Description
The Cisco Catalyst 2960-Plus Series Switches are fixed-configuration Fast Ethernet switches that provide enterprise-class Layer 2 switching for branch offices, conventional workspaces, and infrastructure applications.
-
Enterprise-class quality of service
The Cisco 2960-Plus Series Switches offer intelligent traffic management that keeps everything flowing smoothly. Flexible mechanisms for marking, classification, and scheduling deliver superior performance for data, voice, and video traffic, all at wire speed. -
Cisco Catalyst SmartOperations
Cisco Catalyst SmartOperations is a comprehensive set of capabilities that simplify LAN planning, deployment, monitoring, and troubleshooting. Deploying SmartOperations tools reduces the time and effort required to operate the network and lowers total cost of ownership (TCO). -
Cisco EnergyWise
Cisco EnergyWise empowers IT teams to measure and manage the power consumed by devices connected to the network, providing measurable energy savings and reduced greenhouse gas emissions. EnergyWise policies can be used to control the power consumed by PoE-powered endpoints, desktop and data-center IT equipment, and a wide range of building infrastructure. EnergyWise technology is included on all Cisco Catalyst 2960-Plus Series Switches. -
Power over Ethernet
Cisco Catalyst 2960-Plus switches support IEEE 802.3af Power over Ethernet (PoE) to deliver lower total cost of ownership for deployments that incorporate Cisco IP phones, Cisco Aironet wireless access points, or other standards-compliant PoE end devices. PoE removes the need to supply wall power to PoE-enabled devices and eliminates the cost of adding electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments. -
Network management
The Cisco Catalyst 2960-Plus Series Switches offer a superior CLI for detailed configuration and administration. 2960-Plus switches are also supported in the full range of Cisco network management solutions.
Specifications
Summary
- Product Description
- Cisco Catalyst 2960-Plus 48PST-S - switch - 48 ports - Managed - rack-mountable
- Device Type
- Switch - 48 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Fast Ethernet
- Ports
- 48 x 10/100 (PoE) + 2 x Gigabit SFP + 2 x 10/100/1000
- Power Over Ethernet (PoE)
- PoE
- PoE Budget
- 370 W
- Performance
- Switching capacity: 16 Gbps , Forwarding performance (64-byte packet size): 13.1 Mpps
- Capacity
- Active VLANs: 64
- Jumbo Frame Support
- 9018 bytes
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, CLI
- Features
- Full duplex capability, BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, STP support, RSTP support, MSTP support, DHCP snooping, PAgP support, TFTP support, QoS, DAI, Cisco EnergyWise technology, SRR, LLDP support, DHCP relay, LACP, MAC Address Notification, MIB, CoS, DSCP support
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 45 cm x 33.2 cm x 4.4 cm
- Weight
- 5.4 kg
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 48 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Fast Ethernet
- Ports
- 48 x 10/100 (PoE) + 2 x Gigabit SFP + 2 x 10/100/1000
- Power Over Ethernet (PoE)
- PoE
- PoE Budget
- 370 W
- Performance
- Switching capacity: 16 Gbps , Forwarding performance (64-byte packet size): 13.1 Mpps
- Capacity
- Active VLANs: 64
- Jumbo Frame Support
- 9018 bytes
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, CLI
- Authentication Method
- RADIUS, TACACS+
- Features
- Full duplex capability, BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, STP support, RSTP support, MSTP support, DHCP snooping, PAgP support, TFTP support, QoS, DAI, Cisco EnergyWise technology, SRR, LLDP support, DHCP relay, LACP, MAC Address Notification, MIB, CoS, DSCP support
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
- RAM
- 128 MB
- Flash Memory
- 64 MB
- Status Indicators
- Port transmission speed, port duplex mode, system, status, RPS (Redundant Power Supply), PoE
Expansion / Connectivity
- Interfaces
- 48 x 100Base-TX RJ-45 PoE - 15.4 W , 2 x SFP uplink , 2 x 1000Base-T RJ-45 uplink
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 51.1 Watt
- Features
- Redundant Power System (RPS) connector
Miscellaneous
- MTBF
- 312,000 hours
- Compliant Standards
- CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1 Second Edition, Directive 2004/108/EC, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2006/95/EC, VCCI Class A, KN24, KN22 Class A, RoHS 2011/65/EU, EN 300386
Software / System Requirements
- Software Included
- Cisco IOS LAN Lite
Dimensions & Weight
- Width
- 45 cm
- Depth
- 33.2 cm
- Height
- 4.4 cm
- Weight
- 5.4 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - advance parts replacement - lifetime - response time: next business day , Technical support - consulting - 90 days
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 95% (non-condensing)
- Min Storage Temperature
- -25 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 10 - 95% (non-condensing)
