Description
Are your enterprise data centers growing and requiring increased network performance? Increased workload demands are putting pressure on server I/O. The HP FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter increases throughput for the HP ProLiant Gen8 DL and SL Server series by using the innovative HP FlexibleLOM form factor to offer dual-ports in an SFP+ adapter configuration that includes new storage I/O functionality, making it a full Converged Network Adapter. This is the solution of choice for workload-intensive computing environments.
-
Accelerates Server Performance
The HPE FlexFabric 10Gb 2-port FLR-SFP+ 57810S Adapter boosts network performance with full line-rate 10GbE throughput across all ports.Provides increased server performance by delivering full hardware offload for storage traffic. -
Robust Virtualization Capabilities
The HPE FlexFabric 10Gb 2-port FLR-SFP+ 57810S Adapter delivers Single Root I/O Virtualization (SR-IOV) support to allow multiple operating systems to share a physical interconnect.Enhances network management and efficiency with support for VLAN tagging. -
Streamlines Deployment and Management
Makes BroadcomQLogic Ethernet solutions available across a wide range of HPE server platforms.Unifies NIC and storage management using HPE ProActive Insight architecture. -
Network Partitioning to Reduce Network Sprawl and Take Full Advantage of Bandwidth
Allowing administrators to configure a 10 Gb adapter as four separate partitions or physical functions. Eliminate multiple NICs, HBAs, cables consolidating multiple connections on to one network adapter.Ideal for customers in virtual server environments by allowing them to segment the high performance connection and provide the right amount of network bandwidth to the applications.
Specifications
Summary
- Product Description
- HPE FlexFabric 534FLR-SFP+ - network adapter - PCIe 2.0 x8 - 10 Gigabit SFP+ x 2
- Device Type
- Network adapter
- Form Factor
- Plug-in card
- Interface (Bus) Type
- PCI Express 2.0 x8
- PCI Specification Revision
- PCIe 2.0
- Ports
- 10 Gigabit SFP+ x 2
- Data Link Protocol
- 10GbE
- Data Transfer Rate
- 10 Gbps
- Processor
- 1 x Broadcom BCM57810S
- RAM
- 256 MB
- Compliant Standards
- IEEE 802.3, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 802.2x
- System Requirements
- SuSE Linux Enterprise Server 11, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 5.7, VMware ESXi 5.0 update 1, VMware ESX 4.1 update 2
- Pricing Type
- Factory integrated
- Manufacturer Warranty
- 1-year warranty
Detailed Specification
General
- Device Type
- Network adapter
- Form Factor
- Plug-in card
- Interface (Bus) Type
- PCI Express 2.0 x8
- PCI Specification Revision
- PCIe 2.0
Networking
- Ports
- 10 Gigabit SFP+ x 2
- Connectivity Technology
- Wired
- Data Link Protocol
- 10 Gigabit Ethernet
- Data Transfer Rate
- 10 Gbps
- Status Indicators
- Port status, link/activity
- Features
- Auto-negotiation, Jumbo Frames support, PXE support, Large Send Offload (LSO), Receive Side Scaling (RSS), TCP Segmentation Offload (TSO)
- Compliant Standards
- IEEE 802.3, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 802.2x
Processor / Memory
- Processor
- 1 x Broadcom BCM57810S
- RAM
- 256 MB
Expansion / Connectivity
- Interfaces
- 2 x 10Gb Ethernet - SFP+
Miscellaneous
- Compliant Standards
- FCC Class A certified, UL, VCCI Class A ITE, EN55024, EN55022 Class A, ICES-003 Class A, WEEE, RoHS, BSMI Class A, EN 61000-3-2:2006, EN 61000-3-3:2008
- Pricing Type
- Factory integrated
Software / System Requirements
- OS Required
- SuSE Linux Enterprise Server 11, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 5.7, VMware ESXi 5.0 update 1, VMware ESX 4.1 update 2
Manufacturer Warranty
- Service & Support
- Limited warranty - 1 year
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 55 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
