Description
RS819 is a compact and scalable 4-bay rackmount NAS in a 1U form factor. With snapshot technology support, RS819 brings business workgroups simple yet comprehensive solutions to data management, sharing, synchronization and backup.
-
Robust storage options
With support for RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, and JBOD, the Synology RackStation RS819 offers a range of storage configurations to meet diverse needs, ensuring data redundancy and performance optimization. -
Comprehensive network compatibility
Featuring Gigabit Ethernet connectivity and supporting a variety of network protocols including DNS, FTP, NFS, SMB, and iSCSI, the RS819 ensures seamless integration into any network environment, enhancing file sharing and accessibility. -
Advanced security features
Equipped with SSL and TLS encryption algorithms, alongside hardware encryption, firewall protection, and antivirus analysis, the RS819 provides a secure data storage solution, safeguarding sensitive information against unauthorized access. -
Versatile media and cloud support
The RS819 excels in media and cloud integration, offering support for DLNA Media Server, iTunes server, and various cloud storage services like Amazon S3, Google Drive, and Dropbox, enabling efficient data backup and sharing. -
High-definition surveillance capability
Supporting up to 30 IP cameras and featuring H.264, H.265, and MJPEG compression formats, the RS819 serves as a robust surveillance solution, providing high-quality video monitoring and recording capabilities.
Specifications
Summary
- Product Description
- Synology RackStation RS819 - NAS server
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet
- Enclosure Type
- Rack-mountable - 1U
- Max Supported Capacity
- 56 TB
- Installed Devices / Modules Qty
- 0 (installed) / 4 (max)
- Dimensions (WxDxH)
- 43.05 cm x 29.55 cm x 4.4 cm
- Weight
- 4.34 kg ()
- Processor
- 1 x Realtek Semiconductor RTD1296 1.4 GHz (Quad-Core)
- Storage Controller
- RAID SATA 6Gb/s RAID RAID 0, 1, 5, 6, 10, JBOD
- Networking
- 10Mb LAN, 100Mb LAN, 1GbE
- IP Cameras Supported
- 30
- RAM
- 2 GB
- Power
- AC 120/230 V (50/60 Hz)
- Storage Operating System
- Synology DiskStation Manager
- System Requirements
- Apple MacOS X 10.11 or later, Microsoft Windows 7 / 10
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet
- Enclosure Type
- Rack-mountable - 1U
- Total Storage Capacity
- 0 GB
- Max Supported Capacity
- 56 TB
- Installed Devices / Modules Qty
- 0 (installed) / 4 (max)
- Width
- 43.05 cm
- Depth
- 29.55 cm
- Height
- 4.4 cm
- Weight
- 4.34 kg ()
- Built-in Devices
- Led panel
Processor / Memory
- Processors Installed
- 1 x Realtek Semiconductor RTD1296 1.4 GHz
- Number of Cores
- Quad-Core
- Max Supported Qty
- 1
- RAM
- 2 GB DDR4
Storage Controller
- Type
- RAID
- Interface Type
- SATA 6Gb/s
- RAID Level
- RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Networking
- Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE
- Network / Transport Protocol
- PPTP, L2TP, IPSec, iSCSI, SMTP, FTP, DNS, POP3, IMAP, SMB, NFS, SFTP
- Remote Management Protocol
- SNMP, Telnet, HTTP, HTTPS, TFTP, SSH, SFTP, SMTP
- Network Services Compatibility
- Microsoft Active Directory (AD), DNS, File Level Security (ACLs), Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), SFTP
- Features
- Firewall protection, hardware encryption, LDAP support, wake on LAN (WOL), antivirus analysis, backup server, download client, POP3 e-mail server, file sharing, event log, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, SSH support, iTunes server, FTP server, reset button, bandwidth control, surveillance station, PXE support, DNS server, DLNA Media Server, Apple Time Machine compatible, VPN Server, Dropbox support, Link Aggregation, Google Drive support, failover protection, Amazon Cloud Drive support, Yandex Disk support, Microsoft OneDrive support, file station, hubiC support, OpenStack Swift-compatible, Baidu cloud support, cloud station server, Amazon S3 support, Alibaba Cloud OSS support, Backblaze B2 support, MegaDisk support
- Encryption Algorithm
- SSL, TLS
- Compliant Standards
- DLNA CERTIFIED
Security DVR
- IP Cameras Supported
- 30
- Compression Format
- MJPEG, H.264, H.265
- Image Resolution
- 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160
Expansion / Connectivity
- Expansion Bays
- 4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
- Interfaces
- 2 x Ethernet 1000Base-T - RJ-45 , 2 x USB 3.0 - Type A , 1 x eSATA , 1 x serial (management) - DB-9
Miscellaneous
- Features
- Audible alarm, wake on LAN, built-in 3 cooling fans, scheduled power on/off
- Compliant Standards
- VCCI, BSMI, CCC, FCC, RoHS, EAC, RCM
- Included Accessories
- Accessory pack
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Provided
- 150 Watt
Software / System Requirements
- Storage Operating System
- Synology DiskStation Manager
- OS Required
- Apple MacOS X 10.11 or later, Microsoft Windows 7 / 10
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Environmental Parameters
- Min Operating Temperature
- 5 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 5 - 95%
