Description
The WAX610 supports the next generation Wi-Fi 6 smartphones, IoT devices, and notebook computers, delivering up to 40% more throughput to each individual device in the 5GHz band and 70% more throughput in the 2.4GHz band, compared to the previous generation equivalent model; provides 4x the client device connection, allowing businesses to serve more customers with better speed and less congestion.
The WAX610 is ideal in high-density client device environments, such as schools, hotels, restaurants and conference centers, and provides enterprise-grade Wi-Fi network security. With Insight management, WAX610 works seamlessly with your current NETGEAR Insight managed switches, Wi-Fi access points and network storage, and is compatible with previous generation Wi-Fi devices (Wi-Fi 5 802.11ac for example) and Wi-Fi access points.
In the past several years, the Wi-Fi industry has made progress in increasing speeds by leaps and bounds. However, capacity continues to be a challenge, namely, supporting a large number of concurrent users. This requirement is particularly acute for businesses, where very high throughput to each individual device may not be the paramount requirement. Rather, it is providing network connectivity to a large number of client devices, with good throughput, stable connection, and robust responses to environmental changes that is most important.
With the updated Wi-Fi 6 (802.11ax) technology such as OFDMA, upstream and downstream MU-MIMO, and increased speeds, coverage, and capacity, you can feel confident that you're getting the highest performance Wi-Fi that's set for years to come! Plus the assurance that you can now add more connected devices on your business Wi-Fi network without any slowdowns or blind spots.
The WAX610, a Wi-Fi 6 business access point, combined with Insight, helps small and medium businesses with an easy way to manage their network without an IT expert, providing great Wi-Fi connection leaving each of their customers satisfied as a network user. NETGEAR empowers businesses with a Wi-Fi 6 business access point for high performance and high coverage for the years to come.
Specifications
Summary
- Product Description
- NETGEAR Insight WAX610 - radio access point - Wi-Fi 6 - cloud-managed
- Device Type
- Radio access point
- Form Factor
- External - indoor
- Localisation
- Europe
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Frequency Band
- 2.4 GHz, 5 GHz
- Capacity
- Maximum number of users: 250 , Concurrent users: 30
- Included Accessories
- Wall/ceiling mounting kit
- Power Over Ethernet (PoE) Supported
- PoE+
- Dimensions (WxDxH)
- 16.09 cm x 16.09 cm x 3.325 cm
- Weight
- 412 g
- Manufacturer Warranty
- 5-year warranty
Detailed Specification
General
- Device Type
- Radio access point
- Ruggedized Design
- Indoor
- Width
- 16.09 cm
- Depth
- 16.09 cm
- Height
- 3.325 cm
- Weight
- 412 g
- Localisation
- Europe
Networking
- Form Factor
- External
- Connectivity Technology
- Wireless
- Line Coding Format
- OFDM, OFDMA
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Remote Management Protocol
- SSH, RADIUS
- Cloud-Managed
- Yes
- Frequency Band
- 2.4 GHz, 5 GHz
- Capacity
- Maximum number of users: 250 , Concurrent users: 30
- Wi-Fi Rating
- AX1800
- Status Indicators
- Power, LAN, 2.4/5 GHz
- Features
- VLAN support, auto-uplink (auto MDI/MDI-X), repeating mode, MAC address filtering, Wireless Distribution System (WDS) support, Mesh networking, Wi-Fi Multimedia (WMM) support, LLDP support, Neighbor Discovery Protocol (NDP), Captive Portal, 802.1x authentication, Transmit Power Control (TPC), MU-MIMO technology, band steering, guest access, bridge mode, Target Wait Time (TWT), BSS Coloring
- Encryption Algorithm
- SSL, TLS, PEAP, TTLS, WPA, WPA2, WPA-Enterprise, WPA2-Enterprise, WPA3
- Authentication Method
- Secure Shell (SSH), RADIUS, Extensible Authentication Protocol (EAP)
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
- Antenna
- Internal
Expansion / Connectivity
- Interfaces
- 1 x 1/2.5GBase-T (PoE+) - RJ-45
Miscellaneous
- Included Accessories
- Wall/ceiling mounting kit
Power
- Power Over Ethernet (PoE) Supported
- PoE+
Software / System Requirements
- Software Included
- NETGEAR Insight (1 year subscription)
Manufacturer Warranty
- Service & Support
- Limited warranty - replacement - 5 years - response time: next business day , Technical support - 90 days
