Description
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to battery during power events.
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
-
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms. -
10/100 BaseT connection
Connect the device to a network using a 10 or 100 BaseT connection -
Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. -
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Specifications
Summary
- Product Description
- APC Smart-UPS SRT 8000VA - UPS - 8000 Watt - 8000 VA
- Device Type
- UPS - rack-mountable / external
- Rack Size
- 6U
- Weight
- 111.82 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 230 V ± 3%
- Power Capacity
- 8000 Watt / 8000 VA
- Input Connectors
- Hardwire 5-wire (3PH + N + G), hardwire 3-wire (1PH + N + G)
- Output connectors
- 6 x power IEC 60320 C13 , 4 x power IEC 60320 C19 , 1 x hardwire 3-wire (HN + G) , 3 x IEC connector
- Battery
- Lead Acid
- Run Time (Up To)
- 5.3 min at full load
- Networking
- Ethernet 10/100, USB
- Colour
- Black
- Dimensions (WxDxH)
- 26.3 cm x 71.5 cm x 43.2 cm
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- UPS - rack-mountable / external
- Height (Rack Units)
- 6U
- Colour
- Black
Power Device
- UPS Technology
- On-line
- Input Voltage
- AC 230 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 45 - 65 Hz
- Input Connectors
- Hardwire 5-wire (3PH + N + G), hardwire 3-wire (1PH + N + G)
- Power Output Connectors Details
- 6 x power IEC 60320 C13 , 4 x power IEC 60320 C19 , 1 x hardwire 3-wire (HN + G) , 3 x IEC connector
- Output Voltage
- AC 230 V ± 3% - 50/60 Hz
- Power Capacity
- 8000 Watt / 8000 VA
- Output Waveform
- Sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 480 Joules
- Efficiency
- 98%
Battery
- Technology
- Lead Acid
- Run Time (Up To)
- 5.3 min at full load , 14.8 min at half load
- Recharge Time
- 3 hours
- Features
- Maintenance free, sealed, leak-proof
Networking
- Remote Management Interface
- Ethernet 10/100, USB
Expansion / Connectivity
- Interfaces
- 1 x management (Ethernet) - RJ-45 , 1 x management (USB) - 4 pin USB Type B , 1 x EPO (emergency power off) , 1 x serial - RJ-45
- Expansion Slots
- 1 (total) / 1 (free) x SmartSlot
Miscellaneous
- Features
- Audible alarm, LCD display
- Compliant Standards
- C-Tick, VDE, IEC 60950, EN 50091-2, RoHS, EN 50091-1, REACH, EN 62040-2, IP20, EAC
Software / System Requirements
- Software Included
- APC PowerChute Business Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years , Limited warranty - batteries - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95% (non-condensing)
- Sound Emission
- 55 dBA
Dimensions & Weight
- Width
- 26.3 cm
- Depth
- 71.5 cm
- Height
- 43.2 cm
- Weight
- 111.82 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 60 cm
- Shipping Depth
- 100 cm
- Shipping Height
- 46.1 cm
- Shipping Weight
- 126.82 kg
