Description
- Full Gigabit Ports: 16× gigabit RJ45 ports and 2× gigabit SFP Slots provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralised Cloud Management, and Intelligent Monitoring.
- Centralised Management: Cloud access and Omada app for ultra convenience and easy management.
- Static Routing: Helps route internal traffic for more efficient use of network resources.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
- Standalone Management: Web, CLI (Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities
-
Advanced L3 features
An abundance of L2+ and L3 features are supported to help build a highly scalable and robust network, providing a reliable and efficient solution for enterprises, campuses and ISPs. -
Secure networking
Security features include IP-MAC-Port-VID Binding, Port Security, Storm Control and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports or VLAN ID. Users' network access can be controlled via 802.1x authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided. -
Enterprise-level features
A complete lineup of L2+ features are supported, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling and filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing is a simple way of segmenting the network and internally routs traffic through the switch for improved efficiency. -
Advanced QoS
Voice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more. With QoS (Quality of Service), voice and video services remain smooth, even when bandwidth is in short supply. -
ISP features
sFlow, QinQ, L2PT PPPoE ID Insertion and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links. -
IPv6 support
IPv6 functions, such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discover, guarantee your network is ready for the Next Generation Network (NGN) without upgrading your hardware.
Specifications
Summary
- Product Description
- TP-Link JetStream TL-SG2218 - V1 - switch - 16 ports - smart - rack-mountable
- Device Type
- Switch - 16 ports - smart
- Enclosure Type
- Rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 16 x 10/100/1000 + 2 x SFP
- Performance
- Switching capacity: 36 Gbps , Forwarding rate: 26.78 Mpps
- MAC Address Table Size
- 8K entries
- Jumbo Frame Support
- 9KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, MLDv2, MLD
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, DHCP, IPv4, IPv6
- Features
- Flow control, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, store and forward, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, bandwidth control, DLDP support, NDP, CoS, SP, GVRP, Storm Control, BPDU, Link Aggregation, AAA, Voice VLAN, IPMB, ZTP, WRR, loopback detection, 4.1Mbit packet buffer, MLD, DSCP prioritisation
- Compliant Standards
- IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 44 cm x 18 cm x 4.4 cm
Detailed Specification
General
- Device Type
- Switch - 16 ports - smart
- Enclosure Type
- Rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 16 x 10/100/1000 + 2 x SFP
- Performance
- Switching capacity: 36 Gbps , Forwarding rate: 26.78 Mpps
- MAC Address Table Size
- 8K entries
- Jumbo Frame Support
- 9KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, MLDv2, MLD
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, DHCP, IPv4, IPv6
- Encryption Algorithm
- SSL, SSL 3.0, TLS 1.2
- Authentication Method
- Secure Shell (SSH), RADIUS, PAP, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP), EAP-TLS, EAP-TTLS
- Features
- Flow control, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, store and forward, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, bandwidth control, DLDP support, NDP, CoS, SP, GVRP, Storm Control, BPDU, Link Aggregation, AAA, Voice VLAN, IPMB, ZTP, WRR, loopback detection, 4.1Mbit packet buffer, MLD, DSCP prioritisation
- Compliant Standards
- IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az
- RAM
- 256 MB
- Flash Memory
- 32 MB
Expansion / Connectivity
- Interfaces
- 16 x 1000Base-T RJ-45 , 4 x Gigabit LAN SFP
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 15.9 Watt
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- FCC, RoHS
Dimensions & Weight
- Width
- 44 cm
- Depth
- 18 cm
- Height
- 4.4 cm
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 90% (non-condensing)
