Description
Coming with advanced HomePlug AV2 technology, TL-PA7017P KIT provides users with high-speed data transfer rates of up to 1000 Mbps - ideal for bandwidth-intensive applications such as multiple HD/3D/4K video streaming, online gaming, and large file transfers. With one Gigabit Ethernet port, TL-PA7017P KIT allows users to connect a bandwidth-intensive device to the internet at high speeds, ensuring smooth streaming for Ultra HD videos. This makes the TL-PA7017P KIT the perfect home entertainment companion.
-
1000 Mbps perfect for bandwidth-hungry activities
Coming with advanced HomePlug AV2 technology, TL-PA7017P KIT provides users with high-speed data transfer rates of up to 1000 Mbps - ideal for bandwidth-intensive applications such as multiple HD/3D/4K video streaming, online gaming, and large file transfers. -
Gigabit port for ultra-fast data transfer
With one Gigabit Ethernet port, TL-PA7017P KIT allows users to connect a bandwidth-intensive device to the internet at high speeds, ensuring smooth streaming for Ultra HD videos. This makes the TL-PA7017P KIT the perfect home entertainment companion. -
Plug and Play, no configuration required
Connect a powerline adapter to the router. Plug another powerline adapter into a wall socket in another room. Connect it to your internet enabled device via Ethernet - and you're done! -
Extra power outlet for additional devices
Finding it hard to plug in your devices? The TL-PA7017P KIT has an integrated AC pass-through power socket. Your powerline adapter can now be used like a traditional electrical outlet. Plug your smart TV or game consoles into the adapter. No socket left to waste. The built-in noise filter helps prevent electrical signal noise from affecting your powerline performance. -
Up to 85% power saved
The future's looking green for powerline adapters. TL-PA7017P KIT's practical design and sophisticated Power-Saving Mode, which automatically switches from its regular "Working" mode to "Power-Saving" mode, reduces its energy consumption by up to 85%.
Specifications
Summary
- Product Description
- TP-Link AV1000 - Gigabit Passthrough Starter Kit - powerline adapter kit - wall-pluggable
- Device Type
- Powerline adapter kit
- Packaged Quantity
- 2 (specifications are for single item)
- Enclosure Type
- Wall-pluggable
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901
- Data Transfer Rate
- 1 Gbps
- Features
- Reset button
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0
- Power
- AC 220 V (50 Hz)
- Dimensions (WxDxH)
- 5.8 cm x 4.2 cm x 9.5 cm
- System Requirements
- Apple MacOS, Linux, Microsoft Windows Server 2003, Microsoft Windows 2000/XP/Vista/7, Windows 8, Windows 8.1
Detailed Specification
General
- Packaged Quantity
- 2 (specifications are for single item)
- Device Type
- Powerline adapter kit
- Enclosure Type
- Wall-pluggable
- Connectivity Technology
- Wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901
- Data Transfer Rate
- 1 Gbps
- Encryption Algorithm
- 128-bit AES
- Features
- Reset button
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0, RoHS
- Status Indicators
- Power, LAN, powerline
Line Properties
- Line Coding Format
- OFDM
Expansion / Connectivity
- Interfaces
- LAN: 1 x HomePlug AV 2.0
Power
- Voltage Required
- AC 220 V (50 Hz)
- Power Consumption Operational
- 2.3 Watt
Miscellaneous
- Cables Included
- 1 x network cable
Software / System Requirements
- OS Required
- Apple MacOS, Linux, Microsoft Windows Server 2003, Microsoft Windows 2000/XP/Vista/7, Windows 8, Windows 8.1
Dimensions & Weight
- Width
- 5.8 cm
- Depth
- 4.2 cm
- Height
- 9.5 cm
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
