Product

TP Link 16 Port GigaBit Switch

Review this product
Quicklinx: 77PQWS00 Mfr#: TL-SG1016
Type: Gigabit Ethernet
Ports: 16
Data Transfer Rate: 1Gbps
Managed: No
POE: No
More than 50 in stock
£54.86 ex VAT
£65.83 inc VAT
Qty
Standard delivery Delivered within 3-5 working days

Description

The TL-SG1016 is specially designed for Ethernet (10Mbps), Fast Ethernet (100Mbps) and Gigabit Ethernet (1000Mbps). It is the perfect choice to improve the performance of Offices and Workgroups networks.

  • TP-LINK Green Technology

    This generation TL-SG1016 Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.
  • High performance

    All 16 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1016 forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the tra­ffic congestion and make The TL-SG1016 work reliably. It's a perfect choice to update your network to Gigabit while protecting your previous investment properly.
  • Easy to use

    The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Specifications

Summary

Product Description
TP-Link TL-SG1016 - switch - 16 ports - rack-mountable
Device Type
Switch - 16 ports
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
16 x 10/100/1000
Features
Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Power
AC 120/230 V (50/60 Hz)
Dimensions (WxDxH)
44 cm x 18 cm x 4.4 cm


Detail

General

Device Type
Switch - 16 ports
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
16 x 10/100/1000
Features
Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Status Indicators
Power, 100M device connected, 1000M device connected, link/activity

Expansion / Connectivity

Interfaces
16 x 1000Base-T RJ-45

Power

Voltage Required
AC 120/230 V (50/60 Hz)

Dimensions & Weight

Width
44 cm
Depth
18 cm
Height
4.4 cm

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90%
