Description
Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache, when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring, that your media stays up, even if the network goes down.
-
Keep your content up and running with FailOver
Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides content protection with an advanced technology, that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and you're ready for instant protection. -
CMND - take control of your displays
A robust display management platform, CMND puts the power back into your hands. Update and manage content with CMND and Create or control your settings with CMND and Control. It's all possible with CMND. -
Manage settings of multiple displays with CMND and Control
With CMND and Control, easily manage multiple displays in a central location. With real time display monitoring, setting and updates from a remote location, and the ability to customize and configure multiple displays at once, such as video wall or menu board displays, controlling your suite of displays has never been easier. -
Create and update content with CMND and Create
Design and create compelling content with CMND and Create, a powerful authoring tool. With a drag-and-drop interface, preloaded templates, and integrated widgets, you'll be able to amaze your customers with compelling content. -
Connect and control your content via the cloud
Connect and control your content via the cloud with the integrated HTML5 browser. Using the browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with Full HD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the Internet, using Wi-Fi or with an RJ-45 cable, and enjoy your own created playlists. -
SmartPower for energy saving
The backlight intensity can be controlled and pre-set by the system to reduce the power consumption, which saves substantially on energy costs.
Specifications
Summary
- Product Description
- Philips Signage Solutions P-Line 55BDL5057P 55" Class (54.64" viewable) LED-backlit LCD display - Full HD - for digital signage
- Product Type
- LED-backlit LCD flat panel display
- Energy Label QR Code URL
- Https://eprel.ec.europa.eu/qr/337944
- Diagonal Class
- 55"
- Diagonal Size
- 54.64"
- Commercial Use
- Yes - digital signage
- Resolution
- 1920 x 1080
- Display Format
- 1080p
- Input Video Formats
- 1080/60i, 480/60p, 720/60p, 1080/50i, 720/50p, 576/50p, 1080/50p, 1080/60p, 480/60i, 576/50i
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
- Max Number of Screens
- 225
- Video Interface
- HDMI
- HDMI Ports Qty
- 2 ports
- Connectivity
- Wi-Fi, LAN
- PC Interface
- DVI, VGA (HD-15), DisplayPort, USB
- LCD Backlight Technology
- LED backlight
- Image Aspect Ratio
- 16:9
- TV Tuner
- No tuner
- Commercial Features
- CMND management
- Picture Enhancements
- Dynamic contrast enhancement, Pixel Shift, 3D Digital Comb Filter, Low Bright
- Speaker System
- 2 speakers
- Storage Drive Capacity
- 16 GB
- Storage Capacity
- 16 GB
- Supported Memory Cards
- microSD
- USB
- Yes
- Included Accessories
- Remote control, batteries
- Voltage
- AC 120/230 V (50/60 Hz)
- Energy Class
- Class G
- Power Consumption Operational
- 110 Watt
- Power Consumption (On mode)
- 123 W
- Power Consumption Stand by
- 0.5 Watt
- Energy Consumption per Year
- 179 kWh
- Dimensions (WxDxH) - without stand
- 122.86 cm x 5.68 cm x 69.94 cm
- Weight
- 25.2 kg
- Environmental Standards
- ENERGY STAR Qualified
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Product Type
- LED-backlit LCD flat panel display
- Energy Label QR Code URL
- Https://eprel.ec.europa.eu/qr/337944
- Energy Class
- Class G
- Power Consumption Operational
- 110 Watt
- Power Consumption (On mode)
- 123 W
- Power Consumption SDR (On mode)
- 123 kWh/1000h
- Energy Consumption per Year
- 179 kWh
- Diagonal Class
- 55"
- Diagonal Size
- 54.64"
- Commercial Use
- Yes - digital signage
- Operating System
- Android OS
- TV Tuner
- No tuner
- TV Tuner Presence
- No
- Video Interface
- HDMI
- HDMI Ports Qty
- 2 ports
- PC Interface
- DVI, VGA (HD-15), DisplayPort, USB
- Modes
- Portrait mode, landscape mode
- Picture Enhancements
- Dynamic contrast enhancement, Pixel Shift, 3D Digital Comb Filter, Low Bright
- Dimensions
- Without stand
- Width
- 122.86 cm
- Depth
- 5.68 cm
- Height
- 69.94 cm
- Weight
- 25.2 kg
Display
- Resolution
- 1920 x 1080
- Display Format
- 1080p
- Image Aspect Ratio
- 16:9
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
- LCD Backlight Technology
- LED backlight
- Image Contrast Ratio
- 1300:1
- Dynamic Contrast Ratio
- 500000:1
- Brightness
- 700 cd/m²
- Viewing Angle
- 178 degrees
- Viewing Angle (Vertical)
- 178 degrees
- Pull-Down Compensation
- 3:2, 2:2
- Response Time
- 8 ms
- Display Menu Language
- Danish, Chinese (traditional), Chinese (simplified), English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Turkish, Arabic, Japanese
- Backlight Life
- 60,000 hour(s)
- Commercial Features
- CMND management
- Features
- Certified for 24/7 Continuous Operation
Video Wall
- Max Number of Screens
- 225
Stands & Mounts
- Stand
- Optional
- Flat Panel Mount Interface
- 400 x 400 mm
Video Features
- Input Video Formats
- 1080/60i, 480/60p, 720/60p, 1080/50i, 720/50p, 576/50p, 1080/50p, 1080/60p, 480/60i, 576/50i
- Supported Computer Resolutions
- 1366 x 768, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 768 (WXGA), 1360 x 768, 1920 x 1080, 1440 x 900, 1280 x 800, 3840 x 2160
Media Player
- Supported Video Formats
- MPEG-4, WMV, MKV, VOB, TS, M2TS, M4V, MPG, MPEG, MTS, MK3D, TTS
- Supported Audio Formats
- MP3, WMA, WAV, AAC, AIFF, LPCM, M4A, AIF, ASF, M3U, MP4
- Supported Pictures Formats
- BMP, JPG, GIF, JPEG, PDF
- Supported Memory Cards
- microSD
- USB Port
- Yes
- USB Ports Qty
- 1
- Configuration
- ARM Cortex-A53 Octa-Core ( 1.5 GHz ) - 2 GB DDR3 - 16 GB - PowerVR SGX6110
- Storage Drive Capacity
- 16 GB
Remote Control
- Type
- Remote control
Audio System
- Speaker System
- 2 speakers
- Output Power / Total
- 20 Watt
- Speakers
- 2 x main channel speaker - 10 Watt
Network & Internet Multimedia
- Connectivity
- Wi-Fi, LAN
- LAN Protocol
- Ethernet
- Supported Consumer Electronics Control (CEC)
- One Wire
Connections
- Connector Type
- DisplayPort input , 2 x HDMI , DVI-D input , USB , DisplayPort output , DVI-I output , Audio line-in , Audio line-in , Audio line-out , Audio line-out , LAN , Serial input , Serial output , Infrared input , Infrared output , mPCIe slot
Miscellaneous
- Included Accessories
- Batteries
- Cables Included
- Serial cable
- Compliant Standards
- FCC Class B certified, UL, VCCI, C-Tick, BSMI, GOST, cUL, CB, CCC, RoHS, PSE Mark, J-MOSS
Sustainability Information
- ENERGY STAR Certified
- Yes
- ENERGY STAR Version
- 7.0
Power
- Power Device
- Power adapter
- Input Voltage
- AC 120/230 V (50/60 Hz)
- Power Consumption Stand by
- 0.5 Watt
- Power Consumption (Off Mode)
- 0.5 Watt
- Features
- Smart power
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 20 - 80%
