Description
The Back-UPS CS provides professional-grade power protection for office and home office systems. Battery powered & surge protected power outlets, built-in phone/fax/modem line (DSL compatible) protection, safe system shutdown software with sophisticated power management features and pro-active audio-visual status indicators ensure office systems and their valuable data are protected from dangerous power surges, spikes and blackouts. USB connectivity gives users more flexibility making installation quicker and easier. Easy access to a hot-swappable, user-replaceable battery also makes servicing the Back-UPS CS hassle-free. These features along with its classic styling make the Back-UPS CS a perfect choice for protecting your important office and home office systems.
-
Serial connectivity
Provides management of the UPS via a serial port -
USB connectivity
Provides management of the UPS via a USB port (not available on all models)
Specifications
Summary
- Product Description
- APC Back-UPS CS 350 - UPS - 210 Watt - 350 VA
- Device Type
- UPS - external
- Weight
- 6.3 kg
- Load Rating
- Individual PC
- Input Voltage
- AC 230 V
- Output Voltage
- AC 230 V
- Power Capacity
- 210 Watt / 350 VA
- Input Connectors
- 1 x power IEC 60320 C14
- Output connectors
- 1 x power IEC 60320 C13 (surge) , 3 x power IEC 60320 C13 (UPS and surge)
- Battery
- Lead Acid
- Battery Form Factor
- Plug-in module
- Batteries Qty
- 1
- Run Time (Up To)
- 4.7 min at full load
- Networking
- RS-232, USB
- Colour
- Beige
- Dimensions (WxDxH)
- 9.1 cm x 28.4 cm x 16.5 cm
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- UPS - external
- Battery Enclosure Type
- Plug-in module
- Colour
- Beige
Power Device
- Load Rating
- Individual PC
- Supported Battery Technology
- Lead Acid
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 196 - 280 V
- Frequency Required
- 50/60 Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 1 x power IEC 60320 C13 (surge) , 3 x power IEC 60320 C13 (UPS and surge)
- Output Voltage
- AC 230 V
- Power Capacity
- 210 Watt / 350 VA
- Dataline Surge Protection
- Phone line - RJ-45
- Surge Suppression
- Yes
- Surge Energy Rating
- 300 Joules
- Circuit Protection
- Circuit breaker
Battery
- Quantity
- 1
- Technology
- Lead Acid
- Run Time (Up To)
- 4.7 min at full load
- Recharge Time
- 6 hours
Networking
- Remote Management Interface
- RS-232, USB
Expansion / Connectivity
- Interfaces
- 1 x USB / serial RS-232 - RJ-45
Miscellaneous
- Cables Included
- USB cable - external
- Features
- Audible alarm
- Compliant Standards
- C-Tick, GOST, UL 1449, VDE, EN 50091-2, EN 50091-1
Software / System Requirements
- Software Included
- APC PowerChute Personal Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - replace or repair - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Min Storage Temperature
- -15 °C
- Max Storage Temperature
- 45 °C
- Humidity Range Operating
- 0 - 95%
- Humidity Range Storage
- 0 - 95%
- Sound Emission
- 40 dBA
Dimensions & Weight
- Width
- 9.1 cm
- Depth
- 28.4 cm
- Height
- 16.5 cm
- Weight
- 6.3 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 24.1 cm
- Shipping Depth
- 36.8 cm
- Shipping Height
- 17.8 cm
- Shipping Weight
- 7.1 kg
