D-Link 48 10/100/1000 Base-T Port Gigabit Smart Switch

Review this product
Quicklinx: 988XWS00 Mfr#: DGS-1210-52
Type: Gigabit Ethernet
Ports: 48
Data Transfer Rate: 1Gbps
Managed: Yes
POE: No
14 in stock
£287.86 ex VAT
£345.43 inc VAT
Qty
Standard delivery Delivered within 3 working days

Description

The DGS-1210-10/10P/20/28 features a fanless design that allows for quieter operation and helps to extend the device's lifetime. While the DGS-1210-28P/52/52P feature a smart fan design that powers on after the switch reaches a certain temperature, saving energy and cutting costs without sacrificing performance.

  • Flexible port configurations

    The DGS-1210 series provides 48 10/100/1000 Mbps ports plus 4 SFP ports.
  • D-Link Green technology

    D-Link Green device is about providing eco-friendly alternatives without compromising performance. D-Link Green technology to reduce energy consumption on DGS-1210 series such as shutting down a port, or turning off some LED indicators, or adjusting the power usage according to the Ethernet cable connected to it.
  • Extensive L2 features

    Implemented as complete L2 devices, the switch include functions such as IGMP snooping, port mirroring, spanning tree, 802.3ad LACP and loopback detection to enhance performance and network resiliency.
  • Traffic segmentation, QoS and auto surveillance VLAN

    The switch supports 802.1Q VLAN standard tagging to enhance network security and performance. The switch also supports 802.1p priority queues, enabling users to run bandwidth-sensitive applications such as streaming multimedia by prioritizing that traffic in network. These functions allow switch to work seamlessly with VLAN and 802.1p traffic in the network. Auto surveillance VLAN will automatically place the video traffic from pre-defined IP surveillance devices to an assigned VLAN with higher priority, so it can be separated from normal data traffic. Asymmetric VLAN is implemented in the switch for a more efficient use of shared resources, such as server or gateway devices.
  • Network security

    D-Link's excellent safeguard engine function protects the switch against traffic flooding caused by virus attacks. Additional features like 802.1x port-based authentication provide access control of the network with external RADIUS servers. ACL is a powerful tool to screen unwanted IP or MAC traffic. Storm control can help to keep the network from being overwhelmed by abnormal traffic. Port security is another simple but useful authentication method to maintain the network device integrity.
  • Versatile management

    The D-Link web smart switch provides growing business with a simple and easy management of their network, using an intuitive smart console utility or a web-based management interface that allows administrators to remotely control their network down to the port level. The smart console easily allows customers to discover multiple D-Link web smart switch with the same L2 network segment connected to the user's local PC. With this utility, users do not need to change the IP address of the PC and provide easy initial settings of the smart switch. The switch within the same L2 network segment connected to the user's local PC are displayed on the screen for instant access. It allows extensive switch configuration settings, and basic configuration of discovered devices, such as a password change or firmware upgrade.

Specifications

Summary

Product Description
D-Link Web Smart DGS-1210-52 - switch - 48 ports - Managed - rack-mountable
Device Type
Switch - 48 ports - Managed
Enclosure Type
Rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
48 x 10/100/1000 + 4 x Gigabit SFP
Performance
Switching capacity: 104 Gbps , Forwarding performance: 77.4 Mpps
MAC Address Table Size
16K entries
Jumbo Frame Support
10000 bytes
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, SNMP 2c, HTTP, CLI
Features
Flow control, full duplex capability, Layer 2 switching, DHCP support, auto-negotiation, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Safeguard Engine, D-Link Green Technology
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x
Power
AC 120/230 V (50/60 Hz)
Dimensions (WxDxH)
44 cm x 25 cm x 4.4 cm


Detail

General

Device Type
Switch - 48 ports - Managed
Enclosure Type
Desktop, rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
48 x 10/100/1000 + 4 x Gigabit SFP
Performance
Switching capacity: 104 Gbps , Forwarding performance: 77.4 Mpps
MAC Address Table Size
16K entries
Jumbo Frame Support
10000 bytes
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, SNMP 2c, HTTP, CLI
Features
Flow control, full duplex capability, Layer 2 switching, DHCP support, auto-negotiation, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Safeguard Engine, D-Link Green Technology
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x
RAM
128 MB
Flash Memory
16 MB
Status Indicators
Port transmission speed, power, link OK, link/activity

Expansion / Connectivity

Interfaces
48 x 1000Base-T RJ-45 , 4 x SFP (mini-GBIC)

Power

Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)

Miscellaneous

Compliant Standards
FCC Class A certified, C-Tick, cUL, VCCI Class A ITE, IC Class A

Dimensions & Weight

Width
44 cm
Depth
25 cm
Height
4.4 cm

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95%
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
Humidity Range Storage
0 - 95%
