StarTech.com HDMI USB Over HDBaseT Extender

Review this product
Quicklinx: C9JKWS00 Mfr#: ST121HDBTU
Ordered upon request
£497.64 ex VAT
£597.16 inc VAT
Qty
Standard delivery Product out of stock. Due date unavailable.

Description

Extend Ultra HD 4K video, an IR signal and four USB devices to a remote location, with power over cable. This HDMI extender kit uses HDBaseT 2.0 technology, enabling you to extend 4K HDMI video and four USB 2.0 peripheral devices to a remote location up to 295 feet (90 meters) away, using a single CAT5e or CAT6 cable. The extender can extend 1080p (HD) video even further at up to 330 feet (100 meters).

You can power both the transmitter and receiver using the same single power source, which you can connect to either the extender or receiver using Power Over Cable (POC). You can also connect up to four USB devices on the remote side and support 3D video and 7.1 digital audio. The versatility of this video extender makes it the perfect solution for digital signage applications in large buildings such as commercial shopping centers, stadiums, schools, and hospitals.

HDBaseT is a standardized, zero-latency video technology that's revolutionizing HDMI distribution. HDBaseT uses an advanced method of modulation that enables you to distribute uncompressed HDMI audio and video along with additional signals such as USB and power over cable.

The extender offers a complete end-to-end solution, using HDBaseT technology to extend HDMI, IR, power and USB over a single CAT5 cable. With power and USB along with your video signal, HDBaseT is the clear choice for every integrator and system designer. The added benefit of power over cable means that you'll only need one power source at one side of your extension, and USB lets you add a console at the remote location - great for extending video and control to areas where power outlets may be limited, such as industrial sites.

The A/V industry is quickly adopting 4K as the new high-resolution video standard. But long-range video distribution can be a challenge if you're using standard HDMI cables because the signal becomes susceptible to degradation at 30 feet. HDBaseT maintains your Ultra HD 4K picture quality - four times the resolution of high-definition 1080p - even at 330 feet away from your video source. Plus, because the extender supports high-definition 1080p and lower resolutions, you can comfortably use this extender to make any video source look great, while future proofing your setup for 4K implementation.

This extender has been specifically designed for a simple and tidy installation. HDBaseT technology offers single-cable installation, so you can integrate it seamlessly using your existing CAT5e or CAT6 infrastructure. This means that you can avoid the hassle of running multiple Ethernet cables, while reducing potential failure points.

The extender also features Power-over-Cable technology, so you only need one power source for both the extender and receiver units. Mounting hardware is included for both the extender and receiver, for discreet, professional installation.

Specifications

Summary

Product Description
StarTech.com HDMI over CAT5e / CAT6 HDBaseT Extender with 4-port USB Hub, IR and Power over Cable - 295 ft (90m) - Ultra HD 4K (ST121HDBTU) - video/audio/infrared/USB extender
Device Type
Video/audio/infrared/USB extender
Form Factor
External
Transmission Medium
CAT 5e/6
Max Transfer Distance
100 m
Power
AC 120/230 V
Manufacturer Warranty
2-year warranty


Detailed Specification

General

Device Type
Video/audio/infrared/USB extender
Form Factor
External
Built-in Devices
USB Hub

Networking

Connectivity Technology
Wired
Max Resolution
4096 x 2160
Max Transfer Distance
100 m
Features
7.1 channel audio support

Expansion / Connectivity

Interfaces
1 x HDMI (input) - 19 pin HDMI Type A female , 1 x mini-USB 2.0 - Type B female , 1 x Ethernet (input) - RJ-45 female , 1 x HDMI (output) - 19 pin HDMI Type A , 4 x USB 2.0 - Type A female , 2 x IrDA (input) - mini jack , 2 x IrDA (output) - mini jack female , 1 x audio (input) - mini jack female , 1 x audio (output) - mini jack female

Miscellaneous

Included Accessories
IR receiver, IR transmitter, 2 x foot pad sets
Cables Included
1 x USB cable
Mounting Kit
Included
Compliant Standards
FCC, RoHS

Power

Power Device
External power adapter
Voltage Required
AC 120/230 V

Manufacturer Warranty

Service & Support
Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 80% (non-condensing)
