Description
The first of a generation, the SD5700T Thunderbolt 4 Dual 4K Docking Station with 90W PD - Win/Mac offers premium Thunderbolt benefits now, and well into the future; compatible with Thunderbolt 4-enabled Windows 10 laptops and backward compatibility with Thunderbolt 3 MacBooks running macOS 11 (Big Sur) or later, supports Thunderbolt 3, Thunderbolt 4, USB-C and USB4 accessories and provides full power delivery, regardless of how many devices are connected. Features include 11-ports, Single 8K @ 30 Hz, or up to Dual 4K @ 60Hz video, 40Gbps data transfer speeds, UHS-II SD 4.0 card reader speeds, and more.
-
Universal compatibility
Universally compatible, this Thunderbolt 4 desktop docking station is the first of its kind, providing the ultimate plug-and-play solution for Thunderbolt 4 Window 10 laptops and Thunderbolt 3 MacBooks running macOS 11 (Big Sur) or later, while also supporting Thunderbolt 3, Thunderbolt 4, USB-C and USB4 accessories. -
Thunderbolt 4 technology
For the first time, this Thunderbolt 4 modern docking station can connect up to three additional Thunderbolt devices directly (up to five in total) while providing transfer speeds up to 40Gbps, up to Dual 4K video output, and audio; all through the included 0.8m Thunderbolt 4 cable, for a quick and powerful plug-and-play experience. Intel VT-d DMA protection blocks peripheral devices from unauthorized access to system memory. -
Single 8K or Dual 4K video output for Thunderbolt 4-enabled devices
Single 8K or Dual 4K (@60 Hz) video output for Thunderbolt 4-enabled host devices lets you extend visual productivity with the crisp resolution, contrast, and color depth of Ultra HD (Single 8K 30Hz or Dual 4K 60Hz) via the available Thunderbolt 4 ports. -
90W power delivery
90W power delivery allows you to quickly and easily charge any Thunderbolt 4 Windows 10 laptop or Thunderbolt 3-enabled MacBook running macOS 11 (Big Sur) or later, in addition to providing full support for your USB-C or USB4 peripheral accessories. -
Helps future-proof your desktop setup
With 11 ports of connectivity, you'll have the power to get the job done today and well into the future. This dock offers four Thunderbolt 4 ports, all capable of data, video and audio; four USB-A ports (one 5V/1.5A charging port on the front and three Gen2@10Gbps ports on the rear); one Gigabit Ethernet port; one audio combo jack; and one UHS-II SD 4.0 card reader.
Specifications
Summary
- Product Description
- Kensington SD5700T Thunderbolt 4 Dual 4K Docking Station with 90W Power Delivery - docking station - Thunderbolt 4 - 4 x Thunderbolt - 1GbE
- Product Type
- Docking station
- Docking Interface
- Thunderbolt 4
- Video Interfaces
- 4 x Thunderbolt
- Dimensions (WxDxH)
- 15.5 cm x 25.4 cm x 9.2 cm
- Weight
- 1.69 kg
- Colour
- Black
- Localisation
- Europe
- Networking
- Gigabit Ethernet
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Product Type
- Docking station
- Width
- 15.5 cm
- Depth
- 25.4 cm
- Height
- 9.2 cm
- Weight
- 1.69 kg
- Enclosure Colour
- Black
- Localisation
- Europe
Networking
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
Expansion / Connectivity
- Interfaces
- 3 x USB-C 3.2 Gen 2 - 9 pin USB Type A , 4 x USB 2.0 - 4 pin USB Type A , 1 x network - 10Base-T/100Base-TX/1000Base-TX - RJ-45 , 1 x audio - headphones/microphone - mini-phone 3.5 mm , 1 x Thunderbolt 4 upstream - 24 pin USB-C , 3 x Thunderbolt 4 downstream - 24 pin USB-C
Miscellaneous
- Input Device
- SD card reader, microSD card reader
- Features
- Dual monitor support, fast charging, 90W power delivery
- Security Slot Type
- Kensington nano security slot / Kensington security slot
- Compliant Standards
- Plug and Play
System Requirements
- OS Required
- Windows 10
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
