StarTech.com Industrial Fiber to Ethernet Media Converter 1Gbps SFP to RJ

Review this product
Quicklinx: G3QMWS00 Mfr#: IMC1GSFP
Less than 10 in stock
£164.62 ex VAT
£197.54 inc VAT
Qty
Standard delivery Delivered within 3 working days

Description

An industrial media converter that converts fiber to copper at a network endpoint.

  • A flexible solution covering different requirements

    This media converter features an open SFP slot for any standard gigabit SFP to be used for the incoming fiber connection and is easily deployed across applications or fiber cable types. Accepts terminal block power or coaxial power connectors with the barrel plug adapter, allowing the product to be hardwired or powered using an external power supply (not included), which does not require professional installation. It can be powered using 12V-56V DC for solar, automotive, rail, and other applications and requires a minimum 12V power input. Includes hardware for DIN rail or wall mounting.
  • For mission-critical applications

    Designed with IP-30 housing and has an MBTF of >500,000 hrs (Telcordia/Bellcore) at 50°C and an operating temperature range of include -40 C to 75 C for durability; it's rated to various vibration, shock, and free-fall standards.

Specifications

Summary

Product Description
StarTech.com Industrial Fiber to Ethernet Media Converter - 1Gbps SFP to RJ45/ Cat6 - Singlemode/Multimode Optical Fiber to Copper Gigabit Network - 12-56V DC - IP-30/ -40 to +75C - fibre media converter - 10Mb LAN, 100Mb LAN, GigE
Device Type
Fibre media converter - RJ-45 / SFP (mini-GBIC)
Form Factor
DIN rail mountable
Cabling Type
1000Base-SX, 1000Base-T
Data Transfer Rate
1 Gbps
Data Link Protocol
10Mb LAN, 100Mb LAN, GigE
Dimensions (WxDxH)
8.15 cm x 10.4 cm x 3.2 cm
Weight
144 g
Manufacturer Warranty
2-year warranty


Detailed Specification

General

Device Type
Fibre media converter
Form Factor
DIN rail mountable
Colour
Black

Networking

Connectivity Technology
Wired
Cabling Type
1000Base-SX, 1000Base-T
Data Link Protocol
10Mb LAN, 100Mb LAN, GigE
Data Transfer Rate
1 Gbps
Status Indicators
Port status, active, link
Features
Flow control, auto-uplink (auto MDI/MDI-X), full duplex mode, 2KV Surge protection, 9 KB Jumbo Frame
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3x

Expansion / Connectivity

Interfaces
1 x Ethernet 1000Base-T - RJ-45 female , 1 x Ethernet 1000Base-SX - SFP female

Miscellaneous

Included Accessories
Power terminal block
Mounting Kit
Included
MTBF
569,265 hours
Compliant Standards
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, FCC, RoHS, EN 60950-1, WEEE, MSA, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6

Power

Power Device
External power adapter

Dimensions & Weight

Width
8.15 cm
Depth
10.4 cm
Height
3.2 cm
Weight
144 g

Dimensions & Weight (Shipping)

Shipping Width
21.1 cm
Shipping Depth
16.2 cm
Shipping Height
6.4 cm
Shipping Weight
400 g

Manufacturer Warranty

Service & Support
Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Humidity Range Operating
5 - 95% (non-condensing)
