Description
The ImageCenter ADS-2400N desktop scanner with Gigabit Ethernet networking offers powerful features for mid-to-large size workgroups that help simplify the way documents are captured, managed, processed, and delivered. The ImageCenter ADS-2400N boasts various integrated image optimization features, including multi-feed detection, background removal, blank page removal and deskew support, and many more.
-
Fast, durable desktop document scanner with networking - designed with workgroups in mind
The Brother ImageCenter ADS-2400N desktop scanner is a reliable addition to your mid-to-large size workgroup which will help simplify the way documents are captured, managed, processed, and delivered. Ideally suited for a wide variety of office environments, the ADS-2400N offers wired Gigabit Ethernet network connectivity as well as a Hi-Speed USB 2.0 interface for local connections. -
Scan to a variety of local or shared destinations
The ADS-2400N gives you the option to easily scan to a number of different destinations to help you manage your documents and workflow, including scanning to a file, an image, OCR software, or even to a printer. -
Advanced document capture solutions designed for businesses
With flexible media handling capabilities, the ADS-2400N can digitize materials. It also includes a variety of integrated image optimization features to help maximize output quality, including hole punch removal, edge cleanup, despeckle, background removal and more. Advanced scanning features further enhance capture versatility, including 2-in-1 mode for capturing 11" x 17" documents, and Continuous Scan Mode for scanning unlimited pages into a single file.
Specifications
Summary
- Product Description
- Brother ADS-2400N - document scanner - desktop - USB 2.0, Gigabit LAN, USB 2.0 (Host)
- Device Type
- Document scanner - desktop
- Interface Type
- USB 2.0, Gigabit LAN, USB 2.0 (Host)
- Additional Functions
- Email, scan to cloud, scan to USB
- Max Supported Document Size
- 215.9 x 5000 mm
- Input Type
- Colour
- Grayscale / Color Depth
- 8-bit (256 colours) / 30-bit colour
- Grayscale / Color Depth (External)
- 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Interpolated Resolution
- 1200 dpi x 1200 dpi
- Max Document Scan Speed
- 30 ppm (mono) / 30 ppm (colour)
- Max Document Size
- 215.9 mm x 5000 mm
- Automatic Duplexing
- Yes
- Supported Document Type
- Plain paper
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 50 sheets
- Duty Cycle
- 3000 scans per day
- Power
- AC 120/230 V (50/60 Hz)
- System Requirements
- Microsoft Windows Server 2003, Microsoft Windows Vista (32/64 bits), Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Apple OS X 10.8 Mountain Lion, Windows 8 (32/64 bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Apple OS X 10.9 Mavericks, Microsoft Windows Server 2012 R2 x64 Edition, Apple MacOS X 10.10, Windows 10 (32/64 bits), Apple MacOS X 10.11
- Dimensions (WxDxH)
- 30.6 cm x 25.8 cm x 25 cm
- Weight
- 4.45 kg
Detailed Specification
General
- Type
- Document scanner - desktop
- Interface Type
- USB 2.0, Gigabit LAN, USB 2.0 (Host)
- Additional Functions
- Email, scan to cloud, scan to USB
- Max Supported Document Size
- 215.9 x 5000 mm
Scanner
- Input Type
- Colour
- Grayscale Depth
- 8-bit (256 colours)
- Colour Depth
- 30-bit colour
- Colour Depth (External)
- 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Interpolated Resolution
- 1200 dpi x 1200 dpi
- Automatic Duplexing
- Yes
- Max Document Scan Speed B/W
- 30 ppm
- Max Document Scan Speed Colour
- 30 ppm
- Duty Cycle
- 3000 scans per day
- Scanner Speed Details
- 30 ppm - black & white - A4 , 30 ppm - colour - A4 , 60 ipm - duplex - black & white - A4 , 60 ipm - duplex - colour - A4
- Scanner Features
- Scan to portable USB drive
- Compliant Standards
- TWAIN, ISIS, WIA
Media Handling
- Max Document Size
- 215.9 mm x 5000 mm
- Supported Document Type
- Plain paper
- Supported Document Size Details
- ADF
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 50 sheets
Expansion / Connectivity
- Interfaces Details
- USB 2.0 (Host) - Type A , Gigabit LAN , USB 2.0 - Type B
Miscellaneous
- Cables Included
- 1 x USB cable
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational (Standby)
- 27 Watt
- Power Consumption Stand by
- 3 Watt
- Power Consumption Sleep
- 1.9 Watt
Software / System Requirements
- Software Included
- Brother Control Center 4, Brother Control Center 2, Nuance PaperPort 14, ABBYY FineReader Sprint 12
- OS Required
- Microsoft Windows Server 2003, Microsoft Windows Vista (32/64 bits), Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Apple OS X 10.8 Mountain Lion, Windows 8 (32/64 bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Apple OS X 10.9 Mavericks, Microsoft Windows Server 2012 R2 x64 Edition, Apple MacOS X 10.10, Windows 10 (32/64 bits), Apple MacOS X 10.11
Dimensions & Weight
- Width
- 30.6 cm
- Depth
- 25.8 cm
- Height
- 25 cm
- Weight
- 4.45 kg
Environmental Parameters
- Min Operating Temperature
- 5 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 20 - 80%
