Description
Get maximum performance from your PowerEdge servers with QLogic 57810 dual-port 10 GbE KR blade converged mezzanine cards. Each QLogic 57810 offers massive bandwidth through two 10 GbE ports and is supported by the established performance of the QLogic architecture and software stack.
-
Extensive bandwidth
Provides two ports of 10 Gigabit Ethernet (10 GbE) with full 10 GbE line-rate performance per port. -
Fast, reliable performance
Keeps data moving with hardware offload for network (TOE) and storage traffic while offering support for data center bridging (DCB). -
Customizable configurations
Supports fabric-independent NIC partitioning (NPAR), which helps to improve resource utilization and deployment flexibility. -
Easy integration
Developed to the IEEE standards and offering PCI hot plug/hot swap capability, the Broadcom 57810 fits easily into your virtualized or workload-intensive PowerEdge server environment. -
Improved management efficiency
Reach new levels of speed and convenience through remote access to Dell's Lifecycle Controller management framework. -
Advanced capabilities
Bring scalable performance and flexible provisioning to your data center through high-performance hardware offload (iSCSI and FCoE-ready) and switch-independent NIC partitioning (NPAR) capabilities.
Specifications
Summary
- Product Description
- QLogic 57810 - network adapter - 10Gb Ethernet x 2
- Device Type
- Network adapter
- Form Factor
- Plug-in card - low profile
- Ports
- 10Gb Ethernet x 2
- Data Link Protocol
- 10GbE
- Designed For
- PowerEdge FC430, FC630, FC830, R320, R420, R520, R620, R720, R720xd, R820, VRTX, VRTX M520, VRTX M620; PowerVault DL4000
Detailed Specification
General
- Device Type
- Network adapter
- Form Factor
- Plug-in card - low profile
Networking
- Ports
- 10Gb Ethernet x 2
- Connectivity Technology
- Wired
- Data Link Protocol
- 10 Gigabit Ethernet
Expansion / Connectivity
- Interfaces
- 2 x 10Gb Ethernet - SFP+
Compatibility Information
- Designed For
- Dell PowerEdge FC430, FC630, FC830, R320, R420, R520, R620, R720, R720xd, R820, VRTX, VRTX M520, VRTX M620 , Dell PowerVault DL4000
