Description
The NETGEAR M4300 Switch Series delivers L2/L3/L4 and IPv4/IPv6 rich services for enterprise edge and SMB aggregation deployments with unrivaled ease of use: 10 Gigabit models can seamlessly stack with 1 Gigabit models within the series. Non-stop forwarding virtual chassis architectures provide advanced High Availability (HA) with hitless failover, that is, distributed link aggregation allows for load balancing and virtually zero downtime. License-free L3 feature set includes static routing, policy-based routing, RIP, VRRP, OSpiv as well as Multicast PIM routing. The NETGEAR M4300 Switch Series is ready for the future, with Software-defined Network (SDN) and OpenFlow 1.3 enabled for your network.
M4300-24X24F comes with 24 ports 10GBASE-T and 24 ports 10GBASE-X SFP+ in a full-width form factor. All 48 ports are independent and 1G backward compatible for progressive transition to 10G speeds. Ideal for Top-of-Rack server and storage applications: 1+1 PSU protection and front to back cooling ensure hot and cold aisle compliance. M4300-24X24F is line-rate with 960Gbps fabric for SMB core applications as well as spine and leaf stacking architectures.
-
Efficient performance
With a switching capacity of 960 Gbps and throughput of 714 Mpps, the NETGEAR M4300-24X24F delivers efficient and reliable performance for demanding network environments. -
Comprehensive connectivity
This switch has a total of 48 ports, including 24 10GBase-T and 24 10GBase-X ports, complemented by dedicated management, serial, and USB ports, ensuring versatile connectivity options for a wide range of devices. -
Advanced networking features
Equipped with Layer 3 switching capabilities, the M4300-24X24F supports advanced features such as ARP support, Access Control List (ACL) support, Quality of Service (QoS), and various routing protocols including OSPF and RIP, enhancing network efficiency and security. -
High scalability
The switch is designed for scalability, allowing up to 8 units to be stacked, facilitating network growth and expansion without compromising performance. -
Secure and manageable
Featuring robust security protocols including RADIUS and TACACS+ authentication, and comprehensive remote management protocols such as CLI, HTTPS, SNMP, SSH, and Telnet, the M4300-24X24F ensures a secure and easily manageable network infrastructure.
Specifications
Summary
- Product Description
- NETGEAR M4300-24X24F - switch - 48 ports - Managed - rack-mountable
- Device Type
- Switch - 48 ports - L3 - Managed - stackable
- Enclosure Type
- Front to back airflow rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 24 x 10/100/1000/10000 + 24 x 10 Gigabit SFP+
- Performance
- Switching capacity: 960 Gbps , Throughput: 714 Mpps
- Capacity
- Virtual interfaces (VLANs): 4000
- Routing Protocol
- OSPF, RIP, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, MLDv2
- Remote Management Protocol
- SNMP, Telnet, HTTPS, SSH, CLI
- Features
- ARP support, DiffServ support, IPv6 support, STP support, RSTP support, VRRP support, DHCP snooping, ACL support, QoS, MLD snooping, STP Root Guard, IPv4 support, LACP support, DHCP relay, RSPAN, PVRST, dynamic ARP protection, IP source guard, BPDU, LISP ASM, SSM
- Compliant Standards
- IEEE 802.3ad (LACP), IEEE 802.3az
- Power
- AC 120/230 V
- Localisation
- Europe, Americas
- Manufacturer Warranty
- NETGEAR lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 48 ports - L3 - Managed - stackable
- Enclosure Type
- Front to back airflow rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 24 x 10/100/1000/10000 + 24 x 10 Gigabit SFP+
- Performance
- Switching capacity: 960 Gbps , Throughput: 714 Mpps
- Capacity
- Virtual interfaces (VLANs): 4000
- Max Units In A Stack
- 8
- Routing Protocol
- OSPF, RIP, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, MLDv2
- Remote Management Protocol
- SNMP, Telnet, HTTPS, SSH, CLI
- Authentication Method
- RADIUS, TACACS+
- Features
- ARP support, DiffServ support, IPv6 support, STP support, RSTP support, VRRP support, DHCP snooping, ACL support, QoS, MLD snooping, STP Root Guard, IPv4 support, LACP support, DHCP relay, RSPAN, PVRST, dynamic ARP protection, IP source guard, BPDU, LISP ASM, SSM
- Compliant Standards
- IEEE 802.3ad (LACP), IEEE 802.3az
- Processor
- 1: 800 MHz
- RAM
- 1 GB
- Flash Memory
- 256 MB
Expansion / Connectivity
- Interfaces
- 24 x 10GBase-T RJ-45 , 24 x 10GBase-X SFP+ , 1 x management (Gigabit LAN) RJ-45 , 1 x serial (RS-232) RJ-45 , 1 x console (mini-USB) , 1 x USB Type A
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V
Miscellaneous
- Localisation
- Europe, Americas
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
