StarTech.com Thunderbolt 3 Dock/USB-C Dock - Dual 4K DP/HDMI, 1x8K - 96W

StarTech.com Thunderbolt 3 Dock/USB-C Dock - Dual 4K DP/HDMI, 1x8K - 96W

Review this product
Quicklinx: G6JCWS00 Mfr#: TB3CDK2DHUE
More than 50 in stock
£247.34 ex VAT
£296.80 inc VAT
Qty
Standard delivery Delivered within 3 working days

Description

Dual DP 4K 60Hz or Dual HDMI 2.0 Monitors macOS & Windows | 5x USB 3.0 Ports 96W PD 0.8 m Cable. A high-performance Thunderbolt 3 Certified docking station with USB Type-C compatibility featuring dual monitor 4K 60Hz DSC support from either Dual or dual HDMI 2.0 video outputs, 96W Power Delivery (100W peak power), 5x USB 3.2 Hub with 2x BC 1.2 fast charging ports, gigabit Ethernet & headset ports.

Flexible Dual Display Outputs

This universal docking station features both dual DisplayPort 1.4 (Single 8K30 on HBR3 host) and dual HDMI video outputs that can be configured in three different ways:

DisplayPort + DisplayPort

HDMI + HDMI

DisplayPort + HDMI

Resolutions and video outputs are host-dependent.

Host Output

DCS Status

Single Video

Dual Video

Thunderbolt with DP 1.4 (nVidia Graphics)

Off

8K (7680 x 4320) @ 30Hz (DP Only)

n/a

Thunderbolt with DP 1.4 (nVidia Graphics)

Off

n/a

2x 4K (3840x2160) @60Hz

Thunderbolt with DP 1.4 (nVidia Graphics)

On

4K (3840x2160) @144Hz

n/a

Thunderbolt with DP 1.4 (nVidia Graphics)

On

n/a

2x 4K (3840x2160) @60Hz

Thunderbolt with DP 1.4 (Intel Graphics)

n/a

5K (5120x2880) @60Hz (DP Only)

n/a

Thunderbolt with DP 1.4 (Intel Graphics)

n/a

n/a

2x 4K (3840x2160) @60Hz

Thunderbolt with DP 1.2

n/a

4K (3840x2160) @60Hz

n/a

Thunderbolt with DP 1.2

n/a

n/a

2x 4K (3840x2160) @60Hz

USB Type-C DP Alternate Mode DP 1.4

Off

4K (3840x2160) @30Hz

n/a

USB Type-C DP Alternate Mode DP 1.4

Off

n/a

2x QHD (2560x1440)

USB Type-C DP Alternate Mode DP 1.4

On

5K (5120x2880) @60Hz (DP Only)

n/a

USB Type-C DP Alternate Mode DP 1.4

On

n/a

2x 4K (3840x2160) @60Hz

USB Type-C DP Alternate Mode DP 1.2

n/a

4K (3840x2160) @30Hz

n/a

USB Type-C DP Alternate Mode DP 1.2

n/a

n/a

2x 1080p (1920x1080) @ 60Hz

More Downstream USB Ports

Featuring an integrated USB 3.2 hub, this docking station has 5 downstream USB ports:

Front Facing:

1x USB 3.2 Gen 2 Type-C (10 Gbps) with 15W (3A, 5V) Charging

1x USB 3.2 Gen 2 Type-A (10 Gbps) with B.C. 1.2 Fast-Charging

Back Facing:

2x USB 3.2 Gen 1 Type-A (5 Gbps)

1x USB 3.2 Gen 2 Type-C (10 Gbps)

Easy to Set Up & Manage

This universal Thunderbolt 3 / USB-C Dock has an automatic driver setup and includes a longer 0.8 meter (2.6 ft) Thunderbolt 3 host cable, front-facing TB3/USB-C host port, front-facing LED indicator, mounting holes for the optional bracket, k-slot for security lock & MAC address changer utility.

Connected Device Transparency with the StarTech.com MAC Address Changer Utility

The TB3CDK2DHUE includes a free Windows application that enables you to better manage your enterprise network security. When you connect to your network through the ethernet port of the dock, the computer's MAC address is typically not broadcast to the network, as your network only sees the MAC address of the docking station. However, the StarTech.com MAC Address Changer or Cloning software enables the USB-C dock to use MAC address spoofing of the connected Windows laptop rather than the MAC address of the dock itself. This ensures your network administrators have full visibility of each device on the network and can monitor and limit activity accordingly. To request access to our MAC Address Changer utility, please contact our Technical Support Department by phone, live chat, or e-mail.

