Description
Add 2 high-speed IEEE 1284 parallel ports (EPP/ECP/SPP/PS2) to your desktop computer through a PCI Express expansion slot. The PEX2PECP2 2 Port PCI Express Parallel Adapter Card - EPP/ECP/SPP/PS2 parallel card adds two IEEE 1284 parallel ports to your PC, with support for parallel data communication at speeds of up to 1.5 Mbps.
This high performance 2 Port PCI Express parallel card adds 2 DB25 parallel ports, perfect for connecting printers, scanners, memory card readers, bar code scanners and more. With the added convenience of plug-and-play capability, installing the parallel adapter card is hassle-free. The PCIe Parallel card also includes both standard and half-height/low profile mounting brackets for compatibility with almost any system form factor.
Specifications
Summary
- Product Description
- StarTech.com 2 Port PCI Express / PCI-e Parallel Adapter Card - IEEE 1284 with LP Bracket - 2x DB25 (F) PCIE Parallel Port Card (PEX2PECP2) - parallel adapter - PCIe - IEEE 1284 x 2
- Device Type
- Parallel adapter
- Form Factor
- Plug-in card
- Interface (Bus) Type
- PCI Express x1
- Ports
- IEEE 1284 x 2
- Dimensions (WxDxH)
- 1.9 cm x 12.1 cm x 6.7 cm
- Weight
- 60 g
- Data Link Protocol
- Parallel
- Data Transfer Rate
- 1.5 Mbps
- System Requirements
- Linux, Microsoft Windows 2000, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits), Windows 10 (32/64 bits)
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Parallel adapter
- Form Factor
- Plug-in card
- Interface (Bus) Type
- PCI Express x1
Networking
- Ports
- IEEE 1284 x 2
- Connectivity Technology
- Wired
- Data Link Protocol
- Parallel
- Data Transfer Rate
- 1.5 Mbps
Expansion / Connectivity
- Interfaces
- 2 x IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25)
- Compatible Slots
- 1 x PCI Express x1
Miscellaneous
- Included Accessories
- Low-profile bracket
- Compliant Standards
- FCC, RoHS
Software / System Requirements
- Software Included
- Drivers & Utilities
- OS Required
- Linux, Microsoft Windows 2000, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits), Windows 10 (32/64 bits)
Dimensions & Weight
- Width
- 1.9 cm
- Depth
- 12.1 cm
- Height
- 6.7 cm
- Weight
- 60 g
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 5 - 85% (non-condensing)
