Description
Fast, high-volume scanning
The DS-780N is designed for high-volume network scanning, with a 100-sheet automatic document feeder (ADF), very fast colour scanning speeds of 45ppm/90ipm at 300dpi, and USB 3.0 to enable direct-to-PC connection.
Smart features improve workflow
Innovative features make scanning easy, including industry first slow mode for delicate documents and double-feed detection skip to allow scanning of items such as envelopes and documents with Post-its. An intuitive colour LCD touchscreen panel makes scanning easy, and allows job creation without accessing a computer.
Built-in networking and security features
The DS-780N with built-in networking is the perfect solution for creating a scanner fleet. Epson's Document Capture Pro 2.0 software offers complete control and security, allowing job, group, device and access protocols to be managed centrally. User authentication can be enabled via pin code, third-party IC card or user directory (LDAP), with a lockable control panel to prevent tampering. Pre-defined job profiles help ensure scans are sent to the correct locations.
Usage reports and maintenance alerts
Using Epson Device Admin or Document Capture Pro Server, the DS-780N can alert the administrator if it needs maintenance, and provides detailed usage reports showing which devices are used most and how many scans they've made, for effective fleet management.
-
Secure scanning
Complete controlIntelligent, secure business scanner with built-in networking and smart features for fast, high-volume scanning and circulation.
Specifications
Summary
- Product Description
- Epson WorkForce DS-780N - document scanner - desktop - USB 3.0, Gigabit LAN
- Device Type
- Document scanner - desktop
- Interface Type
- USB 3.0, Gigabit LAN
- Additional Functions
- Scan to network share, scan to FTP, scan to SharePoint, scan to email
- Max Supported Document Size
- A4 (210 x 297 mm)
- Localisation
- United Kingdom
- Input Type
- Colour
- Grayscale / Color Depth
- 10-bit grey / 30-bit colour
- Grayscale / Color Depth (External)
- 8-bit (256 grey levels) / 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Max Document Scan Speed
- 45 ppm (mono) / 45 ppm (colour)
- Max Document Size
- 215.9 mm x 6096 mm
- Automatic Duplexing
- Yes
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 100 sheets
- Duty Cycle
- 5000 scans per day
- System Requirements
- Linux, Microsoft Windows XP Professional x64 Edition, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2003 (32/64-bits), Apple MacOS X 10.7.x, Apple MacOS X 10.6.8, Apple MacOS X 10.8.x, Microsoft Windows Server 2012 x64 Edition, Microsoft Windows Server 2012 R2, Apple MacOS X 10.9.x, Microsoft Windows 7 / 8 / 8.1 / 10 (32/64 bits)
- Dimensions (WxDxH)
- 29.6 cm x 21.2 cm x 21.7 cm
- Weight
- 3.7 kg
- Manufacturer Warranty
- 1-year warranty
Detailed Specification
General
- Type
- Document scanner - desktop
- Interface Type
- USB 3.0, Gigabit LAN
- Additional Functions
- Scan to network share, scan to FTP, scan to SharePoint, scan to email
- Max Supported Document Size
- A4 (210 x 297 mm)
- Localisation
- United Kingdom
Scanner
- Input Type
- Colour
- Grayscale Depth
- 10-bit grey
- Grayscale Depth (External)
- 8-bit (256 grey levels)
- Colour Depth
- 30-bit colour
- Colour Depth (External)
- 24-bit (16.7 million colours)
- Optical Resolution
- 600 dpi x 600 dpi
- Scan Mode
- Single-pass
- Automatic Duplexing
- Yes
- Max Document Scan Speed B/W
- 45 ppm
- Max Document Scan Speed Colour
- 45 ppm
- Duty Cycle
- 5000 scans per day
- Scanner Speed Details
- 45 ppm - black & white - A4 - 300 dpi , 90 ipm - duplex - black & white - A4 - 300 dpi , 45 ppm - colour - A4 - 300 dpi , 90 ipm - duplex - colour - A4 - 300 dpi , 45 ppm - black & white - A4 - 200 dpi , 90 ipm - duplex - black & white - A4 - 200 dpi , 45 ppm - colour - A4 - 200 dpi , 90 ipm - duplex - colour - A4 - 200 dpi
- Scanner Features
- EPSON ReadyScan LED Technology, Barcode Detection, blank page skipping, built-in LCD screen, Auto Deskew, Punch Hole Removal, A3 stitching, automatic folder creation, automatic multi-document recognition, Unsharp Mask
- Scan File Formats
- JPEG, TIFF, PDF
- Compliant Standards
- TWAIN, ISIS, WIA
Media Handling
- Max Document Size
- 215.9 mm x 6096 mm
- Document Feeder Type
- Automatic
- Document Storage Capacity
- 100 sheets
Expansion / Connectivity
- Interfaces
- USB 3.0 , Gigabit LAN
Miscellaneous
- Cables Included
- 1 x USB cable
Power
- Power Device
- Internal power supply
- Power Consumption Operational (Standby)
- 17 Watt
- Power Consumption Stand by
- 1.3 Watt
Software / System Requirements
- Software Included
- EPSON Document Capture Pro, EPSON Document Capture, EPSON Scan 2
- OS Required
- Linux, Microsoft Windows XP Professional x64 Edition, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2003 (32/64-bits), Apple MacOS X 10.7.x, Apple MacOS X 10.6.8, Apple MacOS X 10.8.x, Microsoft Windows Server 2012 x64 Edition, Microsoft Windows Server 2012 R2, Apple MacOS X 10.9.x, Microsoft Windows 7 / 8 / 8.1 / 10 (32/64 bits)
Dimensions & Weight
- Width
- 29.6 cm
- Depth
- 21.2 cm
- Height
- 21.7 cm
- Weight
- 3.7 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - 1 year - on-site
Environmental Parameters
- Min Operating Temperature
- 5 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 15 - 80%