TB3CDK2DHUE is backed by a StarTech.com three-year warranty and free lifetime technical support.

  • Full function dock

    Thunderbolt 3 docking station with USB-C compatibility features dual monitor 4K 60Hz, 96W PD, 5x USB Hub (incl 2x BC 1.2 charging ports) with 3x USB-A (1x 10Gbps USB 3.2/3.1 Gen 2) & 2x USB-C 10Gbps; Gigabit Ethernet, headset ports.
  • 96W certified power delivery

    Thunderbolt 3 / USB Type-C Dock can deliver up to 100W peak power (96W sustained) and charge high performance laptops, Ultrabooks & workstation laptop computers such as MacBook Pro 16, HP, Lenovo ThinkPad & Dell XPS.
  • Flexible monitor outputs

    Thunderbolt 3 docking station features dual DisplayPort 1.4 with DSC (single 8K 30Hz) or dual HDMI 2.0 video outputs with options for dual DP, dual HDMI or DP + HDMI displays at dual 4K 60Hz on both TB3 & USB-C (non TB3) laptops.
  • Easy to use

    Universal Thunderbolt 3/USB-C dock with automatic drivers; incl. 2.6 ft (0.8m) Thunderbolt 3 host cable, mounting holes for optional bracket, k-slot for security lock & MAC address changer utility.

Specifications

Summary

Product Description
StarTech.com Thunderbolt 3 Dock with USB-C Host Compatibility, Dual 4K 60Hz DisplayPort 1.4 or Dual HDMI 2.0 Monitors, Single 8K, TB3/USB-C Laptop Docking Station, 96W PD, 5x USB, 10Gbps - 96W Power Delivery (TB3CDK2DHUE) - docking station - USB-C 3.2 Gen 2 / Thunderbolt 3 - 2 x HDMI, 2 x DP - GigE
Product Type
Docking station
Docking Interface
USB-C 3.2 Gen 2 / Thunderbolt 3
Video Interfaces
2 x HDMI, 2 x DP
Dimensions (WxDxH)
22 cm x 8 cm x 3 cm
Weight
250 g
Networking
Gigabit Ethernet
Power
Power adapter AC 120/230 V
Manufacturer Warranty
3-year warranty


Detailed Specification

General

Product Type
Docking station
Width
22 cm
Depth
8 cm
Height
3 cm
Weight
250 g

Video

Max Resolution Details
7680 x 4320 - 30 Hz , 3840 x 2160 - 60 Hz (Dual Display) , 3840 x 2160 - 144 Hz (DisplayPort 1.4 only) , 5120 x 2880 - 60 Hz (DisplayPort 1.4 only) , 3840 x 2160 - 60 Hz (DisplayPort 1.4 over USB-C) , 5120 x 2880 - 60 Hz (DisplayPort 1.4 over USB-C) , 3840 x 2160 - 30 Hz (DisplayPort 1.2 over USB-C) , 2560 x 1440 (Dual Display)

Networking

Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Compliant Standards
USB 3.0, USB 3.2 Gen 2, USB 3.2 Gen 1, Battery Charging 1.2

Expansion / Connectivity

Interfaces
1 x USB-C 3.2 Gen 2 / Thunderbolt 3 with Power Delivery 100W (96W sustained) - 24 pin USB-C , 2 x display / video - DisplayPort - 20 pin DisplayPort , 2 x display / video - HDMI - 19 pin HDMI Type A , 1 x audio - headphones/microphone - mini-phone stereo 3.5 mm , 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 , 1 x USB 3.2 Gen 2 with Fast Charging - 9 pin USB Type A , 2 x USB 3.2 Gen 1 - 9 pin USB Type A , 1 x USB-C 3.2 Gen 2 with Fast Charging - 24 pin USB-C , 1 x USB-C 3.2 Gen 2 - 24 pin USB-C

Miscellaneous

Cables Included
1 x Thunderbolt 3 / USB-C cable - external - 80 cm
Features
Security lock slot (cable lock sold separately), 96W power delivery
Security Slot Type
Kensington security slot
Compliant Standards
FCC, RoHS, DisplayPort 1.4, DSC

Power

Power Device
Power adapter
Voltage Required
AC 120/230 V

System Requirements

OS Required
Windows 8, Windows 10, Apple macOS Mojave 10.14, Ubuntu 18.04, Apple macOS Catalina 10.15, Apple macOS Big Sur 11.0, Ubuntu 20.04

Manufacturer Warranty

Service & Support
Limited warranty - 3 years

Dimensions & Weight (Shipping)

Shipping Width
30.5 cm
Shipping Depth
16 cm
Shipping Height
11 cm
Shipping Weight
1.1 kg

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
