Description
Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
-
Cold-start capable
Provides temporary battery power when the utility power is out. -
Energy meter
Provides actual kilowatt hours of usage for energy conscious users. -
Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. -
High online efficiency
Reduces utility costs, generates less heat. -
Intelligent Card Slot
Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS. -
Intuitive LCD interface
Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys. -
Predictive replace battery date
Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning. -
Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics. -
Single switched outlet group
Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding. -
SmartConnect
Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services. -
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Specifications
Summary
- Product Description
- APC Smart-UPS SMT1000IC - UPS - 700 Watt - 1000 VA - with APC SmartConnect
- Device Type
- UPS - external
- Weight
- 18.86 kg
- Input Voltage
- AC 220/230/240 V
- Output Voltage
- AC 230 V ± 5%
- Power Capacity
- 700 Watt / 1000 VA
- Input Connectors
- 1 x power IEC 60320 C14
- Output connectors
- 8 x power IEC 60320 C13 , 2 x IEC jumper
- Battery
- Lead Acid
- Batteries Qty
- 1
- Run Time (Up To)
- 5.8 min at full load
- Networking
- RS-232, USB
- Colour
- Black
- Dimensions (WxDxH)
- 17.1 cm x 43.9 cm x 21.9 cm
- Manufacturer Warranty
- 3-year warranty
- Bundled with
- APC SmartConnect
Detailed Specification
General
- Device Type
- UPS - external
- Colour
- Black
- Bundled with
- APC SmartConnect
Power Device
- UPS Technology
- Line interactive
- Input Voltage
- AC 220/230/240 V
- Input Voltage Range
- AC 160 - 286 V
- Input Voltage Range (Adjustable)
- AC 151 - 302 V
- Frequency Provided
- 50/60 Hz ± 3Hz
- Frequency Required
- 50/60 Hz ± 3Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 8 x power IEC 60320 C13 , 2 x IEC jumper
- Output Voltage
- AC 230 V ± 5% - 50/60 Hz
- Power Capacity
- 700 Watt / 1000 VA
- Output Waveform
- Sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 459 Joules
- Circuit Protection
- Circuit breaker
Battery
- Quantity
- 1
- Technology
- Lead Acid
- Run Time (Up To)
- 5.8 min at full load , 19.1 min at half load , 183 min at 50 Watts , 100 min at 100 Watts , 45.2 min at 200 Watts , 24.7 min at 300 Watts , 15 min at 400 Watts , 9.8 min at 500 Watts , 7.1 min at 600 Watts , 5.8 min at 700 Watts
- Recharge Time
- 3 hours
- Transfer Time
- 6 ms
- Features
- Maintenance free, sealed, leak-proof
Networking
- Remote Management Interface
- RS-232, USB
Expansion / Connectivity
- Interfaces
- 1 x management (RS-232) , 1 x USB , 1 x EPO (emergency power off)
- Expansion Slots
- 1 (total) / 1 (free) x SmartSlot
Miscellaneous
- Cables Included
- Network cable - external , USB cable - external
- Features
- Audible alarm, emergency power off, LCD display, Automatic Voltage Regulation (AVR), cold-start function, automatic self-test, predicitive failure notification, hot-swappable batteries, energy metre
- Compliant Standards
- CSA, UL 1778, VDE, IEC 62040-2, EN 62040-2, EAC, RCM, IEC 62040-1, EN 62040-1
Software / System Requirements
- Software Included
- APC PowerChute Business Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - replace or repair - 3 years , Limited warranty - batteries - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95%
- Sound Emission
- 41 dBA
Dimensions & Weight
- Width
- 17.1 cm
- Depth
- 43.9 cm
- Height
- 21.9 cm
- Weight
- 18.86 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 32.8 cm
- Shipping Depth
- 59.5 cm
- Shipping Height
- 37.6 cm
- Shipping Weight
- 22.77 kg
