Description
An effective work environment encourages collaboration. That often means tearing down office walls to create open workspaces. With their quiet, fan-less design, the switches create many possibilities for designing workspaces. They can reside nearly anywhere outside your wiring closet. Install them in carpeted areas such as offices, conference rooms, classrooms, and retail stores for quick, flexible connections. Rearrange rooms and floors without changing your cabling infrastructure. Consolidate cabling for big savings. Rather than running multiple Ethernet cables from endpoints like IP phones and Wi-Fi access points to a wiring closet, you just connect devices over a few feet of cabling to a nearby 3560-CX switch. Then connect the compact switch to the wiring closet with a single Ethernet or fiber cable. Using this setup, a 200-room hotel using compact switches in guest rooms can eliminate up to 30 kilometers of cables.
-
ETHERNET PORT CONFIGURATION
12 10/100/1000 Gigabit Ethernet (GbE) ports; 8 PoE+ output ports; two 1 G SFP uplinks; two 1 G copper uplinks -
POWER CONSUMPTION
26.3W at 100% throughput -
FANLESS DESIGN
Silent operation -
DEFAULT SOFTWARE
IP Base (IP Services with RTU Licence) -
PEACE OF MIND
Enhanced limited lifetime warranty
Specifications
Summary
- Product Description
- Cisco Catalyst 3560CX-12PC-S - switch - 12 ports - Managed - rack-mountable
- Device Type
- Switch - 12 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 12 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 240 W
- Performance
- Forwarding performance: 16 Gbps , Forwarding performance (64-byte packet size): 23.8 Mpps
- Capacity
- Virtual interfaces (VLANs): 1023
- Jumbo Frame Support
- 9018 bytes
- Routing Protocol
- RIP-1, RIP-2, static IP routing
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI
- Features
- BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, STP support, DHCP snooping, PAgP support, ACL support, QoS, fanless, SRR, MAC Address Notification, RSPAN, Energy Efficient Ethernet, MVR, CoS, WTD
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 26.9 cm x 23.8 cm x 4.44 cm
- Weight
- 2.31 kg
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 12 ports - Managed
- Enclosure Type
- Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 12 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 240 W
- Performance
- Forwarding performance: 16 Gbps , Forwarding performance (64-byte packet size): 23.8 Mpps
- Capacity
- Virtual interfaces (VLANs): 1023
- Jumbo Frame Support
- 9018 bytes
- Routing Protocol
- RIP-1, RIP-2, static IP routing
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI
- Authentication Method
- Kerberos, Secure Shell (SSH), RADIUS, TACACS+
- Features
- BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, STP support, DHCP snooping, PAgP support, ACL support, QoS, fanless, SRR, MAC Address Notification, RSPAN, Energy Efficient Ethernet, MVR, CoS, WTD
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az
- RAM
- 512 MB
- Flash Memory
- 128 MB
- Status Indicators
- Port status, port transmission speed, port duplex mode, system, link/activity
Expansion / Connectivity
- Interfaces
- 12 x 1000Base-T RJ-45 PoE+ - 30 W , 1 x console RJ-45 , 1 x mini-USB Type B management , 1 x USB Type A , 2 x 1000Base-T RJ-45 uplink , 2 x SFP uplink
Power
- Power Device
- Internal power supply
- Power Provided
- 300 Watt
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 23.5 Watt
- 80 PLUS Certification
- 80 PLUS Silver
Miscellaneous
- Rack Mounting Kit
- Optional
- MTBF
- 553,140 hours
- Compliant Standards
- GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1
Software / System Requirements
- Software Included
- Cisco IOS IP Base
Dimensions & Weight
- Width
- 26.9 cm
- Depth
- 23.8 cm
- Height
- 4.44 cm
- Weight
- 2.31 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - advance parts replacement - lifetime - response time: next business day , Technical support - consulting - 90 days
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Min Storage Temperature
- -25 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
