Description
WD Blue hard drives deliver solid performance and reliability while providing you with all of the space you need to hold enormous amounts of photos, videos, and files. WD Blue hard drives are designed for use as primary drives in notebooks and external enclosures.
-
SATA 6 Gb/s interface
The SATA 6 Gb/s interface provides greater flexibility for use with the advanced chipsets as well as backwards compatibility to legacy systems with SATA 3 Gb/s requirements. -
NoTouch ramp load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit. -
High quality
Built to the high standards of quality and reliability of the WD brand, these drives offer the features and capacity ideal for your everyday computing needs. -
Low power consumption
State-of-the-art seeking algorithms and advanced power management features help ensure low power consumption. -
Quiet
In a notebook drive, silence is golden. WD's exclusive noise reducing technologies yield some of the quietest hard drives on the market.
Specifications
Summary
- Product Description
- WD Blue WD20SPZX - hard drive - 2 TB - SATA 6Gb/s
- Type
- Hard drive - internal
- Capacity
- 2 TB
- Form Factor
- 2.5"
- Interface
- SATA 6Gb/s
- Data Transfer Rate
- 600 MBps
- Buffer Size
- 128 MB
- Spindle Speed
- 5400 rpm
- Features
- NoTouch ramp load technology, Advanced Format technology, S.M.A.R.T.
- Dimensions (WxDxH)
- 69.85 mm x 100.2 mm x 7 mm
- Weight
- 90 g
- Manufacturer Warranty
- 2-year warranty
- Designed For
- Intel Next Unit of Computing 13 Extreme Kit - NUC13RNGi5, 13 Extreme Kit - NUC13RNGi7, 13 Extreme Kit - NUC13RNGi9
Detailed Specification
General
- Device Type
- Hard drive - internal
- Capacity
- 2 TB
- Form Factor
- 2.5"
- Interface
- SATA 6Gb/s
- Buffer Size
- 128 MB
- Features
- NoTouch ramp load technology, Advanced Format technology, S.M.A.R.T.
- Width
- 69.85 mm
- Depth
- 100.2 mm
- Height
- 7 mm
- Weight
- 90 g
Performance
- Drive Transfer Rate
- 600 MBps (external)
- Spindle Speed
- 5400 rpm
Reliability
- Non-Recoverable Errors
- 1 per 10^14
- Start / Stop Cycles
- 600,000
Expansion & Connectivity
- Interfaces
- 1 x SATA 6 Gb/s - 7 pin Serial ATA
- Compatible Bay
- 2.5"
Power
- Power Consumption
- 1.7 Watt (read/write) , 0.5 Watt (idle) , 0.1 Watt (standby) , 0.1 Watt (sleep)
Software & System Requirements
- Software Included
- Acronis True Image WD Edition
Miscellaneous
- Compliant Standards
- RoHS, TUV Nord, NMB-3 Class B, CAN ICES-3 Class B
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 60 °C
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 65 °C
Compatibility Information
- Designed For
- Intel Next Unit of Computing 13 Extreme Kit - NUC13RNGi5, 13 Extreme Kit - NUC13RNGi7, 13 Extreme Kit - NUC13RNGi9
