StarTech.com 4-Port USB 2.0 Extender Hub
-
Hi-Speed USB Performance
With data bandwidth of up to 480Mbps and no software installation required, the USB extender over Cat5e, Cat6, or Cat7 network cabling offers a fast, easy, and versatile solution for business or commercial applications with durable metal housing, an included surface-mounting bracket kit and simple plug-and-play installation. Plus, the 330 ft. (100 m) USB extender provides up to the full 500 mA of power (with the use of an external power adapter at the remote end) allowing for greater compatibility with bus-powered USB devices. -
Compatible with USB 2.0/1.1/1.0 Devices
Connecting low-speed peripherals or HID devices isn't a problem. This versatile USB over network extender is backward compatible with legacy USB 1.0/1.1 devices, so you can access up to four different types of USB devices from your remote location, far away from the host computer. -
The Choice of IT Pros Since 1985
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales USB2004EXT100 is backed by a StarTech.com 2-year warranty and free lifetime 24/5 North American based, multi-lingual support.
Specifications
Summary
- Product Description
- StarTech.com 4 Port USB 2.0 Extender Hub over Single CAT5e/CAT6 Ethernet Cable (RJ45), 330ft (100m), USB Extender Adapter, Externally Powered, 480 Mbps, Metal USB Extender Kit - Power/Link LEDs (USB2004EXT100) - USB extender - USB 2.0
- Device Type
- USB extender
- Form Factor
- External
- Localisation
- Australia, Japan, New Zealand, North America, United Kingdom, Europe
- Data Transfer Rate
- 480 Mbps
- Data Link Protocol
- USB 2.0
- Transmission Medium
- CAT 5e/6
- Max Transfer Distance
- 100 m
- Power
- AC 100-240 V
- Dimensions (WxDxH)
- 6 cm x 10 cm x 2.2 cm
- Weight
- 143 g
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- USB extender
- Form Factor
- External
- Colour
- Black
- Localisation
- Australia, Japan, New Zealand, North America, United Kingdom, Europe
Networking
- Connectivity Technology
- Wired
- Data Link Protocol
- USB 2.0
- Data Transfer Rate
- 480 Mbps
- Max Transfer Distance
- 100 m
- Status Indicators
- Status
- Features
- Rugged
- Compliant Standards
- USB 2.0
Expansion / Connectivity
- Interfaces
- 4 x USB 2.0 - Type A , 1 x USB 2.0 - Type B
Miscellaneous
- Included Accessories
- 4 rubber feet
- Cables Included
- 2 x mini-USB to USB cable - 1.5 m , 1 x network cable - 1.5 m
- Compliant Standards
- Plug and Play, FCC, RoHS, WEEE
Power
- Power Device
- External power adapter
- Installed Qty
- 1
- Voltage Required
- AC 100-240 V
- Power Consumption Operational
- 10 Watt
Dimensions & Weight
- Width
- 6 cm
- Depth
- 10 cm
- Height
- 2.2 cm
- Weight
- 143 g
Dimensions & Weight (Shipping)
- Shipping Width
- 23.5 cm
- Shipping Depth
- 15.3 cm
- Shipping Height
- 6.5 cm
- Shipping Weight
- 716 g
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 80% RH
