Description
ReadyNAS 628X is an 8-bay desktop network storage device, delivering up to 20 Gigabits per second throughput in data backup, file sharing and virtualized storage with a unique 5 Levels of Data Protection, achieving industry leading benchmarks in network data storage and business continuity.
-
File sharing
These days, running a successful business often depends on successful file sharing - application data, virtual images, client files, email, all the digital files that make your business go. With ReadyNAS you finally have an advanced and easy-to use solution for centralizing, securing, and sharing those critical assets. -
Backup
The advanced data protection solution for SMB. Businesses depend on data - customer information, transaction records, pay roll, product development and marketing data. ReadyNAS helps businesses protect their data against physical and human errors, malicious attacks, and natural disasters. Business continuity is part of any business plan. -
Disaster recovery
The custom-built ReadyNAS OS protects stored data with automatic RAID configuration, the continuous security of Unlimited Snapshots, and easy to manage Cloud Replication. By maintaining multiple copies of vital data through cloud replication, it makes it easy for you to move data off-site to protect against natural disasters and theft.
Specifications
Summary
- Product Description
- NETGEAR ReadyNAS 628X - NAS server
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet / 10 Gigabit Ethernet
- Max Supported Capacity
- 80 TB
- Installed Devices / Modules Qty
- 8 (max)
- Dimensions (WxDxH)
- 19.2 cm x 28.855 cm x 31.9 cm
- Weight
- 9.38 kg ()
- Processor
- 1 x Intel Xeon D-1521 2.4 GHz (Quad-Core)
- Storage Controller
- 1 x RAID SATA 6Gb/s RAID 0, 1, 5, 6, 10, JBOD
- Hard Drive
- SATA 6Gb/s
- Networking
- 10Mb LAN, 100Mb LAN, 1GbE, 10GbE
- RAM
- 8 GB
- Power
- AC 120/230 V (50/60 Hz)
- Storage Operating System
- ReadyNAS OS 6.6
- System Requirements
- UNIX, Linux, Apple MacOS X, Microsoft Windows Server 2008 R2, Android, Apple iOS, Microsoft Windows Server 2012, Microsoft Windows 7 / 8 / 8.1 / 10
- Manufacturer Warranty
- 5-year warranty
Detailed Specification
General
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet / 10 Gigabit Ethernet
- Max Supported Capacity
- 80 TB
- Installed Devices / Modules Qty
- 8 (max)
- Width
- 19.2 cm
- Depth
- 28.855 cm
- Height
- 31.9 cm
- Weight
- 9.38 kg ()
- Built-in Devices
- Status LCD, touch screen
Processor / Memory
- Processors Installed
- 1 x Intel Xeon D-1521 2.4 GHz
- Number of Cores
- Quad-Core
- Max Supported Qty
- 1
- RAM
- 8 GB DDR4
Storage Controller
- Type
- 1 x RAID
- Interface Type
- SATA 6Gb/s
- RAID Level
- RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Hard Drive
- Type
- HDD - hot-swap
- Interface Type
- SATA 6Gb/s
Networking
- Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE, 10GbE
- Network / Transport Protocol
- TCP/IP, NTP, FTP, DHCP, Bonjour, SMB
- Remote Management Protocol
- SNMP 2, SNMP 3, SSH
- Network Services Compatibility
- Microsoft Active Directory (AD), DHCP, Microsoft CIFS, Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS
- Features
- Wake on LAN (WOL), E-mail alert, IPv6 support, Access Control List (ACL) support, SSH support, iTunes server, Jumbo Frames support, static IP mode, IPv4 support, dynamic IP mode, DHCP client, WebDAV server, Dropbox support, anti-virus protection
- Encryption Algorithm
- 256-bit AES
- Compliant Standards
- IEEE 802.3ad (LACP), UPnP
Expansion / Connectivity
- Expansion Bays
- 8 (total) / 8 (free) x hot-swap - 2.5" / 3.5"
- Interfaces
- 2 x Ethernet 1000Base-T - RJ-45 , 3 x USB 3.0 - Type A , 1 x eSATA , 2 x Ethernet 10Base-T - RJ-45
Miscellaneous
- Features
- Security lock slot (cable lock sold separately), built-in cooling fan, UPS support, scheduled power on/off
- Compliant Standards
- FCC Class B certified, RoHS, VCCI Class B
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 85.6 Watt
- Power Provided
- 250 Watt
Software / System Requirements
- Storage Operating System
- ReadyNAS OS 6.6
- OS Required
- UNIX, Linux, Apple MacOS X, Microsoft Windows Server 2008 R2, Android, Apple iOS, Microsoft Windows Server 2012, Microsoft Windows 7 / 8 / 8.1 / 10
Manufacturer Warranty
- Service & Support
- Limited warranty - replacement - 5 years - response time: next business day , Technical support - 90 days
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
