Description
Cisco Business 350 series switches are affordable managed switches that provide critical building blocks for any small office network. Intuitive dashboard simplifies network setup, and advanced features accelerate digital transformation, while pervasive security protects business-critical transactions. Cisco Business 350 series switches provide the ideal combination of affordability and capabilities for small office and help you create a more efficient, better-connected workforce.
Cisco Business 350 series switches are fixed-configuration managed Ethernet switches. All Cisco Business 350 series switches support the advanced security management capabilities and network features you need to support enterprise-class data, voice, security, and wireless technologies. At the same time, these switches are simple to deploy and configure, allowing you to take advantage of the managed network services your business needs.
-
SWITCH PORTS
8-Port 10/100/1000 + 2 x 1GE copper/SFP combo -
SIMPLE
Intuitive Cisco Business Dashboard or on-box U/I simplifies network operations and automates lifecycle management -
POWER-OVER-ETHERNET
8 PoE ports with 67W total power budget, PoE, PoE+ -
ENHANCED SECURITY
IP-MAC port biding detects and blocks deliberate network attacks. IPv6 First Hop Security provides unparalleled protection against a vast range of address spoofing and man-in-the-middle attacks on IPv6 networks -
INNOVATIVE DESIGN
Elegant and compact design, ideal for installation outside of wiring closet such as retail stores, open plan offices, and classrooms
Specifications
Summary
- Product Description
- Cisco Business 350 Series 350-8P-2G - switch - 8 ports - Managed - rack-mountable
- Device Type
- Switch - 8 ports - L3 - Managed - stackable
- Enclosure Type
- Rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 8 x 10/100/1000 (PoE+) + 2 x combo SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 67 W
- Performance
- Switching capacity: 20 Gbps , Forwarding performance (64-byte packet size): 14.88 Mpps
- Capacity
- RPVST+ instances: 126 , MSTP instances: 8 , VLANs supported: 4094 , ACL rules: 1024 , Buffer capacity (MB): 1.5
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 2KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MLDv2, MLD, CIDR, MSTP, RSTP, STP
- Remote Management Protocol
- SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS
- Features
- Flow control, BOOTP support, ARP support, VLAN support, Syslog support, DoS attack prevention, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, firmware upgradable, SNTP support, DHCP snooping, QoS, DHCP server, DAI, PVST+, reset button, STP Root Guard, UDLD, fanless, LACP support, LLDP support, DHCP relay, MIB, MVR, GVRP, 802.1x authentication, ToS, DSCP support, cable test, IP source guard, SmartPort technology, dual image support, DNS client, SCT, PVE, LLDP-MED, IPMB, SSD, ISATAP tunnel support, RA guard, UDP, WRR, HOL Blocking Prevention, loopback detection, Unknown Storm Control, BPDU Guard, LAG, VSDP, RPVST+, DAD
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3az
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 26.8 cm x 32.3 cm x 4.4 cm
- Weight
- 3.5 kg
- Localisation
- Kuwait, Qatar, Saudi Arabia, Hong Kong, Malaysia, Singapore, United Kingdom
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 8 ports - L3 - Managed - stackable
- Enclosure Type
- Rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 8 x 10/100/1000 (PoE+) + 2 x combo SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 67 W
- Performance
- Switching capacity: 20 Gbps , Forwarding performance (64-byte packet size): 14.88 Mpps
- Capacity
- RPVST+ instances: 126 , MSTP instances: 8 , VLANs supported: 4094 , ACL rules: 1024 , Buffer capacity (MB): 1.5
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 2KB
- Max Units In A Stack
- 4
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MLDv2, MLD, CIDR, MSTP, RSTP, STP
- Remote Management Protocol
- SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS
- Encryption Algorithm
- SSL
- Authentication Method
- Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2)
- Features
- Flow control, BOOTP support, ARP support, VLAN support, Syslog support, DoS attack prevention, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, firmware upgradable, SNTP support, DHCP snooping, QoS, DHCP server, DAI, PVST+, reset button, STP Root Guard, UDLD, fanless, LACP support, LLDP support, DHCP relay, MIB, MVR, GVRP, 802.1x authentication, ToS, DSCP support, cable test, IP source guard, SmartPort technology, dual image support, DNS client, SCT, PVE, LLDP-MED, IPMB, SSD, ISATAP tunnel support, RA guard, UDP, WRR, HOL Blocking Prevention, loopback detection, Unknown Storm Control, BPDU Guard, LAG, VSDP, RPVST+, DAD
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3az
- Processor
- X ARM: 800 MHz
- RAM
- 512 MB
- Flash Memory
- 256 MB
- Status Indicators
- Status, PoE, link/activity/speed
Expansion / Connectivity
- Interfaces
- 8 x 10/100/1000 Base-T RJ-45 PoE+ , 2 x 1000Base-T / 1000Base-X RJ-45/SFP , 1 x console (mini-USB) Type B , 1 x USB Type A , 1 x console RJ-45
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 83.17 Watt
Miscellaneous
- Rack Mounting Kit
- Included
- MTBF
- 1,786,412 hours
- Compliant Standards
- UL 60950, CSA 22.2, FCC CFR47 Part 15 B Class A, USGv6
- Localisation
- Kuwait, Qatar, Saudi Arabia, Hong Kong, Malaysia, Singapore, United Kingdom
Dimensions & Weight
- Width
- 26.8 cm
- Depth
- 32.3 cm
- Height
- 4.4 cm
- Weight
- 3.5 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - replacement - lifetime - response time: next business day , Technical support - web support - 1 year , Technical support - phone consulting - 1 year
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -25 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 10 - 90% (non-condensing)
