Description
The TL-SL1218P is fully compatible with PoE devices, such as IP cameras, access points, and IP phones. It also works with non-PoE wired devices, such as PCs, printers, and IPTV.
Specifications
Summary
- Product Description
- TP-Link JetStream TL-SL1218P - V1 - switch - 16 ports - unmanaged - rack-mountable
- Device Type
- Switch - 16 ports - unmanaged
- Enclosure Type
- Rack-mountable
- Subtype
- Fast Ethernet
- Ports
- 16 x 10/100 (PoE+) + 2 x 10/100/1000 + 1 x combo Gigabit SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 150 W
- Performance
- Switching capacity: 7.2 Gbps , Packet forwarding rate: 5.36 Mpps
- MAC Address Table Size
- 8K entries
- Jumbo Frame Support
- 10KB
- Features
- Flow control, security lock slot (cable lock sold separately), 2 fans, priority mode, extend mode, Intelligent Power Management
- Compliant Standards
- IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 44 cm x 18 cm x 4.4 cm
Detailed Specification
General
- Device Type
- Switch - 16 ports - unmanaged
- Enclosure Type
- Rack-mountable
- Subtype
- Fast Ethernet
- Ports
- 16 x 10/100 (PoE+) + 2 x 10/100/1000 + 1 x combo Gigabit SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 150 W
- Performance
- Switching capacity: 7.2 Gbps , Packet forwarding rate: 5.36 Mpps
- MAC Address Table Size
- 8K entries
- Jumbo Frame Support
- 10KB
- Features
- Flow control, security lock slot (cable lock sold separately), 2 fans, priority mode, extend mode, Intelligent Power Management
- Compliant Standards
- IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
Expansion / Connectivity
- Interfaces
- 16 x 100Base-TX RJ-45 PoE+ - 30 W , 1 x 1000Base-T RJ-45 , 1 x 1000Base-T / 1000Base-X RJ-45/SFP
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 172.8 Watt
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- Plug and Play, FCC, RoHS
Dimensions & Weight
- Width
- 44 cm
- Depth
- 18 cm
- Height
- 4.4 cm
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 90% (non-condensing)
