Description
The PN-V601A ultra thin bezel model is mainly designed for video wall applications. This 152 cm (60") LCD-monitor can be used in a variety of signage and multi screen configurations. As a flexible solution with an almost seamless bezel, the PN-V601A sets a new standard for video wall displays.
-
Enlarge display mode
The Enlarge Display mode can spread one image across up to 25 monitors from a PC. The Frame Width Adjustment function virtually eliminates misalignment and boldly enhances the enlarged image on a multi-screen display. -
Full-array LED backlight
To give the PN-V601A more uniform brightness than conventional CCFL backlighting can offer, Sharp has positioned LED elements across the entire panel directly behind the liquid crystal layers, helping ensure that Sharp multi-screen displays are bright, beautiful and uniform. -
Professional quality and 24/7 durability
Because business never stops, neither do the PN-V601A video wall monitors. These professional-grade products are rugged enough for continuous 24/7 operation in the most demanding professional applications. -
Full range of connectivity
The PN-V601A feature extensive interface capability. -
Create a 4K2K ultra-high resolution experience
When placed in a 3x3 video wall configuration, the PN-V601A standard resolution multiplies by three, creating a total resolution of up to 4098 x 2304 pixels for ultra-high resolution/ultra-high impact images.
Specifications
Summary
- Product Description
- Sharp PN-V601A PN-V Series - 60" LED-backlit LCD display - HD - for digital signage
- Product Type
- LED-backlit LCD flat panel display
- Diagonal Class
- 60"
- Commercial Use
- Yes - digital signage
- Resolution
- 1366 x 768
- Display Format
- 720p
- Max Number of Screens
- 25
- Video Interface
- HDMI
- HDMI Ports Qty
- 1 ports
- PC Interface
- VGA (HD-15)
- HDCP Compatible
- Yes
- LCD Backlight Technology
- Direct-lit LED
- Image Aspect Ratio
- 16:9
- TV Tuner
- No tuner
- Voltage
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 480 Watt
- Dimensions (WxDxH) - without stand
- 133.59 cm x 14.93 cm x 75.42 cm
- Weight
- 45 kg
Detailed Specification
General
- Product Type
- LED-backlit LCD flat panel display
- Power Consumption Operational
- 480 Watt
- Diagonal Class
- 60"
- Commercial Use
- Yes - digital signage
- Series
- PN-V Series
- TV Tuner
- No tuner
- TV Tuner Presence
- No
- Sensors
- Brightness sensor
- Video Interface
- HDMI
- HDMI Ports Qty
- 1 ports
- PC Interface
- VGA (HD-15)
- HDCP Compatible
- Yes
- Modes
- Portrait mode, landscape mode, Mirror Display Mode
- Dimensions
- Without stand
- Width
- 133.59 cm
- Depth
- 14.93 cm
- Height
- 75.42 cm
- Weight
- 45 kg
Display
- Resolution
- 1366 x 768
- Display Format
- 720p
- Image Aspect Ratio
- 16:9
- LCD Backlight Technology
- Direct-lit LED
- Colour Depth
- 16.7 million colours
- Image Contrast Ratio
- 4000:1
- Brightness
- 700 cd/m²
- Viewing Angle
- 176 degrees
- Viewing Angle (Vertical)
- 176 degrees
- Response Time
- 6 ms
- Features
- Certified for 24/7 Continuous Operation, Hardware Diagnostics, Bezel Correction
Video Wall
- Max Number of Screens
- 25
Stands & Mounts
- Flat Panel Mount Interface
- 200 x 200 mm
Connections
- Connector Type
- HDMI input - rear , VGA input - rear , Audio line-in - rear , Audio line-out - rear , Serial input - rear , Serial output - rear , Remote control - rear
Miscellaneous
- Compliant Standards
- Plug and Play
Power
- Power Device
- Power supply
- Input Voltage
- AC 120/230 V (50/60 Hz)
- On / Off Switch
- Yes
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 20 - 80%
