High performance
VESA certified DisplayPort 1.4 cable; 8K 60Hz, 4K 120Hz, 32.4Gbps bandwidth, HDR10, 32Ch audio, MST, GTC for precise audio channel timing; future-proof your equipment by making it 8K ready. -
Reliable
28 AWG video cable built with internal wire manager to ensure signal integrity; metal connector sub-structure & Al-Mylar Foil w/Braid for superior EMI shielding; Gold-plated latching DP connectors prevent accidental disconnection, -
Durable
Tested to withstand 5000+ insertions and 300+ bend cycles at 120° angle; long lasting TPE jacket w/ molded Soft TPE strain relief absorbs stress of frequent bends; TPE is non-toxic, halogen free & RoHS certified for environmental sustainability.
Specifications
Summary
- Product Description
- StarTech.com 16ft (5m) VESA Certified DisplayPort 1.4 Cable, 8K 60Hz HDR10, Ultra HD 4K 120Hz DP Video Cable, DisplayPort to DisplayPort Cable, DP Cord for Monitors/Displays, M/M - DP 1.4 Cable with Latches (DP14VMM5M) - DisplayPort cable - DisplayPort to DisplayPort - 5 m
- Type
- DisplayPort cable
- Technology
- Shielded
- Features
- Molded, passive cable, 8K60Hz (7680 x 4320) support, 4K120Hz (3840 x 2160) support, strain relief, HBR3 support, Display Stream Compression 1.2 (DSC), DisplayPort Multi-Stream Transport (MST), 32 audio channels, HDR10 support, 7.1 audio channel support, Chroma subsampling (4:4:4), 32.4 Gbps data rate, Forward Error Correction, 5.1 audio channel support
- Length
- 5 m
- Connector
- 20 pin DisplayPort - male
- Connector (Second End)
- 20 pin DisplayPort - male
- Compliant Standards
- DisplayPort 1.4
- Colour
- Grey, black
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Type
- DisplayPort cable
- Technology
- Shielded
- Shielding Material
- Aluminum mylar foil with braid
- Jacket Material
- Thermoplastic elastomer (TPE)
- American Wire Gauge (AWG)
- 28
- Plated Connector
- Gold
- Features
- Molded, passive cable, 8K60Hz (7680 x 4320) support, 4K120Hz (3840 x 2160) support, strain relief, HBR3 support, Display Stream Compression 1.2 (DSC), DisplayPort Multi-Stream Transport (MST), 32 audio channels, HDR10 support, 7.1 audio channel support, Chroma subsampling (4:4:4), 32.4 Gbps data rate, Forward Error Correction, 5.1 audio channel support
- Length
- 5 m
- Outside Diameter
- 7.5 mm
- Colour
- Grey, black
Connectivity
- Connector
- 20 pin DisplayPort - male
- Connector (Second End)
- 20 pin DisplayPort - male
Miscellaneous
- Compliant Standards
- DisplayPort 1.4, RoHS, HDCP 2.2, 8K VESA certified
Dimensions & Weight (Shipping)
- Shipping Width
- 33 cm
- Shipping Depth
- 25.5 cm
- Shipping Height
- 2 cm
- Shipping Weight
- 405 g
- Service & Support
- Limited lifetime warranty
