Description
Smart-UPS RT is a family of high performance UPSs for servers, networking equipment, telecommunication systems, industrial and medical equipment, and other mission-critical applications. Smart-UPS RT UPSs are based on the field-proven, industry-leading Smart-UPS functionality, but feature double conversion on-line topology, which delivers tight voltage and frequency regulation, zero transfer time to and from battery, and input power factor correction. While offering advanced performance and high availability features, the Smart-UPS RT can be managed using PowerChute software, as well as an array of SmartSlot accessories. Smart-UPS RT provides battery back up to the load through the use of internal batteries. However, an unlimited number of external battery packs can be added to meet desired levels of runtime. All Smart-UPS RTs and battery packs ship in tower configuration, while easily converting to the 19" rack-mount mode with the addition of an APC Rail Kit.
Specifications
Summary
- Product Description
- APC Smart-UPS RT 1000 - UPS - 700 Watt - 1000 VA
- Device Type
- UPS - external
- Rack Size
- 2U
- Weight
- 23 kg
- Input Voltage
- AC 220/230/240 V
- Output Voltage
- AC 220/230/240 V ± 5%
- Power Capacity
- 700 Watt / 1000 VA
- Input Connectors
- 1 x power IEC 60320 C14
- Output connectors
- 6 x power IEC 60320 C13
- Battery
- Lead Acid
- Battery Form Factor
- Plug-in module
- Run Time (Up To)
- 10.2 min at full load
- Colour
- Black
- Dimensions (WxDxH)
- 43 cm x 48 cm x 9 cm
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- UPS - external
- Battery Enclosure Type
- Plug-in module
- Height (Rack Units)
- 2U
- Colour
- Black
Power Device
- UPS Technology
- On-line
- Supported Battery Technology
- Lead Acid
- Input Voltage
- AC 220/230/240 V
- Input Voltage Range
- AC 160 - 280 V
- Input Voltage Range (Adjustable)
- AC 100 - 280 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 50/60 Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 6 x power IEC 60320 C13
- Output Voltage
- AC 220/230/240 V ± 5% - 50/60 Hz
- Power Capacity
- 700 Watt / 1000 VA
- Output Waveform
- Sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 420 Joules
- Circuit Protection
- Circuit breaker
Battery
- Technology
- Lead Acid
- Run Time (Up To)
- 10.2 min at full load
- Recharge Time
- 3 hours
Expansion / Connectivity
- Interfaces
- 1 x management (RS-232) - 9 pin D-Sub (DB-9)
- Expansion Slots
- 1 (total) / 1 (free) x SmartSlot
Miscellaneous
- Cables Included
- Serial cable - external
- Features
- Audible alarm
- Compliant Standards
- C-Tick, ISO 9001, GOST, EN 60950, EN 61000-3-2, PCBC, UL 1449, VDE, EN55022 Class A, ISO 14001
Software / System Requirements
- Software Included
- Drivers & Utilities, APC PowerChute plus, APC PowerChute Business Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Min Storage Temperature
- -20 °C
- Max Storage Temperature
- 50 °C
- Humidity Range Operating
- 0 - 95%
- Humidity Range Storage
- 0 - 95%
Dimensions & Weight
- Width
- 43 cm
- Depth
- 48 cm
- Height
- 9 cm
- Weight
- 23 kg
