
- PCIe 3.0 x4 (NVMe)
- Buffer Size
- 512 MB
- Features
- TRIM support, sleep mode, Auto Garbage Collection Algorithm, V-NAND Technology, NVM Express (NVMe) 1.3, Samsung Phoenix Controller, S.M.A.R.T.
- Width
- 22.15 mm
- Depth
- 80.15 mm
- Height
- 2.38 mm
- Weight
- 8 g
Performance
- SSD Endurance
- 300 TB
- Internal Data Rate
- 3500 MBps (read) / 3200 MBps (write)
- 4KB Random Read
- 19000 IOPS
- 4KB Random Write
- 60000 IOPS
- Maximum 4KB Random Write
- 550000 IOPS
- Maximum 4KB Random Read
- 480000 IOPS
Reliability
- MTBF
- 1,500,000 hours
Expansion & Connectivity
- Interfaces
- PCI Express 3.0 x4 (NVMe) - M.2 Card
- Compatible Bay
- M.2 2280
Power
- Power Consumption
- 5.8 Watt (average) , 9 Watt (maximum) , 30 mW (idle max)
Miscellaneous
- Compliant Standards
- IEEE 1667
Manufacturer Warranty
- Service & Support
- Limited warranty - 5 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 70 °C
- Shock Tolerance (operating)
- 1500 g @ 0.5 ms half-sine
Compatibility Information
- Designed For
- Intel Next Unit of Computing 11 Essential Kit - NUC11ATKPE
