Description
This industrial 5-port gigabit PoE switch (4-port PoE) features 30W of power and is designed to be installed in harsh environments and supports up to a total of 120W power outputs.
Specifications
Summary
- Product Description
- StarTech.com Industrial 5 Port Gigabit PoE Switch, 30W, Power Over Ethernet Switch, Hardened GbE PoE+ Unmanaged Switch, Rugged High Power Gigabit Network Switch IP-30 Housing/-40 C to 75 C - Gigabit Ethernet PoE (IESC1G50UP) - switch - 5 ports - unmanaged
- Device Type
- Switch - 5 ports - unmanaged
- Subtype
- Gigabit Ethernet
- Ports
- 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 120 W
- Jumbo Frame Support
- 9KB
- Features
- Flow control, full duplex mode, rugged, 2KV ESD Protector, Back Pressure Support, MDI-X
- Compliant Standards
- IEEE 802.3, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
- Power
- DC 48 - 56 V
- Dimensions (WxDxH)
- 8.15 cm x 10.4 cm x 3.2 cm
- Weight
- 150.6 g
- Colour
- Black
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- Switch - 5 ports - unmanaged
- Enclosure Type
- DIN rail mountable, wall-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 120 W
- Jumbo Frame Support
- 9KB
- Features
- Flow control, full duplex mode, rugged, 2KV ESD Protector, Back Pressure Support, MDI-X
- Compliant Standards
- IEEE 802.3, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
- Status Indicators
- Power, PoE, link
Expansion / Connectivity
- Interfaces
- 4 x 1000Base-T RJ-45 PoE+ - 30 W , 1 x 1000Base-T RJ-45 , 1 x terminal block
Power
- Voltage Required
- DC 48 - 56 V
- Power Consumption Operational
- 126 Watt
Miscellaneous
- Colour
- Black
- Included Accessories
- Terminal block connector, mounting kit
- MTBF
- 538451 hours
- Compliant Standards
- IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, FCC, RoHS, UL 60950-1, EN 60950-1, WEEE, MSA, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6
Dimensions & Weight
- Width
- 8.15 cm
- Depth
- 10.4 cm
- Height
- 3.2 cm
- Weight
- 150.6 g
Dimensions & Weight (Shipping)
- Shipping Width
- 21.1 cm
- Shipping Depth
- 16.2 cm
- Shipping Height
- 6.4 cm
- Shipping Weight
- 392.6 g
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- -40 °C
- Max Operating Temperature
- 75 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 85 °C
