Cisco Catalyst 2960X-48FPS-L Switch Managed 48 x 10/100/1000

Cisco Catalyst 2960X-48FPS-L Switch Managed 48 x 10/100/1000

Review this product
Quicklinx: BVMVWS00 Mfr#: WS-C2960X-48FPS-L
Type: Gigabit Ethernet
Ports: 48
Managed: Yes
Stock Status: In Stock
More than 50 in stock
£2,560.29 ex VAT
£3,072.34 inc VAT
Qty
Standard delivery Delivered within 3 working days

Description

Cisco Catalyst 2960-X series switches are fixed-configuration, stackable Gigabit Ethernet switches that provide enterprise-class access for campus and branch applications. Designed for operational simplicity to lower total cost of ownership, they enable scalable, secure and energy-efficient business operations.

Specifications

Summary

Product Description
Cisco Catalyst 2960X-48FPS-L - switch - 48 ports - Managed - desktop, rack-mountable
Device Type
Switch - 48 ports - Managed - stackable
Enclosure Type
Desktop, rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
PoE Budget
740 W
Performance
Switching capacity: 216 Gbps , Forwarding performance (64-byte packet size): 107.1 Mpps
Capacity
Virtual interfaces (VLANs): 1023
Jumbo Frame Support
9216 bytes
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
Features
Layer 2 switching, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Intrusion Detection System (IDS), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, SSH support, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NetFlow, Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Class of Service (CoS), Cisco FlexStack Plus
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
Power
AC 120/230 V (50/60 Hz)
Power Redundancy
Optional
Dimensions (WxDxH)
44.5 cm x 36.8 cm x 4.5 cm
Weight
5.8 kg
Manufacturer Warranty
Limited lifetime warranty
Bundled Services
Limited lifetime warranty


Detail

General

Device Type
Switch - 48 ports - Managed - stackable
Enclosure Type
Desktop, rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
PoE Budget
740 W
Performance
Switching capacity: 216 Gbps , Forwarding performance (64-byte packet size): 107.1 Mpps
Capacity
Virtual interfaces (VLANs): 1023
Jumbo Frame Support
9216 bytes
Max Units In A Stack
8
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
Authentication Method
Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Features
Layer 2 switching, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Intrusion Detection System (IDS), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, SSH support, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NetFlow, Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Class of Service (CoS), Cisco FlexStack Plus
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
Processor
: 600 MHz
RAM
512 MB
Flash Memory
128 MB
Status Indicators
Port status, link activity, port transmission speed, port duplex mode, system, RPS (Redundant Power Supply), PoE

Expansion / Connectivity

Interfaces
48 x 1000Base-T 10Base-T/100Base-TX/1000Base-T - RJ-45 - RJ-45 - PoE+ - 30 W , 1 x console console - RJ-45 - RJ-45 , 1 x mini-USB console - mini-USB Type B - Type B - management , 2 x USB - Type A , 1 x 1000Base-TX 10Base-T/100Base-TX - RJ-45 - RJ-45 - management , 4 x SFP (mini-GBIC) - SFP - uplink
Expansion Slots
1 (total) / 1 (free) x Stacking Module

Power

Power Device
Internal power supply
Power Redundancy
Optional
Voltage Required
AC 120/230 V (50/60 Hz)
Features
Redundant Power System (RPS) connector

Miscellaneous

MTBF
232,610 hours
Compliant Standards
CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 300386

Software / System Requirements

Software Included
Cisco IOS LAN Base

Dimensions & Weight

Width
44.5 cm
Depth
36.8 cm
Height
4.5 cm
Weight
5.8 kg

Manufacturer Warranty

Service & Support
Limited warranty - advance parts replacement - lifetime - response time: next business day , Technical support - consulting - 90 days

Environmental Parameters

Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
10 - 95% (non-condensing)
Min Storage Temperature
-25 °C
Max Storage Temperature
70 °C
Humidity Range Storage
10 - 95% (non-condensing)
