Description
APC Smart-UPS SC is the perfect protection for the IT resources of your growing business. Manageable and cost effective, APC Smart-UPS SC is designed for use by small and medium companies looking to protect networking equipment, providing both power and data-line protection. Included PowerChute Business Edition management software allows you to configure safe system shutdowns and take advantage of advanced UPS management features like automated risk assessments and runtime capacity calculations. (All major operating systems supported). Communications are through your server's standard serial port. When you are ready to take your business to the next level you can use the same software environment found on Smart-UPS SC to seamlessly manage other Smart-UPS models, allowing you to grow your IT infrastructure without having to replace your software or retrain your administrators. Built on the same standards as the award winning Smart-UPS UPS, the Smart-UPS SC is the UPS to start your business with.
-
Front-access servicing
Simplifies installation and UPS maintenance while minimizing space requirements -
Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment -
Multiple mounting methods
Allows for standardization on one product for use in different environments
Specifications
Summary
- Product Description
- APC Smart-UPS SC 450VA - UPS - 280 Watt - 450 VA
- Device Type
- UPS - rack-mountable
- Rack Size
- 1U
- Weight
- 10.2 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 230 V ± 5%
- Power Capacity
- 280 Watt / 450 VA
- Input Connectors
- 1 x power IEC 60320 C14
- Output connectors
- 4 x power IEC 60320 C13
- Battery
- Lead Acid
- Battery Form Factor
- Plug-in module
- Run Time (Up To)
- 5.9 min at full load
- Networking
- RS-232
- Colour
- Grey
- Dimensions (WxDxH)
- 43.2 cm x 38.3 cm x 4.4 cm
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: AR106SH6, AR109SH6, AR112SH6, AR3003, AR3003SP, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP, AR3140G, AR3340G, AR3357X674, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, NBWL0356A
Detailed Specification
General
- Device Type
- UPS - rack-mountable
- Battery Enclosure Type
- Plug-in module
- Height (Rack Units)
- 1U
- Colour
- Grey
Power Device
- UPS Technology
- Line interactive
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 160 - 286 V
- Input Voltage Range (Adjustable)
- AC 151 - 302 V
- Frequency Provided
- 47 - 63 Hz
- Frequency Required
- 50/60 Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 4 x power IEC 60320 C13
- Output Voltage
- AC 230 V ± 5% - 47 - 63 Hz
- Power Capacity
- 280 Watt / 450 VA
- Dataline Surge Protection
- Network/phone line - RJ-45/RJ-11
- Output Waveform
- Stepped approximation to a sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 320 Joules
Battery
- Technology
- Lead Acid
- Run Time (Up To)
- 5.9 min at full load
Networking
- Remote Management Interface
- RS-232
Expansion / Connectivity
- Interfaces
- 1 x management (RS-232) - 9 pin D-Sub (DB-9)
Miscellaneous
- Cables Included
- Serial cable - external
- Rack Mounting Kit
- Included
- Features
- Audible alarm, LED display
- Compliant Standards
- C-Tick, GOST, PCBC, VDE, EN 50091-2
Software / System Requirements
- Software Included
- APC PowerChute Business Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95%
Dimensions & Weight
- Width
- 43.2 cm
- Depth
- 38.3 cm
- Height
- 4.4 cm
- Weight
- 10.2 kg
Compatibility Information
- Designed For
- P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR100, AR100HD, AR106SH6, AR109SH6, AR112SH6, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3003, AR3003SP, AR3006, AR3006SP, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3103, AR3103SP, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3106, AR3106SP, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3357X674, AR3810, AR3812, AR3814, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, AR8135BLK, NBWL0356A
