Description
Convert and extend a Gigabit Ethernet connection up to 10 km (6.2 mi) using single-mode LC fiber cable. This Gigabit Ethernet to fiber media converter is a cost-effective way to extend your network, or extend the distance between two devices by up to 10 km (6.2 mi.).
Fiber network connections provide greater distance and security, with less electromagnetic interference (EMI) than typical RJ45 copper-based networks, making it perfect for IT professionals and secure setups in government, business, or educational applications.
This versatile copper-to-fiber converter supports standalone operation, or alternatively it can be installed into the StarTech.com ETCHS2U Rackmount Chassis (ETCHS2U - sold separately), giving you more options for integration into your existing network. The card module can also be inserted back into the ET91000SM10 enclosure, plus it's compatible with enclosures from other StarTech.com ET91000 series media converters (sold separately).
The converter features a pre-installed Gigabit SFP transceiver with LC connectors. Should your network infrastructure change in the future, you can easily swap and replace the module to adapt the media converter to your new network requirements.
With flexible integration and connectivity up to 10 km away, you can provide network access to remote areas in other buildings, or in areas where Wi-Fi is unreliable or unavailable.
This heavy-duty fiber media converter is designed for maximum reliability. It features a metal (steel) enclosure, so it can withstand the demands of harsh environments such as factories or warehouses.
Plus, by relying on this more durable fiber media converter, you can reduce the strain on your existing copper-based network equipment and potentially extend the life of those devices, which helps save future expenses.
This high-performance media converter supports a range of network setup and diagnostic protocols (for example, Link Fault Passthrough, Auto Laser Shutdown (ALS), and Auto MDIX, so you can set up and troubleshoot your network easily.
If your existing network consists of RJ45 copper-based devices and cables, you might not be ready for future network expansion. Because the newest fiber-based network switches feature SFP ports more often than RJ45 ports, you might need a converter to bridge your copper and fiber networks together.
-
Flexible integration into mixed network environments
This versatile copper-to-fiber converter supports standalone operation. The card module can also be inserted back into the ET91000SM10 enclosure, plus it's compatible with enclosures from other StarTech.com ET91000 series media converters (sold separately). The converter features a pre-installed Gigabit SFP transceiver with LC connectors. Should your network infrastructure change in the future, you can easily swap and replace the module to adapt the media converter to your new network requirements. With flexible integration and connectivity up to 10 km away, you can provide network access to remote areas in other buildings, or in areas where Wi-Fi is unreliable or unavailable. -
Rugged and reliable
This heavy-duty fiber media converter is designed for maximum reliability. It features a metal (steel) enclosure, so it can withstand the demands of harsh environments such as factories or warehouses. Plus, by relying on this more durable fiber media converter, you can reduce the strain on your existing copper-based network equipment and potentially extend the life of those devices, which helps save future expenses. -
Diagnose and correct issues easily
This high-performance media converter supports a range of network setup and diagnostic protocols (for example, Link Fault Passthrough, Auto Laser Shutdown (ALS), and Auto MDIX, so you can set up and troubleshoot your network easily. -
Prepare your network for the future
If your existing network consists of RJ45 copper-based devices and cables, you might not be ready for future network expansion. Because the newest fiber-based network switches feature SFP ports more often than RJ45 ports, you might need a converter to bridge your copper and fiber networks together. The ET91000SM10 is backed by a StarTech.com 2-year warranty, and free lifetime technical support.
Specifications
Summary
- Product Description
- StarTech.com Singlemode (SM) LC Fiber Media Converter for 1Gbe Network - 10km - Gigabit Ethernet - 1310nm - with SFP Transceiver (ET91000SM10) - fibre media converter - 10Mb LAN, 100Mb LAN, 1GbE
- Device Type
- Fibre media converter - RJ-45 / LC single-mode
- Form Factor
- External
- Localisation
- Australia, North America, United Kingdom, Europe
- Cabling Type
- 100Base-LX, 1000Base-T
- Data Transfer Rate
- 2 Gbps
- Optical Wave Length
- 1310 nm
- Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE
- Max Transfer Distance
- 10 km
- Power
- AC 120/230 V
- Dimensions (WxDxH)
- 8.8 cm x 15.9 cm x 2.3 cm
- Weight
- 410 g
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: SVA12M2NEUA, SVA12M5NA
Detailed Specification
General
- Device Type
- Fibre media converter
- Form Factor
- External
- Built-in Devices
- SFP Module
- Localisation
- Australia, North America, United Kingdom, Europe
Networking
- Connectivity Technology
- Wired
- Cabling Type
- 100Base-LX, 1000Base-T
- Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE
- Data Transfer Rate
- 2 Gbps
- Optical Wave Length
- 1310 nm
- Max Transfer Distance
- 10 km
- Status Indicators
- Power, link/activity
- Features
- Auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, Jumbo Frames support
- Compliant Standards
- IEEE 802.3z, IEEE 802.3ab
Expansion / Connectivity
- Interfaces
- 1 x Ethernet 1000Base-T - RJ-45 female , 1 x Ethernet 1000Base-LX - LC single-mode female x 2
Miscellaneous
- Compliant Standards
- FCC, RoHS, MSA
Power
- Power Device
- External power adapter
- Voltage Required
- AC 120/230 V
- Power Consumption Operational
- 19.2 Watt
Dimensions & Weight
- Width
- 8.8 cm
- Depth
- 15.9 cm
- Height
- 2.3 cm
- Weight
- 410 g
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
Compatibility Information
- Designed For
- P/N: SVA12M2NEUA, SVA12M5NA
