Description
TPE-S44 Wireless PoE Access Point is today's link to Wireless Technology. Compliant with the IEEE Wireless Networking Standard 802.11g, it provides Direct Sequence Spread Spectrum (DSSS) operation for transparent bridging and roaming capabilities for wireless nodes. The TPE-S44 also provides WDS bridging functions, allowing users to connect two or more Access Points together, wirelessly. With this Wireless Access Point and Wireless Network Adapters, users can connect to Ethernet/Fast Ethernet LAN at home or office to access network resources with coverage up to 300 meters.
Specifications
Summary
- Product Description
- TRENDnet TPE-S44 - switch - 8 ports - TAA Compliant
- Device Type
- Switch - 8 ports
- Subtype
- Fast Ethernet
- Ports
- 4 x 10/100 (PoE) + 4 x 10/100
- Power Over Ethernet (PoE)
- PoE
- Performance
- Switching capacity: 1.6 Gbps
- MAC Address Table Size
- 1K entries
- Features
- Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, PoE overcurrent protection, PoE circuit sorting protection
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3x
- Dimensions (WxDxH)
- 17.1 cm x 9.8 cm x 2.9 cm
- Weight
- 430 g
- TAA Compliant
- Yes
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 8 ports
- Enclosure Type
- Desktop
- Subtype
- Fast Ethernet
- Ports
- 4 x 10/100 (PoE) + 4 x 10/100
- Power Over Ethernet (PoE)
- PoE
- Performance
- Switching capacity: 1.6 Gbps
- MAC Address Table Size
- 1K entries
- Features
- Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, PoE overcurrent protection, PoE circuit sorting protection
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3x
- Status Indicators
- Port status, power, link/activity
Expansion / Connectivity
- Interfaces
- 4 x 100Base-TX RJ-45 , 4 x 100Base-TX RJ-45 PoE - 15.4 W
Power
- Power Device
- External power adapter
- Power Consumption Operational
- 36.3 Watt
Miscellaneous
- Compliant Standards
- FCC
- TAA Compliant
- Yes
Dimensions & Weight
- Width
- 17.1 cm
- Depth
- 9.8 cm
- Height
- 2.9 cm
- Weight
- 430 g
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -10 °C
- Max Storage Temperature
- 70 °C
